  • Military Knowledge: Shahed 171 (Simorgh) And Shahed Stealth Drones Family

    Military Knowledge: Shahed 171 (Simorgh) And Shahed Stealth Drones Family

    History
    The story of Iranian Simorgh family drones began with hunting “The Beast of Kandahar”. On December 4, 2011, the Iranian Islamic Revolutionary Guard Corps Aerospace Force managed to take control of an advanced US drone named Lockheed Martin RQ-170 Sentinel, known as The Beast of Kandahar. The stealth RQ-170 drone had entered Iran’s airspace to collect information and espionage, and finally, through processes, Iran managed to override its controls and landed it near the town of Bardaskan.

    Iran force-landed RQ-170 near Bardaskan

    In May 12, 2014, during Iran’s Commander-in-Chief’s visit to the IRGC Aerospace Force’s Achievements Exhibition, it was stated that the Iranian Armed Forces had succeeded in obtaining all the software information of this bird and had obtained images from all the bases where this bird was present. During the same visit, it was also announced that a 15% scale version has flown successfully and two 40% and 100% scale versions will be flown in the same year. Also, General Hajizadeh the commander of IRGC Aerospace Force stated that this drone will also be armed with missiles. In November 2014, a video of the successful flight of this bird was published.

    Three drones displayed in the IRGC achievements exhibition in 2014

    In 2016, during Admiral Shamkhani’s visit to the IRGC Aerospace Force achievements exhibition, new variants of this series of UAVs named Shahed 181 were unveiled. Two years later, Shahed 191 was unveiled during the Eghtedar 40 exhibition. It should be noted that both Shahed 181 and Shahed 191 drones are 60% scale version of Shahed 171 drone.

    Different variants of Shahed stealth drones:
    The Shahed stealth drone family includes five combat and reconnaissance types, each of which is measured in terms of its size compared to the RQ-170 or Shahed-171 drone. In this way, the Shahed-171 drone, which is nicknamed Simorgh, is a 100% scale version and completely identical to the RQ-170 Sentinel, and the two Shahed-191 and 181 drones, which carry the nickname of Saegheh, are both 60% scale version of the Shahed 171. In addition to the previous three variants, there are two Shahed-141 and 161 drone, both of which are 40% scale version of Shahed 171 in terms of dimensions.
    It should be noted that there are also two civilian variants of this drone. The first variant is the initial 15% scale version used for flight testing and the second variant is a 60% scale version that is used for cloud seeding. In this way, the number of Shahed-171 stealth drones reaches seven.

    The importance of downing of the RQ-170 was very high, so that after landing this drone, the Iranians realized how much modern technology was used in it at once. Advanced lightweight materials were used in the structure and body of this UAV, and there was a special coating and color on the body. The use of a very advanced engine, an advanced camera with high accuracy and range, and a very advanced synthetic-aperture radar (SAR) are among the other disclosed equipment of this extremely valuable American drone. These features, along with the use of flying wing design, made it one of the most advanced drones in the world.
    Therefore, this drone is considered the most important drone captured by Iran in the last few decades. It can even be considered one of the most important trophies obtained after World War II.

    Shahed-171 (Simorgh):
    Shahed-171 also known as Simorgh, is a 100% scale version of RQ-170, and uses a Toloue-14 turbofan engine. Toloue-14 mini turbofan is the result of turning Toloue-4 mini turbojet engine into a turbofan. Thanks to its turbofan engine, Shahed-171 has reached a flight endurance of 10 hours and a maximum range of 4400 km. The flight ceiling of 40,000 feet (12,000 meters), the maximum take-off weight of 3070 kg and the maximum speed of 460 km/h are other specifications of this drone.
    Like the RQ-170 UAV, Shahed-171 uses a shield for its thermal camera, which reduces its radar cross section.

    The similarity of camera cover in Shahed-171 and RQ-170

    Shahed-171 specifications:
    Role: Reconnaissance
    Length: 4.75 meters
    Wingspan: 13 meters
    Height: 1.2 meters
    Reconnaissance range: 2200 km
    Maximum range: 4400 km
    Flight endurance: 10 hours
    Flight ceiling: 40,000 feet (12,000 meters)
    Engine: Turbofan Toloue-14
    Thrust engine power: 6 kilonewtons
    Maximum speed: 460 km/h
    Cruise speed: Unknown
    Weight: Unknown
    Maximum take-off weight: 3070 kg

    Shahed-171 (Simorgh) drone

    Shahed-181 (Saegheh):
    Shahed-181 drone also known as Saegheh (Lightning), is a 60% scale version of Shahed-171 drone and uses a two-stroke propeller engine. Due to the expensiveness of the Shahed-171 stealth drone, in order to reduce the production cost and also easy mass production, the Shahed 181 drone has been mass produced by removing the landing gear and using a piston engine.
    Shahed-181 has the capability of carrying four Sadid-342 bombs under the body between its skates. Due to having folding wings, Sadid-342 bomb occupies the least space and four of them are easily placed next to each other, and for this reason, it is the best option for use on this drone.

    Shahed-181 takes help from a vehicle to take off. The drone is placed on a special pneumatic launcher on the vehicle. After the vehicle reaches the desired speed, the drone is launched and flies. For landing, Shahed-181 slides on the ground using his skates to stop.

    Shahed-181 specifications:
    Role: Reconnaissance and combat
    Length: 2.7 meters
    Wing length: 7.3 meters
    Height: 0.7 meters
    Combat range: 1150 km
    Maximum range: 3450 km
    Flight endurance: 13 hours
    Flight ceiling: 15000 feet (4572 meters)
    Engine: 80 horsepower piston
    Maximum speed: 220 km/h
    Cruise speed: 150 km/h
    Weight: Unknown
    Maximum take-off weight: 480 kg
    Maximum weight of fuel and cargo: 165 kg
    Take off type: By vehicle
    Landing: By skate
    Armament: 4 smart bombs

    Shahed-181 (Saegheh) drone

    Shahid-191 (Saegheh 2):
    Shahed-191 drone also known as Saegheh 2, like the Shahed-181 is a 60% scale version of Shahed-171. But Shahed-191 uses a turbojet engine instead of a piston engine. The radar cross-section in Shahed-191 is smaller due to the use of a turbojet engine, and Sadid bombs are placed inside the body of the drone.

    Shahed-191 uses a mini turbojet engine with a power of 1078.8 newtons, which is known as Turbojet 894, or a Toloue-10 turbojet engine with a power of 1100 to 1200 newtons. It is worth noting that the 894 turbojet engine was manufactured by the IRGC Aerospace Force and the Toloue-10 turbojet engine was manufactured by the Iran’s Ministry of Defense.

    Shahed-191 has a higher flight ceiling as well as greater stealth profile, and for this reason, an internal place for carrying weapons has been designed to help the stealthy features of this drone during combat missions. Saegheh 2 has the ability to carry two Sadid-342 bombs in its internal weapons bay.

    Based on the published images, it seems that this drone uses the Oghab 4 electro-optic system.


    A type of SAR radar called Absar has been developed specifically for this drone, which is installed in camera place and provides the possibility of searching for objects in the form of 3D imaging.

    Shahed-191 specifications:
    Role: Reconnaissance and combat
    Length: 2.7 meters
    Wing length: 7.3 meters
    Height: 0.7 meters
    Combat range: 500 km
    Maximum range: 1500 km
    Flight endurance: 4.5 hours
    Flight ceiling: 30000 feet (9144 meters)
    Engine: Turbojet 894 or Toloue-10
    Thrust engine power: 110 kg of force (1078.8 newtons)
    Maximum speed: 350 km/h
    Cruise speed: 200 km/h
    Weight: Unknown
    Maximum take-off weight: 500 kg
    Maximum weight of fuel and cargo: 230 kg – 10 kg of optical cargo and 100 kg of weapons in weapon bay
    Take off type: By vehicle
    Landing: By skate
    Armament: 2 smart bombs

    Shahed-191 (Saegheh 2) drone

    Shahed-161:
    Shahed-161 is a 40% scale version of Shahed-171 drone. This drone uses a small and unannounced micro-turbojet engine. In the description provided for Shahed-161, the type of cargo is announced a seeker and warhead. This information strengthens the possibility that this variant is a suicide drone. If Shahed-161 is a suicide type of the Simorgh family, it must be said that this suicide drone is very a expensive one and therefor will be used to hit special targets such as air defense systems. The thermal seeker of Shahed-161 is installed on the wing and the right side of the engine, and when the UAV dives, it gets a better view of the ground.
    One of the characteristics of Shahed-161 is the possibility of different launch. Due to the lightness of this drone compared to other types, a pneumatic launcher has been used, which makes it possible to launch this drone faster from the vehicle. It is also possible to use this technique on other members of the Simorgh family that fly from the vehicle. This drone can also land with the help of a recovery parachute or skates.

    Shahed-161 specifications:
    Role: Reconnaissance and suicide
    Length: 1.9 meters
    Wingspan: 5.13 meters
    Height: 0.71 meters
    Combat range: 150 km
    Maximum range: 300 km
    Flight enduracne: 3 hours
    Flight ceiling: 25000 feet (7620 meters)
    Engine: HKS microjet
    Engine power: 40 kg of power
    Maximum speed: 350 km/h
    Cruise speed: 150 km/h
    Weight: Unknown
    Maximum take-off weight: 170 kg
    Maximum weight of fuel and cargo: 40 kg
    Cargo: Seeker and warhead
    Take off type: Pneumatic launcher
    Landing: By skate, recovery parachute

    Shahed-161 drone

    Shahed-141:
    Shahed-141 drone has not been officially unveiled yet. This drone is a 40% scale version of Shahed-171. According to the information provided at the IRGC achievements exhibition in Isfahan, Shahed-141 has a Wankel 783 engine with a power of 32 horsepower, and thanks to the capacity of carrying 90 kg of cargo, it can carry a high-quality camera and a 12-hour flight endurance for reconnaissance missions.

    Shahed-141 specifications:
    Role: Reconnaissance
    Length: 1.9 meters
    Wingspan: 5.13 meters
    Height: 0.4 meters
    Reconnaissance range: 1300 km
    Maximum range: 2600 km
    Flight endurance: 12 hours
    Flight ceiling: 15000 feet (4572 meters)
    Engine: Wankel 783 piston 32 hsp
    Maximum speed: 220 km/h
    Cruise speed: 150 km/h
    Weight: Unknown
    Maximum take-off weight: 200 kg
    Maximum weight of fuel and cargo: 90 kg
    Take off type: Pneumatic launcher
    Landing: By skate, recovery parachute

    Shahed-141 drone

    15% scale version of Shahed-171:
    Information and a picture of this variant are not available, but it can be pointed out that this variant is the first sample made during the reverse engineering of the RQ-170 UAV. Making a 15% scale version of RQ-170 has helped to better understand the flight structure of this drone, and this has accelerated the build process and use of the Shahed family of stealth drones.

    Samavat drone:
    The Samavat drone was showcased for the first time at the IRGC Achievements Exhibition in Birjand. This drone is equivalent to the Shahed-161 drone and is used for cloud seeding.
    According to published information, the Samavat drone can be used for surveillance and combat missions, and for this purpose, it is possible to separate the silver iodide holding rods from the drone. Except for the body length of 1.7 meters, which is given in the Samavat banner, the rest of the specifications are very similar to Shahed-161.

    Combat history
    The Shahed family of stealth drones have been widely deployed in the IRGC Air Force and have carried out a large number of reconnaissance and combat operations so far. But the first combat operation that has been officially confirmed is related to the use of Shahed 181 and 191 drones on June 18, 2017 in Operation Laylat al-Qadr against ISIS in Syria. It should be noted that due to the confidentiality and sensitivity, most of the missions of this category of drones are not officially announced.

    Shahed 171 And Shahed Stealth Drones Family – click to view full size

    Posters of “Shahed 171 And Shahed Stealth Drones Family” in Russian (Шахед 171), Arabic, Kurdish, Azeri (Şahid 171), Hebrew (שאהד-171), Chinese (见证者-171) and Persian:

  • Military Knowledge: Storm Shadow Cruise Missile

    Military Knowledge: Storm Shadow Cruise Missile

    History
    In July 1996, the Storm Shadow design presented by two companies, Matra and British Aerospace, won a heavy competition among 6 other designs from powerful companies McDonnell Douglas, Texas Instruments/Short Brothers, Hughes/Smiths Industries, Daimler-Benz Aerospace/Bofors, GEC-Marconi and Rafael. A development and production contract was signed in February 1997, by which time Matra and BAe had completed the merger of their missile businesses to form Matra BAe Dynamics. France ordered 500 SCALP missiles in January 1998.

    It is worth noting that since 2001 and after the merger of Matra BAe Dynamics with the Italian company Alenia, this missile is developed and produced under the multinational company MBDA.

    This missile is known as “Storm Shadow” in UK and SCALP-EG in France. SCALP-EG in French stands for “Système de Croisière Autonome à Longue Portée – Emploi Général” and its English translation is “Long Range Autonomous Cruise Missile System General Purpose”.

    The Storm Shadow missile was used for the first time in 2003 during the Iraq war by the Tornado GR4 fighter jet of the British Royal Air Force.

    On November 27, 2013, this missile was tested on the Eurofighter Typhoon at the Decimomannu Air Base in Italy for a range of 250 km. This test was conducted by Alenia Aermacchi in the framework of a phase 2 improvement program for Germany, Italy, Spain and the United Kingdom.

    Design
    The Storm Shadow cruise missile was developed is based on French-developed Apache anti-runway cruise missile. These two missiles are similar in terms of aerodynamics and stealth, but the Storm Shadow missile uses a different engine and its warhead is integrated with high penetration power, while the warhead of the Apache cruise missile is a cluster munition.

    The air-launched version of Storm Shadow missile has a weight of 1300 kg, of which 450 kg is the warhead. The maximum diameter of the body is 63 cm, the distance between its two wings is 3 meters and the length of the missile is 5.1 meters. This missile reaches a maximum speed of Mach 0.8 (equivalent to 980 km/h at sea level) and a range of 560 km using a French TRI 60-30 engine with a power of 5.3 kilonewtons. It should be noted that in export versions, the range of this missile is limited to 300 km.

    This missile uses a two-stage warhead to penetrate the targets. This warhead, known as BROACH, is installed on two other missiles, AGM-154 Joint Standoff Weapon (JSOW) and AGM-86 ALCM, in addition to the Storm Shadow. The two stage warhead is made up from an initial shaped charge, which cuts a passage through armour, concrete, earth, etc., allowing a larger following warhead to penetrate inside the target.

    Combat records
    As mentioned earlier, the Storm Shadow missile was first used in combat in 2003 by Tornado fighter jets belonging to the 617 Squadron of the British Royal Air Force during the international invasion of Iraq.

    During the 2011 military intervention in Libya, SCALP-EG missiles were fired by French Air Force Rafale fighter jets and Storm Shadow missiles by Tornadoes of the Italian Air Force and the British Royal Air Force at targets including Al Jafra Air Base and a military shelter in Sirte, Muammar Gaddafi’s hometown. In December 2011, Italian defense officials noted that during the military intervention in Libya, Tornado fighter jets had fired between 20 and 30 Shadow Storm missiles, with a 97% success rate. This was the first time that Italian aircraft test-fired this missile in a real battle.

    On December 15, 2015 and January 2, 2016, French fighter jets fired twelve rounds of SCALP missiles at ISIS targets in Syria.

    On June 26, 2016, the British Royal Air Force, using a Tornado fighter jet, fired four Storm Shadow missiles at ISIS targets in Iraq.

    In October 2016, the UK government confirmed that Storm Shadow missiles sold to Saudi Arabia had been used by Saudi Arabia in the conflict in Yemen.

    In April 2018, the UK government announced that it had used Storm Shadow missiles (probably using Dassault Rafale fighters) to attack an alleged chemical weapons manufacturing facility in Himm Shinshar in Syria’s Homs province.

    It is also said that during the second Libyan war, the Emirati Mirage and Egyptian Rafale fighter jets may have used Storm Shadow missiles to attack Al-Watia Air Base in July 2020.

    In March 2021, two Royal Air Force FGR4 Typhoon jets attacked a group of ISIS caves near Erbil using a Storm Shadow missile, And the first combat use of the Storm Shadow was recorded by Typhoon fighter jet.

    After the United Kingdom announced that it would deliver the Storm Shadow missile to Ukraine in 2023, this missile entered the Russian-Ukrainian battles. According to video documentation, these missiles are fired by Ukrainian Sukhoi-24 fighter jets.

    An image of the combat use of Shadow Storm missile on the Ukrainian Sukhoi-24 fighter jet

    Variants of Storm Shadow missiles
    Apart from the export version with a range of 250 km and the original version with a range of 560 km, which is in the service of the British and French armies, the Storm Shadow missile has other versions:

    Black Shaheen:
    Developed by France for export to the United Arab Emirates for use with its Mirage 2000, modifications were made to reduce the range reportedly to 290 km (160 nmi; 180 mi) in order to comply with Missile Technology Control Regime guidelines.

    MdCN or SCALP Naval cruise missile:
    In 2006, the French division of MBDA began the development of a long-range vertical-launch cruise missile to be deployed on a new series of French warships and complement the conventional SCALP missiles. This missile, which is called “Missile de Croisière Naval (MdCN)” in French, is called “Naval Cruise Missile” in English.
    The MdCN missile with a range of more than 1000 km plays the same role as the American Tomahawk for the French. In addition to longer range, MdCN naval cruise missile has independent navigation function and final phase guidance with the help of infrared detection. In terms of appearance, this missile has many differences with the conventional version of Storm Shadow. This missile is made in a cylindrical shape and the wings are also folded into the body.
    The SCALP Naval missile has a length of 6.5 meters, a diameter of 50 centimeters and a wingspan of 2.85 meters. The weight of this missile is 1400 kg, of which 200 kg is the warhead. The engine of this missile is micro-turbojet TR50 and the speed of the missile reaches 1000 km/h using this engine.

    Specifications of MdCN Naval Cruise Missile:
    Type: Land-attack missile, Submarine-launched cruise missile
    Length: 6.5 meters
    Diameter: 50 cm
    Wingspan: 2.85 meters
    Weight: 1400 kg
    Warhead weight: 200 kg
    Speed: 1000 km/h
    Engine: Turbojet TRI50
    Range: more than 1000 km
    Launch platforms: FREMM-class frigates, Barracuda-class submarines, and Scorpène-class submarines
    Produced: MBDA France

    Missile de Croisière Naval (MdCN) / Naval Cruise Missile

    The MdCN missile is installed on six French FREMM-class frigates, Barracuda-class submarines and smaller submarines such as the Scorpène-class. This missile is launched in frigates through the Sylver launcher and in submarines through the 533 mm torpedo launch tube.

    The first successful launch of the MdCN missile was carried out in July 2013, at the Biscarosse test range, and it was able to pass all test stages in three launches.

    The MdCN missile was used in the first real battlefield operation in 2018 against alleged Syrian chemical weapons production sites in Damascus and Homs. In this operation, France launched 10 SCALP cruise missiles using five Dassault Rafale fighters and three SCALP Naval missiles using FREMM class frigates. In this operation, due to technical problems and lack of coordination, two frigates failed to fire missiles and only one frigate managed to launch a missile, and out of 10 missiles, one missile had a problem and fell into the sea.

    The first Barracuda-class submarine named FS Suffren, which was launched on October 20, 2020, successfully fired its first MdCN missile in the same year 2020. Considering the problems that arose in 2018 for the launch of the SCALP Naval missile, the successful launch of this missile was an indication of solving the coordination problems of this sea cruise with its marine launcher platforms.

    Specifications of Storm Shadow/SCALP-EG cruise missile:
    Type: Air-launched cruise missile
    Length: 5.10 meters
    Width: 630 mm
    Wingspan: 3 meters
    Weight: 1300 kg
    Warhead weight: 450 kg
    Engine: Turbojet TRI 60-30
    Speed: ~ 1000 km/h
    Range: 560 km (in export versions up to 300 km)
    Guidance: GPS – INS – IIR – TERPROM
    Launch platforms: Tornado, Mirage 2000, Rafale, Typhoon fighter jets
    Origin: France and UK (MBDA company)

    Storm Shadow Cruise Missile – click to view full size

    Storm Shadow cruise missile posters in Russian, Arabic, Azeri, Kurdish, Persian:

    Source:
    Storm Shadow
    Storm Shadow/SCALP EG Conventionally Armed Stand Off Missile (CASOM)
    Eurofighter flies with Storm Shadow missiles
    617 Squadron
    Italy Gives Bombing Stats for Libya Campaign
    Engine Support Surges With Rafale Flight Hours, Exports
    تصاویر ماهواره ای جدید از انهدام سامانه های ترکیه
    Turkey vows ‘retribution’ for attack on its positions in Libya’s al-Watiya
    MdCN (Missile De Croisière Naval – Naval Cruise Missile), France
    La famiglia di missili stealth “Storm Shadow / SCALP”

    BROACH warhead

  • Military Knowledge: Challenger 2

    Military Knowledge: Challenger 2

    The Challenger 2 is the third vehicle of this name, the first being the A30 Challenger, a World War II design using the Cromwell tank chassis with a 17-pounder gun. The second was the Persian Gulf War era Challenger 1, which was the British army’s main battle tank (MBT) from the early 1980s to the mid-1990s. The design process of the Challenger 2 tank was carried out between 1989 to 1994 by the British company “Vickers Defence Systems”, which also designed the Challenger 1 tank. Today, Challenger 2 is produced by BAE Systems Platforms & Services.

    The Challenger 2 tank was developed on the basis of the Challenger 1, however despite outward similarities to the Challenger 1, only about 3% of components are interchangeable with the earlier vehicle.

    The main armament is a L30A1 120-millimetre rifled tank gun, an improved derivative of the L11 gun used on the Chieftain and Challenger 1. Fifty rounds of ammunition are carried for the main armament, alongside 4,200 rounds of 7.62 mm ammunition for the tank’s secondary weapons: A L94A1 EX-34 chain gun mounted coaxially, and a L37A2 (GPMG) machine gun. The turret and hull are protected with second generation Chobham armour, also known as Dorchester. Powered by a Perkins CV12-6A V12 diesel engine, the tank has a range of 550 kilometres and maximum road speed of 59 kilometres per hour.

    Two 7.62 mm machine guns on the Challenger 2

    Challenger 2 benefits from a L30A1 120-millimetre rifled gun, firing both long rod penetrator and High Explosive Squash Head (HESH) ammunition natures. The rifled barrels increase stability and shooting accuracy. The “rifling” is for the purpose of exerting torque and thus imparting a spin to a projectile around its longitudinal axis during shooting to stabilize the projectile longitudinally by conservation of angular momentum, improving its aerodynamic stability and accuracy over smoothbore designs.

    L30A1 rifled gun on Challenger 2

    The commander has a panoramic SAGEM VS 580-10 gyrostabilised sight with laser rangefinder. The commander’s station is equipped with eight periscopes for 360° vision. The Thermal Observation and Gunnery Sight II (TOGS II), from Thales, provides night vision. The thermal image is displayed on both the gunner’s and commander’s sights and monitors. The gunner has a stabilised primary sight using a laser rangefinder, with a range of 200 m to 10 km. The driver’s position is equipped with a Thales Optronics image-intensifying Passive Driving Periscope (PDP) for night driving and a rear view thermal camera.

    The fire control system of Challenger 2 is the same as the US M1A1 Abrams and the French Leclerc MBT. Also, Challenger 2 and Abrams tanks use the same battlefield management system, which allows easy exchange of information between British and American tanks.

    Electro-optical systems used in the Challenger 2

    The turret and hull are protected with second generation Chobham armour, also known as Dorchester. The Dorchester armor, although lighter than the Chobham, provides better protection for the Challenger-2 tank.

    Challenger 2 is also equipped with an automatic fire extinguishing system in addition to the Nuclear, Biological and Chemical (NBC) protection system and Visual and Infrared Screening Smoke (VIRSS) systems.

    The Challenger 2 tank is designed in such a way that its detection and tracking by enemy detection radars is as low as possible. Therefore, the FV4034 Challenger 2 tank can be considered one of the most stealth tanks in the world.

    One of the most confidential information about main battle tanks is the amount of armor in different parts of it, which is usually published in an exaggerated form. An image of the actual amount of armor used in Challenger 2 has been published by a website that claims to have information about Challenger 2. The images below show the armor’s resistance against high-explosive anti-tank (HEAT) projectiles and kinetic energy (KE) projectiles.

    The Challenger 2 Powered by a Perkins CV12-6a turbocharged diesel engine. Using this engine, the Challenger 2 tank can reach a maximum range of 550 km and a maximum speed of 59 km/h.

    Challenger 2’s Perkins CV12-6a engine

    Challenger 2 uses Horstman Defence Systems second-generation hydrogas suspension units, which is an improved suspension system, along with improved gearbox and a Hydraulic Track Tensioner provide platform stability covering flat road surfaces through to rough cross-country terrain.

    The Challenger-2 is the Royal Army’s only main battle tank (MBT) today. The country of Oman has also recruited 38 units of this British tank.

    The Challenger 2 tank has participated in wars such as Bosnia, Kosovo and the Persian Gulf War. In 2003, during the Desert Storm operation in Iraq, a Challenger 2 tank seriously damaged another Challenger 2 tank, and there were no casualties.

    Challenger 2 Updates:

    CLIP update:
    The Challenger Lethality Improvement Programme (CLIP) was a programme to replace the current L30A1 rifled gun with the smoothbore Rheinmetall 120 mm gun currently used in the Leopard 2 and M1 Abrams. The use of a smoothbore weapon would have allowed Challenger 2 to use NATO standard ammunition, including tungsten-based kinetic energy penetrators which do not have the same political and environmental objections as depleted uranium rounds.
    The production lines for rifled 120 mm ammunition in the UK have been closed for some years so existing stocks of ammunition for the L30A1 are finite. Challenger 2 fitted with 120 mm smoothbore gun for trials A single Challenger 2 was fitted with the L55 and underwent trials in January 2006. The smoothbore gun was the same length as the L30A1 and was fitted with the rifled gun’s cradle, thermal sleeve, bore evacuator and muzzle reference system.
    Early trials apparently revealed that the German tungsten DM53 round was more effective than the depleted uranium CHARM 3. The ammunition storage and handling arrangements had to be changed to cater for the single-piece smoothbore rounds, instead of the separate-loading rifled rounds. Other improvements were also considered, including a regenerative NBC protection system.

    HAAIP update:
    Updates to the automotive components of Challenger 2 are being undertaken as part of the ongoing Heavy Armour Automotive Improvement Programme (HAAIP), which is expected to continue until 2031, and expected to align with the Challenger 3 programme. The HAAIP programme “will be made to existing in-service Challenger 2 tanks to increase their mobility and stability, both of which are critical to providing the foundation for the new turret and systems that will upgrade the vehicle to a Challenger 3.”

    The overall scope of HAAIP includes:
    – Upgraded CV12-9A engines for Challenger 3 and CRARRV
    – Third Generation Hydrogas Suspension
    – New Hydraulic Track Tensioners (HTT) with inline accumulators
    – Improved Electric Cold Start System (Intake Manifold Heater)
    – Unspecified new components fitted to improve the transmissions
    – New Main Engine Air Intake Filters
    – Improved Main Engine/Transmission Cooling; fitting new high efficiency radiators and fans.

    TES Megatron update:
    The Megatron update, or Challenger 2 TES Megatron, was first unveiled in 2013 at the DVD Defense Expo in Millbrook. Another example of Megatron’s update was also unveiled in 2016.

    This update includes:
    – Adding reactive and passive armors to deal with new types of threats on the battlefield, which allows to equip Megatron with additional types of armor depending on the type of threats.
    – Upgrading the L30A1 gun to be able to fire more of the existing NATO ammunitions.
    – Installation of a remote control weapons system called Enforcer.
    – Using of a new armor that is a combination of Dorchester’s standard composite armor, reactive, passive and rod armor and Chobham armor.

    Megatron has a maximum weight of 74,840 kg with TES armor and 62,500 kg in standard configuration.

    Enforcer Remote Control Weapons System

    Black Night update:
    In 2018, following the update program of the Challenger-2 tank, an update called Black Night was implemented, which practically became a different product. Two examples of this update have been seen to date, differing only in “gun type”. One example uses the same L30A1 gun and another example uses the L55 gun that was previously coordinated with this tank in the CLIP update.

    Features announced for the Black Night update by BAE include:
    – Active Protection System – Systems allow the tank to detect incoming anti-tank missiles or armour penetrating rounds and automatically launches a counter-explosive to neutralise the threat.
    – Laser Warning System – When targeted by enemy weapon systems, the tank can identify the source of the threat then automatically slew the gun to point at that source, making it quicker for the crew to counter-fire.
    – Regenerative braking – The tank has been made more energy efficient by using less energy-hungry kit and installing regenerative braking in the turret, which generates power when the gun slows down into position.
    – Thermal Imaging Technology – Front and rear infrared cameras (similar to those used in television programmes such as Planet Earth II) provide extremely sharp night imagery, helping troops identify potential threats and move undetected in hostile situations, while also shaving valuable seconds off reaction times.
    – Accelerated fightability – New equipment controlling tank’s weaponry is faster, meaning the crew can identify an enemy, target and engage more quickly.

    CSP / LEP update:
    In 2005, the British MoD recognised a need for a Capability Sustainment Programme (CSP) to extend the service life of the Challenger 2 into the mid-2030s and upgrade its mobility, lethality and survivability. The CSP was planned to be complete by 2020 and was to combine all the upgrades from CLIP, including the fitting of a 120 mm smoothbore gun.
    By 2014, the CSP programme had been replaced by the Life Extension Programme (LEP) which shared a similar scope of replacing obsolete components and extending the tank’s service life from 2025 to 2035, however the 120 mm smoothbore gun had seemingly been abandoned.

    In 2015, the British Army provided an insight into the scope of the LEP, dividing it into four key areas, namely:
    – Surveillance and target acquisition: Upgrades to the commander’s primary sight and gunner’s primary sight, as well as the replacement of the thermal observation and gunnery sights (TOGS) with third-generation thermal imaging.
    – Weapon control system: Upgrades to the fire control computer, fire control panel and gun processing unit.
    – Mobility: Upgrades including third-generation hydrogas suspension, improved air filtration, CV-12 common rail fuel injection, transmission and cooling.
    – Electronic architecture: Upgrades to the gunner’s control handles, video distribution architecture, generic vehicle architecture compliant interfaces, increased onboard processing and improved human machine interface.

    Challenger 3 update:
    This update was implemented to consolidate the experience of all the upgrades made on the Challenger-2 tank and was unveiled in 2021. The upgrades that were first done on the Megatron and then on the Black Night continued on the Challenger 3. In order to increase the survivability of tank in the battlefield, two models of active protection systems (APS) have been used on this tank: MUSS (MUltifunctional Self protection System) and Rheinmetall’s ROSY Rapid Obscurant System.

    MUltifunctional Self protection System – click to view full size

    With the introduction of Megatron in 2016 and Black Knight in 2018, a proposal design was also unveiled by Rheinmetall in 2019. The design included the development of a completely new turret with fully digital electronic architecture, day and night sights for the commander and gunner, and a Rheinmetall L55 120 mm smoothbore gun. Whilst a more substantial upgrade than Black Night, the turret was developed on Rheinmetall’s initiative and was not funded by the UK MoD.
    In June 2019, BAE Systems and Rheinmetall formed a joint venture company, based in the UK, named Rheinmetall BAE Systems Land (RBSL). Despite the merger, the company was still expected to present two separate proposals for the LEP contract, however, at DSEI 2019, RBSL instead opted to only showcase the Rheinmetall proposal.

    This upgrade includes a new turret with a fully digital electronic architecture, a Thales Orion day and night sight for the commander, and a Thales DGNS T3 day and night sights for the gunner, along with the use of a 120mm Rheinmetall L55A1 gun. The turret architecture also allows for an active protection system or an Improvised Explosive Electronic Warfare system to be installed in the future if required by the user.

    Click to view full size

    In 2020, the UK MoD argued against buying a new main battle tank from overseas instead of pursuing the Challenger 2 LEP, stating that an upgraded Challenger 2 would be “comparable – and in certain areas superior” to a Leopard 2 or Abrams.

    In 2021, the UK MoD published its long-awaited command paper, Defence in a Competitive Age, which confirmed the British Army’s plans to upgrade 148 Challenger 2 tanks and designate them Challenger 3. The UK MoD confirmed the contract with RBSL had been signed, valued at £800 million (US$1 billion), on 7 May 2021. Rheinmetall’s more extensive upgrade proposal, including the new 120 mm smoothbore gun, had been accepted. The initial operating capability for the upgraded tanks is expected by 2027, with full operation capability expected to be declared by 2030.

    Infographic published by RBSL comparing Challenger 2 and Challenger 3 tanks

    Types of tanks and combat vehicles based on Challenger-2 chassis:

    Trojan combat engineering armored vehicle:
    The Trojan Armoured Vehicle Royal Engineers is a combat engineering vehicle designed as a replacement for the Chieftain AVRE (ChAVRE). It uses the Challenger 2 chassis, and carries an articulated excavator arm, a dozer blade, and attachment rails for fascines. Entering service in 2007, 33 were produced.

    Trojan combat engineering armored vehicle:

    Challenger 2 Driver Training Tank:
    The Challenger 2 Driver Training Tank (DTT) is based on the Challenger 2 hull. The turret has been replaced with a fixed weighted superstructure to accommodate an instructor and up to 4 trainees. The design is similar to the Challenger 1 derived Challenger Training Tank (CTT). Weighting the superstructure replicates the weight (and therefore also the driving characteristics) of the standard tank in operational service.

    Challenger 2 Driver Training Tank

    Titan armoured bridge layer:
    The Titan armoured bridge layer is based on aspects of the Challenger 2 running gear and replaced the Chieftain Armoured Vehicle Launched Bridge (ChAVLB). The Titan came into service in 2006 with the Royal Engineers, with 33 in service. Titan can carry a single 26-metre-long bridge or two 12-metre-long bridges. It can also be fitted with a bulldozer blade.

    Titan armoured bridge layer

    Challenger 2E:
    Challenger 2E The Challenger 2E is an export version of the tank. It has a new integrated weapon control and battlefield management system, which includes a gyrostabilised panoramic SAGEM MVS 580-day/thermal sight for the commander and SAGEM SAVAN 15 gyrostabilised day/thermal sight for the gunner, both with eye-safe laser rangefinder.
    This allows hunter/killer operations with a common engagement sequence. An optional servo-controlled overhead weapons platform can be slaved to the commander’s sight to allow operation independent from the turret.
    The power pack has been replaced by a new 1,500 hp (1,100 kW) EuroPowerPack with a transversely mounted MTU MT883 diesel engine coupled to Renk HSWL 295TM automatic transmission.
    The increase in both vehicle performance and durability is significant. The smaller volume but more powerful EuroPowerPack additionally incorporates as standard a cooling system and air intake filtration system proved in desert use.
    The free space in the hull is available for ammunition stowage or for fuel, increasing the vehicle’s range to 550 km (340 mi). This power pack was previously installed on the French Leclerc tanks delivered to the UAE as well as the recovery tank version of the Leclerc in service with the French Army. Further developed versions of the EuroPowerPack have more recently been installed in the latest serial produced Korean K2 Black Panther tank.
    BAES announced in 2005 that development and export marketing of 2E would stop. This has been linked by the media to the failure of the 2E to be selected for the Hellenic Army in 2002, a competition won by the Leopard 2.

    Challenger Armoured Repair and Recovery Vehicle:
    The Challenger Armoured Repair and Recovery Vehicle (CRARRV) is an armoured recovery vehicle based on the Challenger 1 hull, designed to repair and recover damaged tanks on the battlefield.
    Ordered in 1985, and delivered between 1988 and 1993, the CRARRV has subsequently been updated to use a Challenger 2 powertrain consisting of a CV12-5C/6C engine with TN54E transmission.
    The British Army ordered 80 vehicles. Four CRARRVs were purchased by Oman to complement their acquisition of Challenger 2 tanks. CRARRVs were first deployed in action in the lead up to the First Gulf War, Operation Granby in 1991. They were subsequently deployed during the 2003 invasion of Iraq, Operation Telic in 2003, alongside standard Challenger 2 MBTs.

    Challenger 2 specifications:
    – Type: Main Battle Tank (MBT)
    – Manufacturer: BAE Systems
    – In service: since 1998
    – Wars: Iraq war, Kosovo war, Bosnian war, Afghanistan war
    – Unit cost: £4,217,000
    – Mass: 64 tons
    – Length: 8.3 m
    – Width: 3.5 m
    – Height: 2.49 m
    – Crew: 4 (commander, gunner, loader–operator, driver)
    – Engine: Perkins CV12-6A V12 diesel, 26.1 L, 1200 bhp (890 kW)
    – Fuel capacity: 1,592 litres
    – Operational range: 550 km on-road, 250 km off-road
    – Speed: 59 km/h on-road, 40 km/h) off-road
    – Origin: UK

    Challenger 2 tank – click to view full size

    Collection of Challenger 2 posters in Russian, Arabic, Persian, Azeri and Kurdish:

    Source:
    Challenger 2
    Challenger 2 Main Battle Tank
    Armour Challenger 2 from SB documentation
    BAE unveils ‘Black Night’ – the first fully-upgraded Challenger 2 tank

    Rifling

  • Infographic: Taliban Border Clashes With Neighboring States Of Afghanistan

    Infographic: Taliban Border Clashes With Neighboring States Of Afghanistan

    The main root cause of the Taliban’s border clashes with Afghanistan’s neighbors is that the Taliban militants possess insufficient know-how regarding international border laws and regulations. More importantly, the Taliban rulers do not make any effort to prevent tensions with their neighbor states!

    Afghanistan is a landlocked country, which does not have any access to free waters. And the prelude to the establishment of stability and security in such a region is cooperation with neighboring states in order to create appropriate condition for economic and political growth along with issues such as security and stability.

    Unfortunately, following five decades of conflict and bloodshed in Afghanistan, the country is still involved in ethnic clashes as well as pursuit of self-interest by powerful individuals and one-dimensional governments. Hence, it can be predicted that the war-torn country has not yet entered a period of stability; so, the second Taliban regime is expected to end up in the fate of previous Afghan governments if it continue the past trend.

    The Taliban militants’ border clashes created an environment of insecurity, which extended smuggling and strengthened terrorist groups’ activities in Afghanistan’s border lines more than ever, and this trend is expected to accelerate the Taliban’s downfall. In such circumstances, coordination and the way that Afghanistan’s neighboring states face the Taliban rulers, would play a significant role…

    The Taliban militants embarked on at least 26 border clashes with Afghanistan’s neighboring states since their takeover of the war-stricken country in 2021. Of the total number of border clashes, some 11 cases occurred on the border with Iran, 11 others on joint border with Pakistan, two conflicts on the border with Tajikistan, two others on joint borderline with Uzbekistan and the last one on the border with Turkmenistan.

    The details of these conflicts are as follows:

    1- Conflict with Iran, Shaghalak area in Hirmand district in Sistan and Baluchistan province, December 1, 2021

    2- Conflict with Pakistan, Sirkanay district in Kunar province, December 24, 2021

    3- Conflict with Turkmenistan, Khamab district in Jowzjan province, January 4, 2022

    4- Conflict with Pakistan, Spin Buldak-Chaman border crossing in Kandahar province, February 24, 2022

    5- Clash with Iran, Darbishak area in Kang district, Nimroz province, March 7, 2022

    6- Conflict with Iran, Islam Qala border crossing in Kahsan district of Herat province, April 23, 2022

    7- Conflict with Uzbekistan, Hairatan border crossing in Balkh province, May 3, 2022

    8- Conflict with Tajikistan, Shirkhan border crossing in Imam Sahib district of Kunduz province, May 15, 2022

    9- Conflict with Iran, the border of Hirmand district in the north of Sistan and Baluchistan province, June 29, 2022

    10- Conflict with Iran, the border of Kang district in Nimroz province, July 12, 2022

    11- Conflict with Iran, the border of Doust Mohammad region located in Hirmand district in Sistan and Baluchistan province, July 31, 2022

    12- Clash with Uzbekistan, Hairatan border crossing and Shortepe district in Balkh province, August 22, 2022

    13- Conflict with Pakistan, border village of Zanjir in Shamulzayi district in Zabul province, September 1, 2022

    14- Conflict with Iran, the Abrisham Bridge in Sistan and Baluchistan province, October 17, 2022

    15- Conflict with Pakistan, Spin Buldak-Chaman border crossing in Kandahar province, November 13, 2022

    16- Conflict with Pakistan, border areas of Paktia province, November 2022

    17- Conflict with Pakistan, border areas of Paktia province, November 2022

    18- Conflict with Pakistan, Kharlachi border village located in Dand Aw Patan district in Paktia province, November 19, 2022

    19- Conflict with Pakistan, Kharlachi border village located in Dand Aw Patan district in Paktia province, November 20, 2022

    20- Conflict with Iran, Sasuli border village in Sistan and Baluchistan province, December 7, 2022

    21- Conflict with Pakistan, Shiro Obo village in Spin Buldak district in Kandahar province, December 11, 2022

    22- Conflict with Pakistan, Shiro Obo village in Spin Buldak district in Kandahar province, December 15, 2022

    23- Clash with Pakistan, Torkham border crossing in Nangarhar province, February 20, 2023

    24- Clash with Iran, Gudar Abdurrahman area near Milak border crossing in Sistan and Baluchistan province, March 5, 2023

    25- Conflict with Iran, the border of Sasuli village in Sistan and Baluchistan province, May 14, 2023

    26- Conflict with Iran, the border of Makaki, Sasuli and Hatam villages in Sistan and Baluchistan province, May 27, 2023

    Click to view full size
  • Military Knowledge: Fattah Hypersonic Ballistic Missile

    Military Knowledge: Fattah Hypersonic Ballistic Missile

    Most ballistic missiles have the ability to reach speeds higher than 5 Mach, but they are not considered hypersonic because they follow a ballistic path and have bullet-like movement. In general, it is easy for air defense systems to detect a ballistic trajectory at any speed. But maneuvering in the final phase is an important characteristic that creates a fundamental difference in missile classification. A hypersonic ballistic missile is a ballistic missile that has the ability to maneuver before hitting its target while maintaining a speed of more than 5 Mach.

    For example, the Khorramshahr missile has a speed of near 16 Mach in the intermediate phase outside the atmosphere and a speed of near 8 Mach when entering the atmosphere, but it lands directly on the target like a bullet, so it is just a ballistic missile.

    Read more: Military Knowledge: Khorramshahr-4 Ballistic Missile

    A review of the Fattah missile shows that this missile has a lot of similarity to the Kheibar Shekan missile in appearance. The tail fins and warhead have a lot of similarity to each other. The similarity is such that even the front ramp of the warhead control fins is the same. Therefore, it is assumed that the diameter of the Fattah and Kheibar Shekan missiles are also the same.

    Read more: Military Knowledge: Khaybar Shekan Ballistic Missile

    Given the great similarity between the two missiles and also the software reviews that were done, it can be assumed that the two missiles have the same diameter, equal to 80 centimeters. Also, considering that the length of the warhead has been announced as 3.6 meters, with a software review of the missile, the total length of the missile can be considered as 11.5 meters.

    Estimation of the length of the Fattah missile

    Another similarity between these two missiles is their range. In addition to the visual similarity of the Kheibar Shekan and Fattah missiles, the range of these two missiles is also similar to each other. The Kheibar Shekan has a range of 1450 kilometers and Fattah has a range of 1400 kilometers.

    The missile body, along with the end fins and the fins on the cap, is entirely composite (carbon fiber). The body color is also of the radar wave absorbing type, which helps increase missile stealth. The use of warhead fins is when the missile comes down from an altitude of 30 kilometers and enters the atmosphere. Because at higher altitudes it has no effect on warhead maneuvering. This is useful for maneuvering near the target.

    The warhead fins of Fattah missile

    As it is clear, the aerodynamic shape of the Fattah and Kheibar Shekan warheads are the same, but due to the addition of an engine and fuel in the final section, it has been tried to maintain the aerodynamics of the warhead and reduce drag by making the missile tip longer.

    Comparison of warheads of Fattah and Kheibar Shekan missiles

    As mentioned, the warhead has propulsion with the ability of change thrust vector, and the presence of this engine allows the warhead to maintain its speed at a speed of more than Mach 5 when maneuvering near the target. When the warhead enters the atmosphere, its speed is greatly reduced due to the strong air resistance, and by performing heavy maneuvers with the help of its fins, its speed is reduced again; But with the warhead engine, it is possible to increase the speed to more than Mach 5. Also, with the thrust vector nozzle, it is possible to perform heavier maneuvers.
    It should be noted that this engine can be turned on when the warhead is separated from the missile, which increases the flight height of the warhead and greatly increases its range.

    Fattah warhead engine with thrust vector nozzle

    The next issue is how the Fattah missile works and whether it is hypersonic or not.
    This missile has a warhead with the ability to change thrust vector, which allows it to maneuver from the time the warhead separates from the body at an altitude of 300 kilometers above the ground. So after separating from the body, the Fattah missile’s warhead maneuvers with a low or depressed trajectory to escape anti-ballistic missile systems and changes or adjusts its path several times during flight.
    It should be noted that Fattah does not need much maneuvering outside the atmosphere; in addition to performing regular maneuvers to adjust its path, this missile has the ability to change its ballistic path shape. The next point is the ability to maneuver from a distance of 100 kilometers before hitting the target, which also puts it in the category of MaRV ballistic missiles.

    So, Fattah follows a non-ballistic path both outside the atmosphere and when it is in Earth’s atmosphere and near its target. However, it should be noted that the mentioned capabilities alone do not make Fattah hypersonic. What puts the Fattah missile in the category of hypersonic ballistic missiles is that in addition to the mentioned capabilities, the missile’s speed at the moment of impact on the target is also higher than 5 Mach. This has been made possible by keeping the engine on for 50 seconds at different stages of flight to maintain warhead speed. As a result, by combining all of these features, we can consider Fattah as a hypersonic ballistic missile.

    Read more: Iran Unveils First Home-Grown Hypersonic Missile ‘Fattah’ (Image)

    Fattah missile specifications:
    Length: ~ 11.5 meters
    Diameter: ~ 80 cm
    Weight: 4000 to 4600 kg
    Warhead length: 3.6 meters
    Warhead weight: ~ 1000 kg
    Weight of explosives: ~ 500 kg
    Speed: more than Mach 13
    Range: 1400 km (increasable)
    Fuel: solid compound
    Flight trajectories: ballistic (maneuverability from the mid-phase)
    Origin: Iran

    Fattah hypersonic missile – click to view full size

    “Fattah hypersonic ballistic missile” posters collection in Persian, Russian, Arabic, Azeri, Kurdish and Hebrew:

  • Military Knowledge: Karrar Drone

    Military Knowledge: Karrar Drone

    Karrar multirole drone is the first Iranian drone that can carry and use a wide range of weapons, including air-to-air and air-to-surface missiles, using a single platform. This UAV is produced by the Iran Aircraft Manufacturing Industrial Company (HESA), which is under the Ministry of Defense, and has been used by various departments of the Iranian Armed Forces.

    History:
    A maquette of Karrar UAV was first seen in 2004 at a military equipment exhibition, and later in 2010, it was unveiled under the name “Karrar Bomber Drone” during a ceremony attended by the then president of Iran. The exact date of the start of the production and use of the Karrar is not known and has not been officially announced, but the year 2010 can be considered as the year of its entry into service.

    From the very beginning of its unveiling, the Karrar UAV carried a Mark 82 unguided bomb weighing 500 pounds (226.79 kg), and it was said that this UAV could also carry a cruise missile. In 2013, the news of using the Kosar cruise missile on the Karrar UAV was published, which increased the capabilities of the Karrar due to Kosar’s 100 kg weight and 25 km range.

    In 2014, Mersad air defense system was tested using Karrar UAV. In this test, Karrar was used as a target drone for testing the air defense system and train the air-defense crews.

    The different introduction of the Karrar UAV in 2018 with the name “Karrar-4 Interceptor” which carried the Shahab Thaqeb missile showed that this drone has generations and each of these generations is defined based on the type of mission; But this generation was never stated clearly.

    At the unveiling ceremony of Yasin, Balaban and Qaem 1, 5 and 9 bombs in 2019, Amir Hatami, the then Minister of Defense, announced that the Yasin glide bomb can be released from the Karrar drone. Yasin glide bomb is the result of adding a wing and guidance kit to the Mark 82 bomb, which was previously used by the Karrar drone.

    Design:
    The Karrar multirole drone is a derivative of the American 1970s-era Beechcraft MQM-107 Streaker target drone. The MQM-107A drone was purchased before the Iranian Islamic Revolution to be used as a target drone in defense exercises. In fact, in terms of appearance, the Karrar UAV is more similar to the Skua UAV made in South Africa. Nevertheless, in general, Karrar drone is very different from Skua and MQM-107 drones.

    To produce Karrar drone, it was first necessary to redesign the engine used in the American version. The MQM-107A drone delivered to Iran used the Teledyne CAE J402 engine, which was considered an old engine and was no longer used in America. In another model of this UAV, which is known by the suffix B, that is, the MQM-107B model, the French microturbo TRI 60-2 074 turbojet engine is used. So, Iran designed and produced the Toloue-4 jet engine based on the same French TRI 60 engine that was used on MQM-107B model. The French TRI 60 engine has many variants, but the TRI 60-2 074 engine is most similar to the Toloue-4 turbojet engine.
    The TRI 60-2 074 engine is a triaxial microjet with three axial compressors, a combustion chamber and a turbine stage, which has a diameter of 33 cm, a length of 124 cm, and a weight of 61 kg, and produces a maximum force of 3.4 kilonewtons (KN). The Toloue-4 jet engine, which is the Iranian indigenously produced variant of this engine, is also a triaxial turbojet engine with three axial compressors, a combustion chamber and a turbine stage, and has a diameter of 33 cm, length of 130 cm, weight of 55 kg, and a maximum power of 3450 newtons (N). The Toloue-4 engine is slightly longer and weighs less than its French counterpart.

    The Toloue-4 turbojet engine is also used in the Noor cruise missile and the Ya-Ali cruise missile.

    Considering the repeated comparison of the Karrar drone with the American MQM-107 drone, we will discuss the differences in appearance between this design and its American model.

    The first difference is in the tail fins, which are similar to the design of Skua drone made in South Africa and not similar to the American model. The BQM-126A UAV is another UAV that is similar to the Karrar in terms of its tail fins, but the wings and the tips of the tail fins in the BQM-126A and the Karrar are completely different, and in this sense, it is more similar to the South African model.

    The second difference is the location of the drone engine, which is not similar to any of the mentioned drones. In the American and African variant, the engine is placed under its body, but in the Iranian variant, this engine is placed along the body and at its end. The reason for this special design is the use of a hardpoint under the belly to carry 250 kg of weapons.

    The third difference and also a similarity is the location of the main wing. In the Iranian variant, the main wing is attached under the body. In the African variant, the wings are located on the body, and in the American variant also the wings are located under the body.

    It cannot be denied that the Karrar is modeled after another drone, but the design of the American target drone and the Iranian Karrar drone are both derived from the idea of simplifying the manufacture of weapons and making them less expensive, which allows for mass and cheap production.

    Variants:
    According to the way of introducing the Karrar multipurpose drone, it seems that this drone has four generations. Many sources stated that there have been changes in the dimensions, but due to the fact that not all the characteristics have been announced in each generation and the lack of sufficient documents, this issue cannot be denied or confirmed.
    First generation: Karrar bomber drone
    At the time of its unveiling in 2010, the Karrar drone carried the title of bomber. The reason for this name was the use of Karrar as a drone that carried and used unguided air-to-ground bombs such as Mark-82 bomb. The published test video of Karar drone show the high accuracy of this UAV when using a free fall bomb.
    Second generation:
    No reliable information has been published about the second generation of the Karrar UAV, but it seems that this variant was launched for a completely different mission, which pushed the generation to the sidelines at the time of unveiling. For this variant, it has a range of 1000 km and a maximum speed of 900 km/h with the possibility of carrying 226 kg of explosives.
    Third generation:
    This variant has a length of 3.75, a wingspan of 3.1 and a height of 1.5 meters, and a maximum take-off weight of 750 kg with the ability to carry a cargo of 250 kg. Other features of Karrar-3 UAV include a flight ceiling of 35,000 feet equivalent to 10,670 meters, max speed of 700 km/h, a cruising speed of 650 km/h, and a flight duration of 1 hour and 15 minutes. In this variant, Toloue 4 jet engine with JP-4 fuel is used and the body is mainly made of aluminum.
    Fourth generation: Karar interceptor drone
    This variant of drone was first seen carrying a Shahab Thaqeb missile in 2018, which was later named Karrar 4 Interceptor. This UAV is used as one of the complementary components in offensive and defensive systems, and due to the possibility of firing it from the back of the trailer, it can be launched from near the borders towards the hostile aircraft to engage with it.
    The interceptor variant has been a regular part of many Iranian military exercises. This drone was able to intercept a P-8 reconnaissance aircraft that was trying to collect information from a military exercise in 2022. The P-8 forced to retreat from the training area.

    It should be noted that for all Karrar models, the ability to fly up to a height of 40,000 feet, equivalent to 12.2 km, and a final speed of 900 km/h have been stated. Karrar UAVs have a range of up to 200 km (Karar-3) when flying with direct communication with the ground station, and between 800 and 1000 km when flying automatically without the need for constant communication with the station.

    A video of “Karrar Interceptor drone” that intercepts another Karrar drone

    Engine:
    As we said earlier, the Karrar drone uses Toloue 4 turbojet engine in most of the variants. However, in 2022, a variant of Karrar equipped with Toloue-5 turbojet engine was used to test Sayyad 4B missile for the Bavar 373 air defense system. Karrar drone with Toloue 5 turbojet engine was able to reach a height of 43000 feet equivalent to 13.1 km and a speed of 733 km/h at that height.

    Launching method:
    The Karrar UAV is launched with the Rocket Assist Take-Off (RATO) mechanism and takes help from the booster to get the initial acceleration. With this booster and its engine, Karrar can fly with a maximum weight of 750 kg, of which 250 kg is weapons. In order to make it possible to use this drone tactically and more widely, a carrier vehicle was designed that carries three drones in ready-to-launch state. The carrier vehicle tent also folds up easily so that it is possible to quickly carry out the operation and then move away from the operation area. This combination greatly increases the survivability on the battlefield for Karrar and its carrier vehicle.

    It should be noted that the Karrar does not need a runway for landing, and a parachute is used to recover it.

    Sensors:
    It seems that Karrar did not have a front camera in its prototypes and used only one camera under the body that is fixed to see the ground and targets. Later, with the introduction of the “Karrar Interceptor”, it was revealed that this drone has a camera in its nose that can detect the target at a distance of 30 km and lock onto the target at a distance of 3 km. The Karrar Interceptor was actually an aid to the country’s air defense system to fill the void of an interceptor fighter jet and also to increase the response time by being constantly present at the border areas.
    The front camera of this UAV has 360-degree surveillance capabilities and increases the ability to detect both aerial and ground targets.

    A new version of the Karrar was seen at the unveiling ceremony of the Army’s Eagle 44 underground base, which is equipped with a front camera and gives the UAV a wider field of vision.

    Guidance system:
    Karrar’s guidance for accurate hitting of Mark 82 unguided free-fall bombs can be related to the existence of a type of guidance such as Constantly Computed Impact Point (CCIP). In this method, all factors such as wind, speed, target’s movement, gravity, projectile launch velocity, projectile drag and other factors that can affect targeting are calculated and provided to the main computer. The set of information and calculations is finally provided to the operator, which allows the drone to release the bomb accurately. So, the set of these factors, which is actually an inertial guidance, along with the presence of the underbelly camera and GPS, allows this drone to accurately hit the free fall bomb.

    Launching of MK-82 unguided bomb by Karar UAV and accurate hitting of the bomb on the target

    Radar equipment:
    In the first prototypes of Karrar and in its production workshop, a variant of the Karrar UAV was seen, which seemed to contain some kind of radar. Also, a type of Karrar carrying two Kosar bombs, each mounted on one wing, can be seen, but such a combat combination has never been seen after that.
    Another variant of Karrar has also been seen in the exercises, which seems to carry a special type of radar. It is not clear if this radar is for observing the environment or if it is a electronic warfare system to disrupt the enemy’s air defense systems.

    The third-generation Karrar drone can be guided by the ground station up to 200 km. Probably, this number has increased to 300 km in the next generations. However, it is still not possible to guide the Karrar “suicide version”, at it’s maximum range which is 1000 km.
    But what is the solution for guiding the Karrar in a range of 1000 km? The only way to guide Karrar drone in a range of 1000 km is to guide it like a cruise missile. This variant most likely has some kind of terrain radar and TERCOM (terrain contour matching) system, which provides the possibility of automatic guidance similar to a cruise missile. It is also stated that there is a possibility of changing the target for the Karrar suicide drone, which seems logical considering the presence of GPS and the possibility of receiving GPS coordinates.

    Karrar armament:
    From the first day of its introduction, the Karrar drone was seen with Mark 82 unguided bomb. In subsequent variants, this drone has been able to carry the Kosar anti-ship missile weighing 100 kg. In a video at an unveiling ceremony, it was revealed that this drone can carry weapons such as Simorgh cluster bomb, Yasin glide bomb (the same Mark 82 bomb with guidance kit), Balaban glide bomb, 500 pound laser guided bomb (similar to GBU-12B), Azarakhsh air-to-air and anti-tank missile and Shafagh (enhanced) missile. Of course, the Karrar drone has the capability of carrying bombs and other missiles weighing up to 250 kg, which may not be installed on it or may be installed on Karrar in the future.

    In addition to carrying all kinds of bombs and missiles, the Karrar drone can also carry rapid-firing guns, which have been offered in two types until now. The first gun is Akhgar; Akhgar gatling is a six-barreled gatling with 7.62 mm caliber and 45 kg weight, which was originally developed for helicopters. The second is the installation of three 7.62 mm light guns in one package and in the nose of Karrar drone. The operational level of these versions is not known, but it is possible to hunt drones or low-speed air targets with these guns.

    In addition to mentioned weapons, an air-launched torpedo has also been installed on the Karrar drone. The Mark 46 torpedo installed on the Karrar is a light air-launched torpedo with a weight of 230 kg, which can destroy all types of submarine targets with a 43.9 kg warhead and a range of 11 km.

    Due to the use of wide range of weapons that Karrar can carry, it is capable of conducting a various range of missions; Therefore, the Karrar drone can be considered and named as the first multirole drone in the world!

    Mark 46 torpedo next to Karrar drone

    Karrar drone missions:
    Air-to-ground (bombing)
    Air-to-air (interception)
    Air-to-surface (anti-ship)
    Anti-submarine
    Target drone
    Suicide drone

    Karrar drone specifications:
    Role: multirole drone
    Length: 3.75 meters
    Wingspan: 3.1 meters
    Height: 1.5 meters
    Maximum take-off weight: 750 kg
    Weight: 500 kg
    Weapons payload: up to 250 kg
    Weight of warhead in the suicide version: 226 kg of TNT
    Engine: Toloue-4 or Toloue-5 turbojet
    Cruise speed: 700 km/h
    Maximum speed: 900 km/h
    Maximum range: 1000 km
    Combat range: up to 500 km
    Flight ceiling: 10700 to 13100 meters
    Origin: Iran

    Karrar multirole drone – click to view full size

    More images of Karrar drone:

    The collection of Karrar UAV posters in Russian, Hebrew, Arabic, Azeri, Kurdish Farsi:

    Source:
    TRI60-2/074
    کرار (پهپاد)

    Constantly computed impact point

  • Military Knowledge: Khorramshahr-4 Ballistic Missile

    Military Knowledge: Khorramshahr-4 Ballistic Missile

    On May 25 and on the occasion of the anniversary of the liberation of Khorramshahr city in the Iraq-Iran war, the Khorramshahr 4 surface-to-surface ballistic missile with the operational name of “Khaybar” was unveiled in the presence of Mohammad Reza Ashtiani, Minister of Defense and Armed Forces Logistics of Iran.

    Brigadier General Mohammad Reza Ashtiani, called the Khorramshahr-4 missile a strategic pinpoint ballistic missile with radar evasion capability. In some parts of his speech, he said the message of the unveiling of the Khorramshahr-4 missile to Iran’s friends is helping peace and stability in the region and providing comprehensive support to countries that are on the path of fighting against the arrogance system.

    Khorramshahr-4 missile is considered to be the newest variant of the Khorramshahr missile series, which has undergone major changes in various parts. Among the most important of these changes, we can point out the use of hypergolic fuel and a new engine. Khorramshahr-4 is equipped with Arvand engine, one of the most advanced Iranian liquid fuel engines, in order to use hypergallic fuel.

    A hypergolic propellant is a rocket propellant combination used in a rocket engine, whose components spontaneously ignite when they come into contact with each other. The main advantages of hypergolic propellants are that they can be stored as liquids at room temperature and that engines which are powered by them are easy to ignite reliably and repeatedly. Hypergolically-fueled rocket engines are usually simple and reliable because they need no ignition system. As hypergolic rockets do not need an ignition system, they can fire any number of times by simply opening and closing the propellant valves until the propellants are exhausted and are therefore uniquely suited for spacecraft maneuvering.[source]

    The launch moment of Khorramshahr-4 ballistic missile

    Another feature of this missile is the ability to store fuel inside the Khorramshahr-4 missile for several years. Using this ability, it is possible to inject fuel into the rocket and keep it in storage for several years. For this reason, the rocket is always ready to fire and there is no need to spend long time for refueling again. Therefore, the preparation time and entering the launch position has reached less than 12 minutes.

    According to statements and information provided by military sources, the range of Khorramshahr-4 missile is up to 2000 km and its warhead is 1500 kg. But based on some facts, it seems that the range of the missile is intentionally announced lower than its actual range. Experts believe that the real range of this missile is up to 4000 km.

    In general, the warhead of this missile with a length of 4 meters and a weight of 1,500 kg is one of the largest and heaviest warheads produced by Iran, which is also resistant to electronic warfare. It should be noted that out of this 1,500 kg, about 1,000 kg are explosives and 500 kg are related to engine, guidance, equipment, etc. The warhead of this missile can be single and heavy or in the form of several lighter warheads, and it also uses various warheads such as thermobaric warheads.
    The point here is that in this warhead, guiding micromotors are used to control and adjust its trajectory outside the Earth’s atmosphere. For example, by reducing the weight of the warhead by half and increasing the amount of fuel, and with the use of guiding micromotors in the mid-phase in exoatmosphere, the range of this missile can easily be increased up to twice the declared range!

    Review of the performance of launch, guidance and control in the mid-phase outside the atmosphere in Khorramshahr-4 missile

    The speed of Khorramshahr-4 is Mach 16 outside the atmosphere and Mach 8 inside the atmosphere before hitting the target, and the circular probable error (CEP) of 10 to 30 meters is also expected for this missile. The speed of Mach 16 outside the earth’s atmosphere and the use of guidance engines to control and adjust the trajectory of the warhead makes it very hard for the outer space missile systems to intercept and destroy this missile. Also, the speed of Mach 8 in the final phase in the atmosphere is a very good speed, making it very difficult to detect, track and intercept by existing anti-missile systems.

    One day after the unveiling of the Khorramshahr 4 missile, Deputy Defense Minister General Farahi provided more information about this missile in a television interview. According to him, unlike previously built missiles whose guidance and control system was in the atmosphere and there was a possibility of jamming and electronic interference by the enemy, guidance and control of Khorramshahr 4 is done outside the atmosphere, and its guidance and control systems are not active inside the atmosphere, and therefore, electronic warfare systems have no effect on the Khorramshahr 4 missile.

    Also, in addition to this feature, this missile uses a cyber defense system and using artificial intelligence with the necessary maneuverability, it can deceive the enemy’s defense systems and escape from the enemy’s missiles. He stated the circle of error (CEP) of Khorramshahr 4 missile up to 30 meters at a distance of 2000 km, and the durability of the fuel inside the missile was also stated to be a maximum of 3 years.

    Among the other capabilities of Khorramshahr 4 is the ability to use radar and optical seeker individually or simultaneously with the use of artificial intelligence to target moving sea and land targets, which is installed on the missile depending on the type of mission and target.

    MIRV and MRV capabilities on Khorramshahr-4 warhead

    Khorramshahr-4 missile can carry multiple warheads inside its main warhead and each warhead can hit an independent target.

    Multiple independently targetable reentry vehicle (MIRV) capability refers to a warhead that carries several other warheads inside, and each of these warheads can target an independent and different target. There is another type of warheads called multiple reentry vehicle (MRV), which is also capable of carrying several warheads, but the warheads do not have the ability to target independently, and all of them hit the target in a certain range and are unguided.

    Currently, the US, UK, France, Russia, China and India have claimed to have MIRV missile systems. Pakistan and the Israeli regime are also suspected of developing and possessing MIRV missile systems.

    In 1970, the United States presented this capability to the world for the first time with the LGM-30G Minuteman III missile. Today, Iran has also achieved this ability and has used it in the new generation of Khorramshahr missiles.

    Khorramshahr-2 missile uses a warhead with MRV capability. This type of warhead, carrying a large number of rockets and bombs, is very suitable for targeting various targets such as runaways, barracks and enemy gatherings. But Khorramshahr-4 missile has gone one step further and has achieved MIRV capability. This feature is very suitable for attacking fixed and predetermined targets.

    The main difference between the Khorramshahr-4 missile and the Minuteman III missile is the accuracy and type of munition. The American missile is designed to carry several nuclear warheads with a power of 170 kilotons of TNT and does not need pinpointing accuracy, because nuclear warheads have large explosions, and even several kilometers of error is not important for these type of missiles. However, the Khorramshahr-4 missile has been developed to carry a conventional warhead, and for this reason, each warhead must have high accuracy.

    Khorramshahr 4 (Khaybar) missile will further boost the offensive and defensive capabilities of Islamic Republic of Iran. The country has been working nonstop to develop its missile capabilities in order to deal with increasing threats from the United States and the Israel regime. Tehran’s large missile program achieved a number of breakthroughs in the last few years, despite facing strict sanctions and even sabotage.

    Khorramshahr 4 missile specifications:
    Length: ~ 13 meters
    Diameter: ~ 1.5 meters
    Weight: ~ 30 tons
    Warhead weight: 1500 kg
    Range: 2000 km (unofficial range: up to 4000 km)
    Accuracy: 10 to 30 meters CEP
    Fuel: Hypergolic – single stage
    Speed: Mach 16 outside the atmosphere – Mach 8 inside the atmosphere
    Introduction: May 25, 2023
    Origin: Iran

    Khorramshahr 4 medium-range ballistic missile – click to view in full size

    More iamges of Khorramshahr 4 missile:

    “Khorramshahr 4 (Khaybar) missile” posters collection in Farsi, Russian, Arabic, Azeri, Kurdish and Hebrew:

  • Military Knowledge: Shafagh Air-To-Surface Missile

    Military Knowledge: Shafagh Air-To-Surface Missile

    The first type of Shafagh missile was unveiled and introduced in 2014 during a ceremony in the presence of the then Defense Minister, General Dehghan. This missile (first type) has a range of 8 to 12 km with a penetration rate of 1500 mm in armor. This amount of armor penetration is considered a very good number for an air-to-ground missile. For example, Kornet ME anti-armor missile has a penetration rate of 1300 mm in rolled steel.

    The Shafagh air-to-ground and anti-tank missile in its two prototypes is very similar to the Shahab Sagheb defense missile that was used in the Ya Zahra (S) and Herz-9 air defense systems. Ya Zahra (S) air defense system, which was unveiled in 2013, is modeled after the French Cortal air defense system, which was captured by the Islamic Republic of Iran Army during the Iraq-Iran war. This French air defense system is also produced in China under the name FM90 or HQ7.

    The Shahab Sagheb missile is also made from the R440 missile belonging to the Cortal defense system and is very similar to it.

    Prototypes of Shafagh missile:
    As mentioned, the first Shafagh missile was installed on the Army’s Air Force helicopters in 2014, but before that in 2013, this missile was seen on the Karrar drone. In those years, it was stated that the Shafagh missile has a range of 8 to 10 km and uses an infrared seeker (IIR) in the last stage to attack targets independently; So Shafagh is a fire-and-forget missile capable of penetrating 1 to 1.5 meters of armor. The prototypes of the Shafagh missile have an accuracy of more than 30 cm at a distance of 10 km and have a speed equal to Mach 2 to 2.7 depending on the release height and the distance to the target. The high speed and fire-and-forget ability turned Shafagh missile into a very dangerous one, because the tanks’ defense system has very little reaction time to deal with this missile and the helicopter can quickly move away from the danger zone after firing.

    Another variant of Shafagh missile was unveiled again in 2019 with the same name as Shafagh. The main difference between the two missiles unveiled at a different time interval was the appearance of the front fins. In the first prototype, Shafagh lacked the front fins, but in the secondary prototype, keeping the front fins, the Shafagh missile was completely similar to the Shahab Sagheb missile. Structurally, the maximum range of the second Shafagh missile was increased to 12 km. The Shafagh missile has a maximum speed of Mach 2 to 2.7 in both variants.

    The main difference between the Shafagh missile in the first variant and the Shahab Sagheb missile was the removal of the front fins in the Shafagh missile, but in the secondary variant, the Shafagh missile can be distinguished from its IIR seekers compared to the Shahab Sagheb.

    Safagh 1 and 2 specifications:
    Length: 2.9 meters
    Weight: 60 kg in first variant – 84 kg in second variant
    Maximum speed: Mach 2 to 2.7
    Range: 8 to 12 km in second variant

    The enhanced Shafagh missile:
    The enhanced Shafagh (شفق بهینه) missile was unveiled as a new generation of Shafagh missile in 2022. The new Shafagh missile has been described as a two-stage missile with a 13 kg warhead. This missile with a length of 1.89 meters and a weight of 50 kg is capable of destroying all types of tanks, personnel carriers, concrete trenches, floats and defense infrastructures in all weather conditions, day and night.

    Due to the aerodynamic redesign and probably the solid fuel engine propulsion of the Shafagh missile, its range has increased to 20 km. There is only one other anti-armor missile in this range, and that is the Nimrod 2 missile manufactured by the Israeli Aerospace Industries. Also, in terms of appearance, Shafagh missile can be compared with Nimrod missile. The main difference in appearance between Shafagh and Nimrod is in the middle fin of these two missiles, which in Shafagh is a trapezoid with two slanted sides, and in Nimrod this trapezoid is with one slanted side and one straight side. In terms of length, the Nimrod is one meter longer and its range is up to 36 km.

    The maximum speed of Shafagh (enhanced) missile is 750 meters per second. The probable circular error (CEP) rate of this missile is 20 cm. The Shafagh (enhanced) missile which is a fire-and-forget missile, uses an infrared seeker and laser guidance to accurately target and hit targets.

    Shafagh (enhanced) missile specifications:
    Type: Fire-and-forget
    Introduction: 2022
    Length: 1.89 meters
    Diameter: 20 cm
    Weight: 50 kg
    Warhead weight: 13 kg
    Speed: 750 meters per second
    Range: 20 km
    Guidance: Infrared homing, semi-active laser
    Origin: Iran

    Shafagh air-to-surface missile – Click to view full size

    More images of Shafagh 1 and 2 missiles and the enhanced Shafagh:

    Shafagh air-to-ground missile posters in English, Russian, Arabic, Azeri and Hebrew:

    Source:
    رونمایی از موشک شفق؛ نیش جدید کبراهای ایرانی +عکس
    رونمایی از موشک شفق در روز ارتش
    نصب نسل جدید موشک‌های «شفق» روی بالگردهای هوانیروز ارتش

  • Military Knowledge: Pantsir Short-Range Air Defense System

    Military Knowledge: Pantsir Short-Range Air Defense System

    The Pantsir air defense system uses the general design concept of the Tunguska M1 system, which is a combination of air defense missiles and a 30 mm anti-aircraft gun. The philosophy of this type of design is to fight against helicopters that quickly reduce their height after firing and hide themselves from the radar, for this purpose a combination of defense missiles and anti-aircraft cannons is considered for quick reaction at different distances and in different situations.

    The effectiveness of the AGM-88 HARM anti-radar missiles produced by the United States and the ALARM anti-radar missile produced by the United Kingdom against the old Soviet systems based in Iraq in the First Persian Gulf War showed that long and medium range defense systems need protection. Iraq’s defense systems were destroyed in the first few days of the Desert Storm operation due to anti-radar missile attacks. These missiles destroyed the defense systems’ radars without any obstacles. The operation showed that if a fighter jet equipped with an anti-radar missile gets close enough to fire the missile, the defense system’s radar is likely to be destroyed. Therefore, one of the goals of developing the Pantsir system was to protect all types of defense systems against anti-radar missiles.

    Therefore, the purpose of the Pantsir defense system is to protect civil and military point and area targets and create defensive cover for motorized or mechanized forces up to regimental size and to defend higher-level air defense assets such as S-300 and S-400 against precision munitions, anti-radar missiles, cruise missiles and drones.

    History:
    The first thing to develop the system was the type of carrier chassis. Due to the fact that the purpose of making Pantsir is to provide air defense to S-300 long-range defense systems, the Pantsir defense system required high mobility. For this reason, a wheeled chassis seemed better than a tank tread for the Pantsir-S, because wheeled vehicles are faster and less prone to breakdowns, and are also easier to maintain and cheaper to manufacture.

    Development of the Pantsir-S began in 1990 as a planned successor to the Tunguska M1. In the first step, the equipment such as the turret and radar were redesigned and then installed on the Ural-5323 chassis and the prototype was completed in 1994. This sample was displayed at the MAKS-1995 exhibition. Due to financial problems that began with the collapse of the Soviet Union in 1991, funding for the development of the Pantsir short-range defense was halted in 1995, but the KBP continued to develop the program using its own funds.

    In order to reduce costs, the same 1L36-1 engagement radar and 9M335 missile used in the Tunguska system were used in the initial design. The turret was modified to increase the number of missiles from 8 to 12, and an optical sighting system was added to it, and the radar was also modified. Two liquid-cooled 30 mm 2A72 cannons with a firing power of 300 to 450 rounds per minute, with a muzzle velocity of 970 m/s and an effective range of 3000 to 4000 m were also used in the turret.

    The prototype of the system had a folding paraboloid search radar operating in the S-band and a flat engagement radar with a conical radome capable of operating in both the X-band and MMW. These radars had the ability to detect and engage with targets with a radar cross section of 0.1 square meters at a distance of 15 km and engaged with two targets at the same time. The set of electro-opticals also gave the system a significant fighting power in the absence of radar.
    The second radar of this system was 1RS2/1RS2-E Shlem or SSTsR fire control radar. This pulse doppler radar could detect a 2 square meter target from a distance of 30 kilometers. This radar operates in two X and Ku bands, the X band to detect the target and the Ku band to guide the missile. This radar, which had the ability to track one target and guide two missiles, was later replaced with another radar.
    One of the reasons for cutting the budget for the production of Pantsir was the inability of this system to fire while moving. This problem was contrary to the main purpose of its development, i.e. protection of mobile systems. The reason for this problem was the use of a modified turret of the Tunguska system. To solve this problem, KBP started redesigning the turret and removed all the remaining features of the old design. Among these efforts was the production of a new PESA (passive electronically scanned array) radar to increase engagement power.
    During the development of the Pantsir system, Ural-5323, MZKT-7930 and KAMAZ-6530 trucks were used, but eventually the KAMAZ-6560 truck entered the production line of this system. However, the MAN chassis provided by the European Union has also been used for the systems delivered to the United Arab Emirates. The development of these parts eventually led to the first release, the Pantsir-S1.

    Variants of Pantisr missile system

    Pantsir-S1 missile system:
    The Pantsir-S1 defense system was supplied with a combination of an anti-aircraft gun and defense missiles, and all its components are installed on a carrier vehicle. This system is designed for point defense of military, industrial, facilities, etc. against warplanes, helicopters, precision ammunition, cruise missiles, and drones.

    Pantsir-S1 system carrier vehicle:
    As mentioned, this system uses the KAMAZ-6560 truck as the main chassis, which is used for the Russian army. KAMAZ truck is a 4-axle 8×8 truck. This 7.31 ton truck uses KamAZ-740.35-400 diesel engine. This 400 horsepower engine allows this truck to carry a maximum of 20 tons of cargo and tow 14 tons of cargo. KAMAZ-6560 truck is also used for other types of Pantsir defense system.
    The Pantsir system can also be installed on the BAZ-6909 truck, which is the truck used in the S-400 system and is similar to the KAMAZ 8×8 truck, but unlike the KAMAZ-6560 truck, which has one steering axle, the BAZ has two steering axles. Also, the Pantsir system is available on the GM-352 armored chassis, which is shared with the Tunguska.

    Pantsir-S1 armament:
    The Pantsir-S1 carries up to twelve 57E6 two-stage solid fuel radio/optical command-guided surface-to-air missiles in sealed ready-to-launch container tubes. Missiles are arranged into two six-tube groups on the turret. The missile has a bicalibre body, consisting of two stages in a tandem configuration. The first stage is a booster, providing rapid acceleration within the first 2 seconds of flight, after which it is separated from the sustainer-stage. The sustainer is highly agile and contains the high explosive multiple continuous-rod/fragmentation warhead, as well as the contact and proximity fuses, guidance flare and radio transponder. The missile is not fitted with a seeker to keep target engagement costs low. Target and missile tracking is instead provided via the system’s multiband sensor system. Guidance data is submitted via radio link for up to four missiles in flight. The system is capable of tracking and guiding four missiles fired at four distinct targets. Operationally, however, two missile salvos are typically fired at each target. The 57E6 missile is believed to have a kill probability of 70–90%. They have a 15-year storage lifetime in its sealed launch container.
    In addition to the described missiles, the Pantsir-S1 system has a liquid-cooled 30 mm 2A38M automatic cannon that can fire 1,950 to 2,500 rounds per minute with a muzzle velocity of 960 meters per second, and the turret magazine capacity has increased to 1,400 rounds.

    Pantsir-S1 radars

    – 2L80E search radar made by VNIIRT company:
    VNIIRT, which is a part of Almaz-Antey Holding as the world’s 8th largest contractor and designer of ground-based air surveillance radars, was responsible for the design of a new radar. The newly designed radar, known as the 2L80 and 2L80E, was a passive phased array (PESA) radar weighing 760 kg with mechanical rotation and dimensions of 1776 x 940 mm. This passive phased array radar is a 360-degree search radar and is mounted at the top and behind the turret and has a freedom angle of 26 to 82 degrees in height, which has a search capability from 1 to 50 km and scans the sky in 2 to 4 seconds. This radar is provided with the ability to identify air targets with an effective dispersion level of 2 to 3 square meters at a distance of more than 30 km and track them from a distance of more than 24 km. With its missiles, Pantsir-S1 can engage tactical aircraft with a maximum range of 20 km and an altitude of 10 km, subsonic cruise missiles with a range of 12 km and an altitude of 6 km, and high-speed air-to-ground missiles.
    The performance of the 2L80E radar for different types of targets according to its radar cross-section is listed as follows:
    36 km for a small fighter jet with a radar cross section (RCS) of 2 square meters.
    20 km for a cruise missile with a radar cross section (RCS) of 0.1 square meters.
    16 km for a glidebomb with a radar cross section (RCS) of 0.2 square meters.
    12 km for an AGM-88 HARM anti-radar missile with a radar cross section (RCS) of 0.1 square meters.
    32 km for an AH-64 Apache attack helicopter.

    – 1RS2-1 fire control radar:
    The 1RS2-1 fire control radar (export version 1RS2-1E), which is a passive phased array (PESA), was developed to replace the 1RS2-Shlem radar. This radar system engages with two targets simultaneously, and by prioritizing the targets and destroying them within one minute, it can engage with 12 targets. The effective range of this system for missiles is 20 km and the maximum height is 8 km. It is also said that it has the ability to engage with artillery shells at a distance of four kilometers.
    KBP claims the radar has a wavelength of “8 mm in K-band” and an antenna geometry of 15 mm (20 GHz) to 18 mm (16.7 GHz). With the ability to guide 4 missiles simultaneously, this radar has the ability to track airborne targets with speeds between 10 and 1100 meters per second.
    The performance of the 1RS2-1 radar for different target types according to its radar cross-section is listed as follows:
    Detection range for a target with a radar cross section (RCS) of 2 square meters: 24 km
    Detection range for a target with a radar cross section (RCS) of 1 square meter: 21 km
    Detection range for a target with a radar cross section (RCS) of 0.5 square meters: 16 km
    Detection range for a target with a radar cross section (RCS) of 0.1 square meters: 10 km
    Detection range for a target with a radar cross section (RCS) of 0.03 square meters: 7 km

    – 10ES1 electro-optical system:
    The 10ES1 electro-optical system has been developed for the Pantsir-S1 defense system. This system uses the MATIS LR thermal camera made by the French company Sagem with a Wide Field Of View (WFOV) sensor with a search angle of 4.17 to 6.25 degrees in order to detect the target and a Narrow Field Of View (NFOV) sensor with a narrow search angle of 0.87 to 1.3 degrees for the lock on the target.
    The 10ES1 electro-optical system has the ability to cover azimuth ± 90 degrees, altitude coverage from -5 degrees to 82 degrees, angular tracking rate of 100 degrees per second and angular acceleration of 170 degrees per second. This system can detect an F-16 fighter jet in a range of 17 to 26 km, AGM-88 HARM missile in a range of 13 to 15 km, cruise missiles in a range of 11 to 14 km, and glider bombs in It is 10 kilometers.

    1RL-123E long range radar and Pantsir-S1 control center:
    The Pantsir system in battalion form has two other parts, which include a 1RL-123E long-range radar and a control station. The exact range of the 1RL-123E radar has not been disclosed, but in various sources, a range of 200 to 350 km has been announced for it. The dimensions of this radar are 2.8 x 3.4 meters and is installed on a KAMAZ-6560 truck. The main drawback of this radar is the lack of 360 degree coverage.
    The control station in a Pantsir missile system battalion is also responsible for coordinating three or four Pantsirs with long-range radar or coordinating several Pantsir systems in the absence of long-range radar. Of course, there is also the possibility of coordination between several Pantsir systems in the absence of a control station.

    Pantsir-S1 exports:
    The first order of this system was registered by the United Arab Emirates worth 734 million dollars. The UAE ordered 50 96K6 Pantsir-S1 systems in May 2000. After the delivery of the first batch in November 2004, the United Arab Emirates requested a new radar, and in 2007, this batch was delivered with the UAE’s desired modifications.
    Syria also ordered 50 Pantsir-S1 systems, which began to be delivered in June 2008. Jordan has also ordered an unknown number of this system. Serbia also announced on January 18, 2020 that it had purchased six Pantsir-S1 systems, and in February 2020, it received the first batch of Pantsir-S1.

    Pantsir-S1 system specifications:
    Armament: 12 anti-aircraft missiles (SAM) on the launcher and 1400 30 mm rounds
    Missile range: up to 20 km
    Height of missile engagement: up to 15 km
    Gun range: up to 4 km up to a height of 3 km
    Radar detection range: 38 km (for a cross section of 1square meter)
    Engagement range: 28 km (for a cross section of 1 square meter)
    Maximum engagement speed: a target with a speed of 1000 m/s
    Number of simultaneously engaged targets: 4 targets
    Reaction time: 4 to 6 seconds if the system is online

    Pantsir-S2/S2E missile system:
    The Pantsir-S2 air defense system (export version Pantsir-S2E) is an improved version of the Pantsir-S1 system, which entered service with the Russian army in 2015. This system uses the same 2A38M cannon along with 12 missiles, which has a range of more than 20 kilometers.
    The new Pantsir-S2 radar is a two-faced SOTS S-band radar that has a hexagonal appearance. This combination allows for faster monitoring of the environment as well as the possibility of engaging in one direction and monitoring behind the head at the same time. This radar has also been improved in terms of range and engagement; So that it has been upgraded from the possibility of simultaneously engaging with one target and guiding two missiles in the Pantsir-S1 system to simultaneously engaging with 4 targets and guiding 8 missiles in the Pantsir-S2 system.
    This system has the new 57E6 missile (export version 57E6E), the range of which has been increased from 20 km to 30 km. Due to this increase in missile range, the new Pantsir-S2 radar should also be able to engage in a range of more than 30 km and detect targets at a distance of more than 50 km. The 57E6E missile has a weight of 76 kg with a 20 kg warhead and a speed of 1300 m/s.

    In general, the main characteristic to distinguish the S2 variant from the S1 is the radar, which is Janus-faced in the Pantsir-S2 system. The extent of export success of this model is not yet known, as not much information has been published about it.

    Two-faced (Janus-faced) SOTS S-band radar of the Pantsir-S2 system
    Promotional video of Pantsir-S2 short-range defense system

    Pantsir-S2 system specifications:
    Carrier vehicle: Kamaz-6560 8×8
    Length: 10.3 meters
    Width: 2.5 meters
    Height: 3.2 to 5 meters
    Crew: 3

    Radar: SOTS S-band and 1RS2-1
    Radar detection range: ~ 55 km
    Engagement range: 30 km
    Maximum engagement speed: targets with a speed of 1200 m/s
    Number of simultaneously engaged targets: 4 targets
    Reaction time: 4 to 6 seconds (if the system is online)
    12 anti-aircraft missiles
    1400 30 mm bullets

    57E6-E missile
    Weight: 76 kg
    Warhead weight: 20 kg (5 kg of explosives)
    Missile range: 20 to 30 km
    Altitude of fire: up to 15 km
    Missile speed: 1300 m/s (780 m/s at final stage)

    Two dual 30mm 2А38M cannons
    Gun range: 4000 meters
    Altitude of fire: 3000 meters

    Pantsir-S2 Air Defense System – Click to view full size

    Pantsir-M/ME missile system:
    The Pantsir-M system (ME for export versions) is the naval version of the Pantsir, and its design was unveiled in 2015, and it has been in service with Russian Army since 2018. This system, which replaced the Kortik SAM system (SA-N-11 Grison), uses two 30 mm GSh-6-30K/AO-18KD gatling cannons with a maximum range of 5 km. Gatling cannon has a higher firing rate and better cooling than normal cannons due to the presence of six rotating cannons. The number of missiles has been reduced from 12 to 8.
    Pantsir-M system can fire the Pantsir family missiles with a range of 20 kilometers and can also fire Hermes-K missiles.
    The Hermes missile is a new and light missile that can engage light armored targets, various types of fortifications, small surface sea targets and air targets at a low speed.
    The Hermes-K missile warhead weighs 27.5 kg, which consists of 13 kg of explosives. Hermes-K missile has two samples with 170 mm and 210 mm booster. The Hermes-K missile with a 170 mm booster weighing 110 kg has a range of 15 to 20 km, and the Hermes-K missile with a 210 mm booster weighing 130 kg has a range of 100 km.

    Hermes-K missile on the right and 57E6E missile on the left

    The fire control radar of this naval system is developed based on the Pantsir 1RS2-1 radar, but the search radar of this system is installed on the mast in a four-sided manner. Also, this system uses an electro-optical system like the ground versions.
    The Pantsir-M defense system was installed on the Odintsovo battleship and tested in October 2020. Pantsir-M was able to destroy all small air targets that were dropped on it by Su-27 fighter jets. Pantsir-M is now installed on Project 22800 of the Navy and other upgraded warships will also be armed with it. This system is likely to become the main close air defense weapon for the Russian Navy.

    Pantsir-M system
    Promotional video of the Pantsir-ME short-range defense system at the Army exhibition

    Pantsir-SA missile system:
    The Pantsir-SA defense system, which was first unveiled at the 2017 Russian Victory Parade, is a development of the Pantsir-S1 system, which is mounted on the DT-30PM armored chassis. The DT-30PM armor consists of two separate parts. The Pantsir-SA appears to have been delivered to the Russian military since 2016.
    The Pantsir-SA system has the same weapons station as the Pantsir-S1, but does not have the 30mm gun mounted on it. The main weapons of this system include 18 57E6 surface-to-air missiles, which are placed in 9 numbers in three rows next to each other on each side of the turret. This system can hit targets at a range of 20 km and a height of 15 km with a maximum speed of 1000 km/s.
    The DT-30PM chassis used in this type of Pantsir has a YaMZ-847.10 12-cylinder V-shaped multi-fuel diesel engine with a power of 800 hp. The DT-30PM can travel at a maximum road speed of 45 km/h and reach a maximum range of 700 km. DT-30PM has the ability to cross slopes up to 30 degrees and transverse slopes up to 15 degrees, and can also cross obstacles with a width of 4.5 meters or a height of 1.2 meters.

    Pantsir-SM missile system:
    The Pantsir-SM defense system is developed based on the Pantsir-S1 system. This system, which was unveiled at the Army 2019 exhibition, had the same radar used in the Pantsir-S1, with the difference that its range was increased. The truck carrying this system has been changed to the K-53958 truck, which is basically a Kamaz-6560M military truck with an armored cabin. All components from search radar and fire control radar, optical system, 30 mm cannon and 12 missiles are installed on the turret assigned to the new truck. The only way to distinguish the S1 system from the SM is this type of truck, which is armored in the Pantsir-SM system and is very different from the Kamaz-6560.
    A replica of the Pantsir-SM system was also exhibited, which shows this defense system with 24 missiles, in such a way that each side of the turret has four rows of three types of 57E6 missiles. But at the time of unveiling, it carries the same 12 standard Pantsir-S missiles.

    This new system has a new missile called 57E6-E-M, which has a range of 40 kilometers. This new missile is designed with the same length as the previous missile to fit inside the previous missile canister. The 57E6-E-M missile gets all its propulsion power from the white booster, which is made of carbon fiber. The system also has a new smaller missile for targeting UAVs and precision guided weapons such as SDBs, which is called 12YA6 and has a maximum range of 5 km.

    The range of the search radar has reached 55 km, and the engagement range has reached 40 km. The main composition of missiles in this system is 10 medium-range missiles and 8 short-range missiles.

    Pantsir-SM system specifications:
    Armament:
    Missile: 12 57E6-E-M missiles independently or combined with 12YA6 missile on the launcher
    Bullets: 1400 30 mm bullets
    57E6-E-M missile range: up to 40 km with a maximum engagement height of 18 km
    12YA6 missile range: up to 5 km with a maximum engagement height of 4 km
    Gun range: up to 4 km with a maximum height of 3 km
    Radar detection range: 55 km (for a cross section of one square meter)
    Engagement range: 40 km (for a cross section of one square meter)
    Maximum engagement speed: a target with a speed of 1000 m/s
    Number of simultaneously engaged targets: 4 targets
    Reaction time: 4 to 6 seconds if the system is online
    Crew: 3

    Pantsir-S1M missile system:
    The Pantsir-S1M defense system was unveiled at the ARMY-2021 exhibition. This short-range defense system is a developed example of the Pantsir-SM version. The radar of this system is a janus-faced radar similar to the Pantsir-S2 system radar. Pantsir-S1M, like all versions of Pantsir, has a search radar, a fire control radar, and an electro-optical system, and is capable of firing all missiles developed for this system. The only way to distinguish this system from the S2 is the armored truck K-53958, which is identical to the SM system.
    Increasing the detection range up to 80 km and increasing the number of detected targets up to 40, increasing the detection range, accurate tracking of 4 targets at the same time, automatic and semi-automatic determination of the coordinates of the missile and the target in the optical band using the electro-optical system (OES), the possibility thermal and television imaging, laser range finder, automatic optical and thermal detector are the new features of this system, which provides the possibility of airspace monitoring and target search by the operator at speeds of up to 1000 meters per second.

    More images of Pantsir air defense systems:

    “Pantsir Short Range Air Defense System” posters in Russian, Arabic, Persian, Kurdish and Azeri:

    Source:
    Pantsir missile system
    “Pantsir’”, S-300 i drugiye sanitary neba
    Станция обнаружения целей (СОЦ) 1РС1-1Е
    KBP 2K22/2K22M/M1 Tunguska SA-19 Grison /96K6 Pantsir S1 / SA-22 Greyhound SPAAGM
    57E6 / 57E6E / SA-22 GREYHOUND
    Pantsir-S1 in Exhibition of MAKS-95
    PANTSIR-S1 / PANTSYR-S1 / SA-22 GREYHOUND
    KamAZ-6560
    Pantsir-SA Arctic short-range air defense missile system
    Pantsir-S1 / S2 / SM mobile air defense system
    Electro-Optic Sensor and System Performance Verification with Motion Systems

    Hermes (missile)

  • Military Knowledge: Sevom Khordad Air Defense System

    Military Knowledge: Sevom Khordad Air Defense System

    This system was seen for the first time at the IRGC achievements exhibition in 2014, and at the time of its unveiling, it had a range of 75 kilometers; After receiving the necessary upgrades in the field of missiles and radar, it reached a range of 200 km. Sevom Khordad system has expanded its operational capability to a wide range of targets by receiving the 9 Dey missile. This fully mobile system can be used as a suitable replacement for the Russian S-200 system and even it’s better than it.

    The image of the prototype of the Sevom Khordad system, which was unveiled in 2014 at the IRGC Achievements Exhibition.

    The Sevom Khordad carrier chassis:
    Sevom Khordad, Raad, Tabas, Alam Al-Hodi and 9th of Dey systems are all from the same air defense family and use the same carrier chassis. Sevom Khordad carrier chassis looks similar to the carrier used in Buk-M2EK and 9K332 Tor-M2 defense systems. Both of these systems use MZKT-6922 manufactured by MZKT.

    The first unveiling of the carrier of the Sevom Khordad missile system took place in December 2012 for the Raad system. But the Iranian model is seriously different from the MZKT-6922 version. The first difference is the length of the truck; The Iranian model is shorter and according to the published images, the engine installation location is in front of the truck, while the engine of the Belarusian model is at the end of the truck. For this reason, the only access door for the operator to the electronic systems in the Iranian example is from the side, and the access doors have different numbers and shapes. Also it seems that the height has increased a little, and two hydraulic jacks have been added in the area between the two axles of the truck for the stability of the system during firing. Considering the presence of three missiles instead of four and the modifications made, it can be said that this truck has better offroad power than the Belarusian model.

    According to these explanations, it seems that Iran made this carrier truck based on the model of Belarus; There is also a possibility that this new chassis was developed with the help of Belarus and produced in Iran.

    Sevom Khordad radar:
    As mentioned, Sevom Khordad system has received many updates in the field of missiles and radar. For a better review, we will look into the radar systems used in Sevom Khordad.

    Sevom Khordad and Tabas systems were unveiled simultaneously in 2014. Tabas was introduced as an inexpensive supplement to Sevom Khordad system; Initially, both systems, as a high-altitude and medium-range system, had the ability to engage at an altitude of 25 to 27 km and a range of 50 km, but Sevom Khordad has an active phased array radar and Tabas has a flat reflector radar with limited rotation power.
    The declared altitude of fire was exactly the same as the range of Buk-M2EK system, i.e. 50 km, which raises the suspicion that the systems are the same. But the differences in the carrier chassis that we reviewed earlier and the use of three missiles in the Iranian systems instead of four missiles in the Russian system, rejected this suspicion. Also, the installation location of the middle fin of Buk missile and Taer missile is different. In the Taer missile, the middle fin is near the end of the missile, while in the Buk missile, the middle fin is located in the middle of the missile.

    In order to better examine the Sevom Khordad radar systems, we must start with the evolution of this system and from its starting point, the Raad system. Contrary to what was seen at the time of the unveiling of Raad system, Raad 1 and 2 systems were installed on commercial trucks. Probably, the reason for using commercial trucks was that the capacity of production line for the prototype was not enough or that the unveiled model was under development.
    The investigation of the primary radars used in the Raad system shows that Raad used pulse doppler radars and its combination with its optical systems, and the whole system was mounted on a commercial truck. So, it seems that the chassis developed for Sevom Khordad was not supposed to be used for the Raad system at all; Rather, the Raad system could be a system similar to Sevom Khordad but for urban and passive warfare; which has used a commercial truck for the carrier for better camouflage, and has the ability to link to TEL variant that only carry missiles.

    Alam al-Hoda system is another system related to Sevom Khordad. Alam al-Hoda system is actually a complementary system for the whole collection.
    Although the exact image of the Alam Al-Hoda radar is not available and its exact range has not been announced, the radar of this system is similar to the Nebo-UE radar. The Nebo-UE radar is a 3D radar in the VHF band with a range of 310 km; But the radar used in the Alam Al-Hoda defense system is a fire control phased array radar in the VHF band.
    Nevertheless, it is noteworthy that after several years since the unveiling of Alam Al-Hoda radar, quality images showing the operationality of such a system have not been published. Therefore, probably, the Alam Al-Hoda system has not been widely implemented or used.

    There are two possibilities for this system:
    1- Considering that Iran has the experience of building the Keyhan mobile radar with a range of 2000 km, the Alam A-Hoda radar is also a very long range radar with a detection range of 500 km and more, which, unlike the nature of VHF band radars, has a very accurate detection capability to detect stealth targets from long distances and is linked with the Sevom Khordad system or any other system and acts as a long-range radar for the Sevom Khordad battalion.
    2- The second possibility is that the Alam Al-Hoda system was actually a development plan for the Sevom Khordad system, which was later led to the use of Bashir radar. Bashir radar can detect cruise and stealth targets and other long-range targets at a range of at least 350 km.

    In general, the Sevom Khordad system consists of three components: Transporter Erector Launcher Radar (TELAR), Transporter Erector Launcher (TEL) and Bashir long range radar for early detection of hostile targets.

    Until now, not so many images of the Sevom Khordad radar system have been published, and reliable information about the height of the conflict and its range has not been provided by the official authorities; But what is clear is that this radar has continuously developed since its unveiling in 2014. According to the available information, this radar is an active phased array (AESA) radar in the X band with 1700 elements, which can simultaneously detect 4 targets and guide 8 missiles (two missiles for each target).
    The altitude of fire for this radar can be estimated up to 30 km, and the range of this radar has probably reached more than 200 km. The reason for this is the presence of Sevom Khordad long-range (Taer-3) missile with a range of 200 km, which was unveiled at Iranian Armed Forces parade on commemoration of the Sacred Defense Week on September 22, 2022.

    Bashir radar:
    The Bashir radar, which is one of the important components of the Sevom Khordad system, is a 3D phased array radar with linear antenna arrays that operates in the L and S bands and is capable of detecting cruise and stealth targets. The maximum range of Bashir radar is 350 km. This radar, which was unveiled and used in the Welayat 97 military exercise in February 2019, is installed on a truck and is placed at a certain height by opening jacks and then rotates to cover 360 degrees. Evidence that Bashir radar has the ability to be used as a fire control radar has not been obtained to date; Therefore, the previous assumption that the main radar of the Sevom Khordad has a maximum range of more than 200 km, can be correct.

    The way Bashir radar is set up and the very short time it takes for this radar to start working

    In the Sevom Khordad system, the entire complex, i.e., missiles, radar, and control station, are all mounted on one vehicle, so Sevom Khordad is able to perform missions completely independently. But its main radar, which is responsible for detecting and locking on the target and then intercepting and guiding the missiles, can only operate in one direction and does not have the ability to engage in four directions at the same time. This is the main weakness of the Sevom Khordad system, and if it is used independently, it will be surprised and vulnerable to attack from several different directions.
    Therefore, Bashir radar, as a very important part of this system, is an important factor in the stability of the Sevom Khordad system in the battlefield, to detect cruise and stealth targets and to constantly monitor the environment around the Sevom Khordad system. With the presence of Bashir radar in this system, it is possible to monitor the surrounding environment in 360 degrees, and by using four Sevom Khordad systems in one battalion, surprise and destruction of the system is prevented.

    Each battalion of the Sevom Khordad missile system includes a control station that is responsible for coordinating the Bashir radar and four TELARs of the Sevom Khordad system. Bashir radar is also responsible for 360-degree scanning of the surrounding environment in the battalion. Each TELAR vehicle can also coordinate with two TELs in the battalion, in addition to coordinating with Bashir radar and control station. As a result, each battalion includes a control station, a Bashir radar, four Sevom Khordad systems (TELAR) and eight TELs, with a total of 36 missiles serving a Sevom Khordad air defense system battalion.

    The number of missiles used in the Sevom Khordad missile system is varied. These missiles include: Taer-2, Taer-2A, Taer-2B, Sayyad-2, Sayyad-2C, Sayyad-3, 9 Dey and the Sevom Khordad (Taer-3) long-range missile.
    The existence of this number of missiles in different ranges can be considered one of the distinctive aspects of this system, because it gives the Sevom Khordad system the ability to perform various missions. In fact, the Sevom Khordad missile system today is not a BUK class system, but an S-300 class system. The comparison between the two may seem far-fetched, but by looking at the S-300 system, we will realize that this system also uses a large number of missiles with different ranges and different altitudes of fire. Only the 40N6 missile that used in the S-300 PMU-3 or S-400 air defense system, has a longer range than the Sevom Khordad missiles. So practically today, the Sevom Khordad system has capabilities close to the S-300.

    Regarding the 9 Dey missile, it is necessary to mention that this missile, unlike other missiles of the Sevom Khordad system, is launched from a box launcher that is specially made for the 9D missile. Therefore, sometimes this launcher is mistakenly considered another independent systems under the title “9 Dey Air Defense System”, which is not true. Rather, this system is the same as the Sevom Khordad system, but with a special box launcher for launching 9 Dey missiles.

    A special box launcher for launching 9 Dey missiles in the Sevom Khordad missile system

    Range and flight ceiling of active missiles in the Sevom Khordad system

    The range and flight ceiling of active missiles in the Sevom Khordad system are:
    Taer-2: with a range up to 50 kilometers and flight ceiling of 27 kilometers
    Taer-2A: with a range up to 75 kilometers and a flight ceiling of 27 kilometers
    Taer-2B: with a range up to 105 kilometers and a flight ceiling of 27 kilometers
    Sayyad-2: with a range up to 75 kilometers and a flight ceiling of 27 kilometers
    Sayyad-2C: with a range up to 120 kilometers and a flight ceiling of 27 kilometers
    Sayyad-3: with a range up to 150 kilometers and a flight ceiling of 30 kilometers
    9 Dey: with a range up to 5 to 30 kilometers and a flight ceiling of 20 kilometers
    Taer-3 (Sevom Khordad): with a range up to 200 kilometers and a flight ceiling of 30 kilometer

    The first missile of this system is the Taer-2 missile, this missile and the Taer-2B missile are the first missiles that have been seen on the Sevom Khordad, Tabas and Raad system. After that, Sayyad-2 and then Sayyad-3 were adopted for Sevom Khordad system, and until Taer-3 was produced, the longest range missile of this defense system was Sayyad-3 with a maximum range of 150. Finally, with Taer-3 (Sevom Khordad) missile, with a range up to 200 km, this missile became the longest-range missile of the Sevom Khordad system.

    As for the missiles used in the Sevom Khordad system, there are two missile families: the Taer family and the Sayyad family. The difference in the appearance of these two families, as shown in the picture, is more evident in the middle fin; Of course, there are differences in the fin at the end of the missile. But in each generation, the middle fin has a fixed shape, the main reason for which was the pattern of each missile at the time of its design and construction.

    In the Sayyad family, the missile is modeled after the standard missile, and in the Taer family, the missile is designed and built based on the model of the BUK family.
    The middle fin of the Sayyad missile is a trapezoid, both edges of which are angled and extends to the body of the missile. But in Taer, the shape of the middle fin is a trapezoid, one edge of which is vertical and the other edge of which is angled. Due to this difference in appearance, we classify the Sevom Khordad (Taer-3) missile in the Taer family.

    Another point is that the Taer missile has a radar to detect targets in the last stage. However, there is still no information about the presence of such a radar in Sayad-2, Sayad-2C and Sayad-3 missiles. It means that the Taer missile is likely to have the ability to detect the target independently, and the Sayyad missile needs to be guided until the moment of impact.

    The next subject about Taer family missiles is that the radome part of the missile is made separately. This feature makes it possible to build a missile with different guidance capabilities at the lowest cost; This has led to the construction of the Taer-2 passive guided missile for the Sevom Khordad system. There is also a version of the Sevom Khordad system that provides the possibility of passive missile guidance at the same time as radar guidance. It is not clear exactly how passive guidance is implemented in the Sevom Khordad system and how it works.

    The sea-based version of the Sevom Khordad system was seen for the first time on the Shahid Siavashi ship of the IRGC along with the passive version of this system. Also, the IRIS Shahid Roudaki was unveiled along with the Sevom Khordad system; Therefore, it is possible to make this system operational with Shahid Roudaki.

    A version of the Taer missile was displayed in the National Aerospace Park of Iran, which identified its various components separately, for example, the location of the missile warhead is located behind the missile’s radar. Also, the Taer missile warhead was displayed, which is a high explosive fragmentation (HE-FRAG) warhead.

    The missiles used in the Sevom Khordad system have another feature, which is the use of proximity sensors such as the Meteor air-to-air missile. This sensor allows the missile to explode near the target and minimizes the need for a direct missile hit. Proximity sensors in the form of strips have been seen on all 9 Dey, Sayyad-2, 2C and 3 missiles as well as Taer 2 and 3.

    Taer missiles have a special flight profile, and in the published footage of how this system works, two points are noteworthy for these missiles. The first point is the flight profile of the Taer missile to deal with cruise missiles, which flew at a distance of several meters from the surface, and this type of flight is very practical. The next point is the missile hit with targets with a higher height. In the published images, the missile hits the target from above, and as stated, with the presence of proximity sensors intended for the missile, this missile does not need a direct hit.

    The control station in the TELAR launcher of the Sevom Khordad system is located beneath the missiles and behind the engine of the carrier vehicle, which is an equipped and fully digital station. Each Sevom Khordad system is connected to a Bashir radar and control station to perform the task of aerial surveillance with greater accuracy.

    The possibility of linking Sevom Khordad with other systems:
    Since Sayyad missiles links to the Sevom Khordad radar, it seems that other systems that currently use Sayyad missiles can also link to the Sevom Khordad system; Such as the Najm-802 radar, which is used for the early warning radar of the Talash system and 15 Khordad as the user of the Sayyad missile. Of course, another possibility can be proposed for the Sevom Khordad system, and that is to link this system with the Bavar-373 system so that Taer missiles can also be used in the Bavar system. Although what was said about the coordination of the Sevom Khordad system is only speculation, but considering the background of the mentioned systems, the use of Sayyad missiles on the Sevom Khordad is also not far from the mind.

    Read more: Military Knowledge: Bavar-373 Long-Range Air Defense System

    The final combination of missiles in the Sevom Khordad system:
    It seems that the combination of missiles operating in the Sevom Khordad system has reached a smaller set today, which shows the independence of the system in the field of production, service and operation in the IRGC combat organization. In its evolution, the Sevom Khordad system has reached three missiles, which are perfectly suitable for three types of conflicts. The first missile is the 9 Dey missile, which is suitable for engagement in the last ring of defense and a range of 5 to 30 km, and its engagement height is 20 km; The ability to fight at this level is excellent. But the second missile is the Taer-2 missile, which has a range of 30 to 105 km at an altitude of 25 to 27 km. The third missile, the Taer-3 missile, as a long-range missile of this system, gives the Sevom Khordad system the ability to fight from a range of 100 to 200 km. The Sevom Khordad missile system achieves a very good operational efficiency with such a combination. Of course, it is still possible to use Sayyad family missiles on Sevom Khordad.

    Weaknesses of the Sevom Khordad system:
    The only problem that the Sevom Khordad system has in the missile section is a missile suitable for targeting ballistic missiles. By adding such a missile to this system, as well as correcting the radars for engagement with ballistic missiles, this system will be a powerful and much more efficient system. Of course, it has been said that this system has the ability to engage targets up to 1000 km/h, which is a very good number.
    Another weakness of this system (if it is used independently) is the lack of 360 degree coverage, which is largely solved by the Bashir radar.

    The main composition of missiles of the Sevom Khordad system – From right to left: 9Dey, Taer-2, Taer-3 missiles

    Operational history of Sevom Khordad:
    On June 20, 2019, Sevom Khordad missile system managed to shoot down an American RQ-4A Global Hawk drone over the Strait of Hormuz and near Mubarake Mountain. RQ-4A drone was detected by the early warning radar at a distance of 490 km and at a distance of 120 km, Sevom Khordad did a radar lock on it and finally the missile hit the RQ-4A at a distance of 75 km and at an altitude of 14 km and destroyed it. It should be noted that the Sevom Khordad air defense system became known as the “Vulture Hunter” after shooting down the US RQ-4A.

    A video of Sevom Khordad air defense system that hunted the US RQ-4A drone

    Specifications of Sevom Khordad air defense system:
    Type: Fully mobile high-altitude long-range missile defense
    Length: 8.9 meters
    Width: 2.5 meters
    Height: 2.5 meters
    Range: 200 km
    Altitude of fire: 30 km
    Number of simultaneously engaged targets: 4 targets
    Number of simultaneously guided missiles: 8 missiles
    Missiles: Taer-2, Taer-2B, Sayyad-2, Sayyad-2C, Sayyad-3, 9 Dey, Taer-3
    Fire-control radar: The name is not specified with a range of more than 200 km and installed on the TELAR vehicle
    Search radar: Bashir radar with a range of 350 km

    9 Dey missile (with a special launcher):
    Range: 5 to 30 km
    Altitude of fire: 20 km
    Length: 3.8 m
    Diameter: 25 cm
    Weight: ~ 240 kg

    Taer-2 missile:
    Range: 30 to 105 km
    Altitude of fire: 25 to 27 km
    Length: 6.10 m
    Diameter: 40 cm
    Weight: ~ 1000 kg

    Taer-3 missile:
    Range: 100 to 200 km
    Altitude of fire: 27 to 30 km
    Length: 6.55 m
    Diameter: 47 cm
    Weight: ~ 1400 kg

    Sevom Khordad air defense system – click to view full size

    More images of Sevom Khordad air defense system:

    The collection of posters of Sevom Khordad air defense system in Russian, Arabic, Farsi, Azeri, Kurdish:

    Source:
    Nebo-UE 3-D VHF Surveillance radar
    نمایشگاه بین المللی هوا فضای ماکس-2011 روسیه
    «علم الهدی» ناشناخته‌ترین سامانه شکار جنگنده‌های رادارگریز
    Buk-M2EK
    MZKT-6922
    MZKT
    سامانه های پدافندی خانواده رعد
    Transporter erector launcher

  • Military Knowledge: Leopard 2

    Military Knowledge: Leopard 2

    The first generation of the Germans’ Main Battle Tank (MBT) was the M48 Patton tank made by the United States, and the second generation was the Leopard-1 tank, which is still in service with modifications for other NATO users. The Leopard 1 tank was designed and produced in West Germany in the 1960s. This tank was first produced in 1963 by Krauss-Maffei for the Ministry of Defense of West Germany, and more than 6,000 units of it were produced for 9 NATO member countries, including Germany, the Netherlands, Belgium, Greece, Turkey, Italy, Canada, Norway, as well as Made in Australia.

    To develop and improve the Leopard-1 tank, Germany started developing the MBT-70 project in 1963 with the cooperation of the United States of America. However, in 1967, the German government ordered Porsche to research the facilities needed to upgrade the Leopard-1 tank. It is interesting to know that the Leopard-1 tank was in the service of Germany from 1965 to 1995, and the need for the MBT-70 project was announced before the Leopard-1 tank entered service. Leopard-1 was designed by Porsche and manufactured by Krauss-Maffei. This issue becomes more interesting when you know that Porsche named this new project Vergoldeter Leopard or Gilded Leopard and focused on updating with advanced technologies. Adding an automatic loader, an automatic and coaxial cannon with a machine gun, an independent periscope for the commander, the possibility of using an anti-aircraft machine gun from inside the cabin, the presence of a television surveillance camera on the mast with the possibility of increasing the height, changing the shape of the turret, improving the suspension system, the gearbox and engine exhaust valves, were considered as new project items.

    Development and production:

    In 1967, the West German government decided to produce a prototype of the Gilded Leopard project, as well as an experimental development based on the Leopard 1 tank. But due to the lack of sufficient funds, it was not possible to develop two projects at the same time, finally a trial development contract was concluded with Krauss-Maffei, but this company committed to work with Porsche to develop the chassis and with Wegmann to develop the turret. In this regard, two prototypes with different components were built with the aim of improving the Leopard 1 tank to match the firepower requirements of the MBT-70. The purpose of these optimizations was to increase the probability of hitting the first shot at a range of more than 2000 meters. Also, increasing the ability to accurately engage with moving targets using a computerized fire control system was another main goal of the experimental development. The tanks built were nicknamed Keiler. Two prototypes (ET01 and ET02) were built by Keiler in 1969 and 1970, both powered by the MB872 engine.

    After many ups and downs in 1971, the name of the MBT-70 project was changed to Leopard-2. In the same year, 17 prototypes were ordered, but only 16 hulls were built because production of the PT12 hull was cancelled. The turrets were named from T1 to T17 and the hull from PT1 to PT17. These prototypes were produced to perform numerous tests, from the required and different components and concepts for the development of the tank, and each sample had components that were not found in other samples. Ten of these turrets were equipped with 105 mm cannons and seven prototypes were equipped with a 120 mm cannon. The welded turret used spaced armor formed by two steel plates. Prototypes were equipped with the EMES-12 optical range finder and fire control system, which was later used in the Leopard 1A4. The T14 turret was modified to install new anti-armor modules and was equipped with an all-electric turret drive and stabilization system. The turret was jointly developed by General Electric and AEG Telefunken.

    The PT15 model with a 105 mm cannon

    In July 1973, an agreement was signed between the defense ministries of Germany and the United States to standardize the Main Battle Tanks (MBT) in favor of NATO. Due to the previous joint cooperation on the MBT-70 design, it was decided to use the parts that were completely manufactured by German companies for the Leopard 2 in the Abrams tank prototype, which reduced the cost of the XM1 Abrams design.
    According to the US laws, it was not possible to interfere in the production of the XM1 Abrams tank by the German company. As a result, modification of the Leopard-2 prototypes to meet US Army requirements was considered. On December 11, 1974, a memorandum of understanding was signed between Germany and the United States that required the United States to test a modified version of the Leopard-2 against the XM1 prototypes. Also, this memorandum obliges the Federal Republic of West Germany to send a sample suitable to the needs of the United States for examination.

    A tougher version of the Leopard 2 tank, the Leopard 2AV, was developed to meet both US requirements and the latest protection requirements of the German Ministry of Defence. The T14 turret was used as the main turret of the Leopard 2AV, but achieving the required level of protection for the hull required further research, until final ballistic tests were carried out in June 1976. The United States preferred to use a US-made laser range finder; For this purpose, the US Hughes company’s laser range finder was used on the turret. This turret was installed on the PT19 prototype.
    Compared to the Leopard 2 prototypes, the AV prototype had a fire control system, along with the EMES-12 optical range finder. In this example, the crosswind sensor was removed and air pressure and temperature sensors were added. Modifications such as the addition of a PERI R12 commander’s sight with infrared illuminator, short-range anti-infantry grenade launcher, retractable searchlight, fixed searchlight, retractable night vision camera, APU and mechanical loading assistant were among the additions to the AV prototype.

    Due to the longer-than-expected design and production of the Leopard 2AV, it was not possible to send the Leopard 2AV to the United States and conduct tests in the United States before September 1, 1976. Despite German efforts to evaluate the Leopard 2AV and XM1 prototypes at the same time, the US Army decided not to wait for the Leopard 2AV and tested XM1 prototypes built by Chrysler and General Motors.

    The Germans sent two prototypes of the hull and three turrets to the United States: the PT20 using a 105 mm L7 gun with a Hughes fire control system, and the second PT19 with the same Hughes fire control system but with the 120 mm Rheinmetall cannon. The third prototype was called the PT21, which was equipped with a Krupp Atlas Elektronik EMES-13 fire control system and a 120 mm Rheinmetall cannon. A study conducted by the US company FMC showed that manufacturing the Leopard 2AV under license in the US would not exceed the cost limits set by the US military. Thus the Leopard 2AV design fully met the US requirements. But after obtaining the license to manufacture the Leopard 2AV, FMC decided not to submit a technical proposal because they saw little chance of acceptance for a vehicle that had not been developed in the United States. For this reason, the focus was on common features and components between the two tanks.

    A US military evaluation found that the XM1 had more special armor than the Leopard 2AV. In tests, the Leopard 2AV was found to have the same performance as the XM1 prototypes, but the AGT-1500 turbine engine used about 50% more fuel. The wheel chains on the Leopard 2AV tank had good endurance, while the wheel chains used on the XM1 prototypes failed to meet the Army’s requirements. The thermal reflection of the MTU diesel engine used in the Leopard 2AV was much lower than the AGT-1500 turbine engine used in the XM1 Abrams. The fire control system in Leopard-2 performed better and the 120 mm gun showed its superiority. The projected production costs for one XM1 tank were $728,000 in 1976, and the costs for one Leopard 2AV were $56,000 higher.

    Contradictory statements about the reasons for rejecting the Leopard 2AV tank were given by America; Such as lower loading speed for firing and lower tank weight as well as better stabilization system of the XM1 Abrams tank. This decision was criticized by many German experts at that time.

    The Ministry of Defense of the West German Federal Government ordered 1,800 Leopard 2 tanks in September 1977, to be produced in five batches. The main contractor was Krauss-Maffei Wegmann (KMW), but Maschinenbau Kiel (MaK) was also contracted to produce 45% of the tanks. The first batch consisted of 380 tanks, with delivery of six tanks scheduled for 1979, 114 tanks for 1980, 180 tanks for 1981, and 300 tanks each year thereafter. This tank entered service from 1979 and Germany received more than 2000 Leopard 2 tanks by 1991. During the Cold War, KMW Company was able to produce 16 units per month and MaK Company was able to produce 9 units per month of this tank. But after the end of the cold war, this production decreased, but KMW company has still maintained its production capacity.

    Leopard 2 variants:

    Leopard 2: The base and early version of the Leopard 2, sometimes informally called “A0” to distinguish it from later versions. This version was the first version produced in the Leopard tank series. From October 1979 to March 1982, a total of 380 tanks of this version were produced.

    Leopard 2A1: In this version, a number of minor modifications were made, including the installation of a thermal sight for the gunner and new ammunition racks on the Leopard-2 tank. This variant of Leopard-2 tank has been used in the Netherlands and Canada.

    Leopard 2A2: This version uses a new thermal sight. This modernisation gradually replaced the original PZB 200 sights in the first batch with thermal sights for the EMES 15 as they became available. The upgrade included the fitting of filler openings and caps to the forward hull fuel tanks to allow separate refuelling. There was an addition of a deflector plate for the periscope and a large coverplate to protect the existing NBC protection system. The tank was given new five metre towing cables with a different position.

    Leopard 2A3: The main change was the addition of the SEM80/90 digital radio sets (also being fitted to the Leopard 1 at the same time), and the ammunition reloading hatches being welded shut. Even with these minor changes the new batch was known as the 2A3.

    An old ammunition hatch of a Leopard 2AV tank with a crew member loading anti-armor rounds into it.

    Leopard 2A4: This version is equipped with a 120mm caliber L44 smoothbore gun along with a high-performance stabilizer, which gives it better combat capabilities than the previous generation. In addition, it has received several upgrades and renovations since its introduction in 1985. The addition of a digital ballistic computer along with an improved fire suppression system plus optimization of the front turret and cannon protection, a new electronic turret and a new automatic cannon arming mechanism, a commander’s periscope equipped with an infrared camera and thermal imaging device, a modern navigation system and etc, are just a few of the upgrades that have been made since then. In general, all models of the Leopard-2 tank have armor consisting of a combination of steel plates of different hardness, elastic materials, and other non-metallic materials to repel various types of anti-armor ammunition, in which changes have been made in this model so that the armor of the Leopard-2 tank model A4 It has a maximum physical thickness of 800 mm.

    The Leopard 2A4 tank was the most produced of the Leopard 2 tanks. Between 1985 and 1992, 2,570 Leopard 2A4 tanks were built for Germany and the Netherlands. After the end of the Cold War, many A4s were sold to other NATO countries including Canada, Denmark, Finland, Greece, Norway, Poland, Portugal, Spain, Sweden and Turkey have also used this tank.

    The latest A4 model is the Leopard 2A4M. The Leopard 2A4M add an additional mine protection plate for the belly, which increases protection against mines and IEDs. Adaptive suspension systems with a combination of thermal imager and low light amplifier, driver’s night vision system for front and rear vision are also among other optimizations of the 2A4M model. Also, to increase operational capabilities, the A4M is equipped with an engineering interface and additional mounts for attaching a bulldozer blade, plow, or roller for dealing with mines.

    During the war between Russia and Ukraine, the Leopard 2A4 tank was the most important option sent by the countries supporting Ukraine. Meanwhile, the Czech Republic was an exception as it sent T-72 MBT tanks to Ukraine and received Leopard 2 in return. On June 5, 2022, Spain announced the delivery of 40 Leopard 2A4 tanks to Ukraine. On January 26, 2023, Canada announced that it had delivered four Leopard 2A4 tanks to Ukraine from their military inventory. On February 3, 2023, Spain announced a plan to supply up to 6 Leopard 2A4 tanks to Ukraine. The first four Leopard 2A4 tanks donated by Poland arrived in Ukraine on February 24, 2023. On March 4, 2023, citing information published by the German news magazine “Der Spiegel”, it was stated that the German company Rheinmetall is ready to supply 50 Leopard 2A4 tanks to Ukraine. Also, on March 7, 2023, Poland announced the delivery of 10 more Leopard 2A4 tanks to Ukraine.

    An image of the Leopard 2A4 KMW tank

    Specifications of the Leopard 2A4 tank:
    Length (turret forward): 9.67 meters
    Width: 3.7 meters
    Height: 2.79 meters
    Weight: 52 tons
    Combat weight: 55 tons
    Engine power: 1500 horsepower (1100 kW)
    Maximum speed: 70 km/h on road and more than 30 km/h off road
    Operational range: 450 km
    Weapons: 120 mm smoothbore gun L/44 – 7.62 mm machine gun

    Various components of the Leopard 2 tank

    Leopard 2A5: The development of this version of the Leopard 2 tank began in 1995 and its production continued until 2002. In the A5 model, armor with a high slope is placed in the front part of the turret and in the sides, and the thickness of the armor has been increased to 1200 mm by these sloped modules. Improvements have also been made to the main armor composition, making it resistant to 125mm APFSDS rounds fired from 1,500 meters away. The inner part of the tank has a spall liner. These liners are used to eliminate the damage caused by projectiles and the fragmentation of armor parts inward if the armor is penetrated. The front third of the tank’s side skirts armour, which protect the tanks against projectiles and rocket-propelled grenades (RPGs), have been replaced with a new, stronger type.

    Arrowhead-shaped armour module of the Leopard 2A5
    Parts of the Leopard 2A5 tank equipped with additional sloped armor

    In addition to the armor changes mentioned earlier, there have also been changes in the command and control section. This tank uses the same gun as the A4 model, i.e. the Rheinmetall 120 mm smoothbore gun L/44 along with two 7.62 mm machine guns, one of which is located on the left side of the gun coaxially with it and the other on the turret and requires an operator outside the tank turret. Two groups of four 76 mm smoke grenades are installed on each side of the turret. The Leopard 2A5 turret is equipped with fully electronic gun control equipment as a replacement for the previous Leopard 2A4’s hydraulic system.
    This model of tank has been used by Germany, Sweden, Spain and 16 other countries. There is also the possibility of delivering this variant to Ukraine.

    Image of emes 15 thermal imaging system installed on Leopard 2A5 tank


    Leopard 2A6: The A6 version has a Rheinmetall 120 mm smoothbore gun L/55, which is one meter longer than the L/44 model used in the A5, making it easy to distinguish the A6 from the A5. This modern gun has more power due to the use of longer length and high caliber bullets. With the new ammunition, the L/55 also gains greater penetration power at greater distances. With the improved DM53 kinetic energy ammunition, the L/55 gun can fire up to a range of 5,000 meters.
    DM53 ammo is a new type of ammo that has a melting shell, this increases the volume of explosives in the pumice, which improves muzzle velocity. The DM53 ammunition was developed for both the L/44 and L/55 cannons.

    Shooting 5 dm53 bullets within 20 seconds. As it is clear, the bullets have no pumice and only a small part of the bullet remains.

    On both sides of the turret, two places with four smoke grenades are installed. The gunner is equipped with a stabilized dual-magnification EMES-15 sight with a 9,900-meter range laser rangefinder and a thermal imaging unit (WBG) connected to the fire control computer. The fire control computer sequentially calculates the sight angle and side angle for the main weapons. The production of this version started in 2001 and continued until 2005.

    In general, the Leopard 2A6 tank with the changes it received reached a weight of about 61.7 tons. This tank was equipped with a MTU MB 873 diesel engine, with a power of 1500 hp, and a Renk HSWL 354 gear and brake system, so that it could carry out its missions despite its greater weight. A6 has a maximum road speed of 70 km/h and a maximum range of 450 km.

    Leopard 2A6 tank in the service of the German army

    Leopard 2 also has an A6M model. In the A6M version, for more protection of the crew against mines, toothed plates are used under the chassis, which makes the crew more survivable on the battlefield.
    Also, the Leopard 2A6EX model has been made with private investment for the export market. The Leopard 2A6 EX tank has an auxiliary power unit, air conditioning unit and improved armor protection over the base model A6.

    Periscope system PERI R17 assigned to various Leopard 2 tanks

    Leopard 2A7: This version of the tank is known with two models A7 and A7+. The A7 tank was not optimized for urban warfare and was fundamentally different from the variants developed by KMW. Therefore, another example named A7+ has been developed by KMW (Kraus-Maffei Wegmann), which has better urban warfare capabilities added to this tank.
    The Leopard 2A7+ tank has been in service since 2014 and was first publicly displayed at the Eurosatory exhibition in 2010 by the German Ministry of Defense.

    Leopard 2A7+ tank at the Eurosatory exhibition in 2010

    The upgrade of this version of the Leopard 2 tank began in 2012. The Leopard 2A7+ is designed to operate both in low-intensity and high-intensity conflicts. The tank’s protection has been increased by modular armour. The frontal protection has been improved with a dual kit on the turret and hull front, while 360° protection against RPGs and mine protection increase the survivability of the tank in urban operations
    The asymmetric threats of terrorist groups, improvised explosive devices, complex and dangerous urban environments led Krauss-Maffei Wegmann to offer the Leopard 2A7+ a suitable solution for armored forces, so that they can carry out their missions more effectively and safely.
    Like the A6 version, the Leopard 2A7+ tank is equipped with the Rheinmetall 120 mm smoothbore gun L/55, replacing the L/44 cannon. Increasing the length of the barrel from 44 caliber to 55 caliber (139 cm) allows more of the energy in the barrel to be converted into projectile velocity. The new programmable 120mm HE gun capability enables the crew to engage targets behind cover and inside buildings.
    The turret-mounted MG3 has been replaced with a stabilised FLW 200 remotely controlled weapon station. Mobility, sustainability, and situational awareness have also been improved.
    The optimizations made in version 2A7+ are available as an upgrade kit for all versions of Leopard 2 and include a complete set of all components.

    7.62 mm machine gun installed on the remote control weapon station KMW FLW 200 on the turret of the Leopard 2A7+ tank

    The Leopard 2A7 + tank is divided into two versions, which we will briefly introduce below:
    Leopard 2A7+ Duel Operations: Developed by KMW and based on a Dutch Leopard 2A6, this model has been optimized for anti-armor operations on the modern battlefield.
    Leopard 2A7+ Urban Ops: The Leopard 2A6 upgrade is equipped with new armor and special equipment for urban combat operations. In fact, this example is considered an upgrade kit.

    How the Leopard tank works on the battlefield

    In all types of Leopard 2 tanks, different thicknesses of armor are used throughout its body. The side and back of the tank are resistant to heavy machine guns, medium caliber bullets and old types of anti-tank ammunition. The side of the body is also covered by armor in the new types to protect against shrapnel and light anti-armor such as RPG and roadside bombs to save the tank crew. On both sides of the body, rubber plates reinforced with steel are used to cover the tank chains. To increase mine protection, a 45-degree slope is used in the front and back, and the floor is reinforced with corrugations.

    Reviewing the armor of Leopard 2, especially the A5 variant, from the way it is arranged to the way the anti-armor bullet penetrates

    Leopard 2 tanks can carry 42 bullets, 15 ready-to-fire bullets are stored in the turret and the rest are stored in front of the body and next to the driver. This ammunition tank is equipped with NBC protection system and automatic fire extinguishing systems.

    This tank uses two types of APFSDS-T anti-armor bullets and HEAT-MP-T multipurpose bullets. The APFSDS-T bullet has the ability to penetrate 450 mm of rolled homogeneous armor at a range of 2000 meters. Since its introduction, several generations of APFSDS-T rounds have been developed and used by the German military. The Germans claim that the Leopard-2 tank bullet can penetrate the front armor of the Russian T-72 tank at a range of 2000 meters and the front armor of the T-62 tank at a range of more than 4000 meters.

    All variants of the Leopard 2 tank have four crew members, including the commander, gunner, loader and driver, and in addition to the 120 mm cannon, it has two 7.62 mm machine guns. One is guided by the gunner and moves along with the main gun, and the other is mounted on the turret, which in the prototypes is fired by one of the crew, and in the A7+ is controlled by remote control from inside.

    The engine used in the A4 and later models is a MTU MB 873 Ka-501 12-cylinder twin-turbocharged diesel engine that provides 1479 horsepower. Providing a torque of 4,700 newton meters at 1,600 to 1,700 rpm gives the tank a very good performance.

    The existence of a very good suspension system and gun stabilizer has provided the possibility of accurate shooting and specific movement conditions for this tank. Leopard 2 has tanks with a capacity of 1160 liters of fuel and can travel up to 450 km on the road and up to 300 km on rough terrain.

    Future development of Leopard-2 tank titled “Panther KF51”:

    The Panther KF51 tank is being developed by Rheinmetall based on the Leopard 2A4 chassis and has not yet reached mass production. This tank uses a new turret that is equipped with a 130 mm automatic cannon, which gives this tank more fire power.

    130 mm Rheinmetall gun

    The development of this tank started in 2016 and the first example was produced and tested in 2018. Its full development is expected to take until 2026, but it is already possible to produce a prototype. One of the features of this tank is coordination with the HERO 120 suicide drone. Using active protection instead of passive protection, using artificial intelligence in the fire control system to enable automatic target detection and identification, using a more powerful engine, using a body with less weight and greater ability to adapt to the environment for longer survivability in the fields are some of the salient features of this model. It is also possible to create an unmanned version of the Panther KF51, which has not yet reached the stage of production and testing.

    The current model of the Panther KF51 tank uses the same MTU MB 873 Ka-501 engine used in the previous models of the Leopard 2 tank. Due to the weight reduction of Panther to 59 tons, its navigation capacity has increased up to 500 km.
    The KF51 Panther is stated to have three layers of protection: passive, reactive and active. The innermost layer consists of all-welded steel armour covered by passive armour modules. The second layer comprises sensor-based reactive armour, while the final layer consists of Rheinmetall’s Active Defence System (ADS) Active Protection System (APS) that Rheinmetall claims is capable of protecting against kinetic energy (KE) projectiles and Anti-Tank Guided Missiles (ATGMs). It is possible to mount the ADS on both the hull and the turret.
    The Panther is fitted with eight Rheinmetall Rapid Obscuring System (ROSY) smoke grenade launchers mounted in staggered rows of two behind the central camera housing on each side of the turret. It is possible to integrate sensors into the Panther that can detect the launch signature of ATGMs and unguided anti-tank rockets before cueing the vehicle’s crew towards the threat or launching appropriate countermeasures. The Panther can be fitted with Rheinmetall’s Top Attack Protection System (TAPS). This comprises a hard-kill element in which the coverage of the ADS is extended to the roof of the platform to protect against both ATGMs and unguided anti-tank rockets launched at high elevations, as well as a soft-kill element that aims to protect against threats such as loitering munitions..

    A video of the introduction of Panther KF51

    Leopard 2 export and contracts:

    In 2011, it was announced that Saudi Arabia plans to purchase 270 Leopard 2A7+ tanks from Germany, but this was not confirmed by Germany.
    According to reports, in 2013, Qatar ordered 62 Leopard 2A7+ tanks, 24 PzH-2000 155mm self-propelled howitzers (SPH) and several light armored vehicles in a contract worth $2.21 billion. The first batch of these weapons was delivered to Qatar in 2015 and the second batch in 2016 by the German company KMW.
    On December 19, 2018, Hungary signed a contract with the German defense company Krauss-Maffei Wegmann (KMW) for the purchase of 44 Leopard 2 A7+ main battle tanks as part of its military modernization process. KMW received an order for the delivery of 44 Leopard 2A7+ tanks to the Hungarian Defense Forces in December 2018, scheduled for delivery between 2021 and 2025. According to information published in May 2022 by the Reuters news agency, the Czech Republic is negotiating with Germany to purchase 50 machines.

    Leopard-2 specifications:
    Crew: 4
    Length Turret forward: 9.67 meters (2A4 and 2A5 models) – 10.97 meters (2A6 and 2A7+ models)
    Width: 3.7 meters (2A4 model) – 3.76 meters (2A5 and 2A6) – 4 meters (2A7+ model)
    Height: 2.79 m (2A4 model) – 3.03 m (2A5 and 2A6) – 2.64 m (2A7+ model)
    Ground clearance: 0.54 meters
    Wading depth without preparation: 1.2 meters
    Wading depth with snorkel: 4 meters
    Engine: MTU MB 873 Ka-501 12-cylinder twin-turbocharged diesel engine with 1500 horsepower
    Fuel capacity: 1160 liters
    Speed: 72 km/h – backwards 31 km/h
    Range: 450 km
    Empty weight: 52 tons (2A4 model) – 57.3 tons (2A5 model) – 57.6 tons (2A6 model)
    Combat weight: 55.15 tons (2A4 model) – 59.5 tons (2A5 model) – 61.7 tons (2A6 model) – 67.5 tons (2A7+ model)
    Rotation time (360°): in 10 seconds
    Armament:
    – Rh-120 L/44 120 mm smoothbore gun and 7.62 mm machine gun (2A4 and 2A5 models)
    – Rh-120 L/55 120 mm smoothbore gun and 7.62mm machine gun (2A6 model)
    – Rh-120 L/55 120 mm or Rh-120 L/44 120 mm smoothbore gun, FLW 200 system with 40mm automatic grenade launcher and 7.62mm machine gun or 0.50 MG machine gun (2A7+)

    Click to view full size

    More images of Leopard 2 tank:

    Collection of “Leopard Tank 2” posters in Russian, Arabic, Farsi, Kurdish and Azeri languages:

    Sources:
    Leopard 1
    Leopard 2
    Panther KF51
    Leopard 2A4 MBT
    LEOPARD 2A7+ MBT KMW
    KMW LEOPARD 2
    Leopard 2 ammunition storage plan
    ammunition hatch in the Leopard 2A3
    Germany approves Leopard 1 battle tank exports to Ukraine
    Leopard 2 tanks: what are they and why does Ukraine want them?
    Leopard 2 Main battle tank
    Leopard 2A4M CAN Main battle tank
    KMW DELIVERS BATCH OF NEW LEOPARD 2A7+ MBTS TO QATAR
    Leopard 2A4 “FIN”
    Leopard 2PL Programme Showcased
    Leopard 2A4 missing telescopic gun sight & EMS-15 magnification
    Leopard 2A6EX
    Leopard 2 A7+ Main Battle Tank
    Main battle tank
