  • Military Knowledge: Yak-130 Fighter Trainer

    Military Knowledge: Yak-130 Fighter Trainer

    History:
    The Soviets were looking for a new trainer fighter to replace the Aero L-29 Delfín and Aero L-39 Albatros trainer jets. The Soviet Air Force, after reviewing the five submitted designs of Sukhoi S-54, Myasishchev M-200, Mikoyan MiG-AT, and Yakovlev Yak-UTS, in 1991, selected two MiG-AT and Yak-UTS designs for prototype production and competition.

    The development of Yak-UTS began in 1991, but with the collapse of the Soviet Union on December 25, 1991, there were not enough funds to continue the work, so in 1993, the Yakovlev company agreed with the Italian company Aermacchi to jointly develop this aircraft.

    Aermacchi was responsible for the financial and technical support of the project and the name of the project was changed from Yak-UTS to Yak/AEM-130. The first prototype of this training fighter was built by the Sokol company (manufacturer of MiG fighters) named Yak-130D and unveiled in June 1995. Yakovlev company managed to make the first flight of this fighter from Zhukovsky airport on April 25, 1996, piloted by Andrey Sinitsyn.

    In 1996, it was reported that the development of the fighter and the construction of four prototypes cost 500 million dollars.

    Iran also unofficially participated in this plan in 1998. Iran proposed a fighter named Shafaq. But due to the continuous efforts of America to prevent Iran from being equipped with fighter jets, Russia soon removed Iran from the plan under the US pressure. But the fruit of Iran’s short-term cooperation with Russia in this field led to the unveiling of the Shafaq project in 2007. The overall design of the Shafaq fighter jet was similar to the Yak 130, but it used a V-shaped tail with modified wings.

    Shafaq fighter which was presented as a mock-up

    In 2000, following political pressure from the United States, the Aermacchi partnership also ended with Russia and Alenia Aermacchi continued the M-346 Master design with a Ukrainian engine. This new design made its first flight in 2004. This fighter jet was used by the Air Force of Italy, Israel, Singapore, Greece, Turkmenistan and Poland.

    The Alenia Aermacchi’s M-346 Master fighter jet; very similar to Yak-130

    The Yak-130 production line at the Sokol Aircraft Plant in Nizhny Novgorod, known as Naz Sokol, has been active since 2003, and its first production was numbered in April 2004. The trials of entering the service of this fighter began in 2005 and ended before the delivery of the first flight group in 2009. This fighter entered the service of the Air Force of Russian Federation in July 2009 at the Military Pilot Training Academy in Krasnodar and was exhibited at the MAKS 2009 air show.

    Design:
    The Yak-130 trainer uses a classic swept-wing design. This fighter is made of light alloy with carbon fiber surfaces and uses Kevlar protection for the engines, cockpit and fighter compartment.
    The use of Fowler flaps has helped a lot in reducing drag and increasing the maneuverability of the fighter. This fighter is also optimized for landing and takeoff from short or unprepared runways. Yak-130 uses a wireless flight control system, flight safety system and automatic flight control system.
    The Yak-130 fighter uses an air brake located on the fuselage and near the vertical tail. This device helps this training fighter to land on short runways.

    Yak-130 air brake

    In the Yak-130 fighter, it is possible to close the main air intake and open the upper air intake to prevent Foreign Object Damage (FOD). This hatch ensures the safety of the fighter taking off from the runways.

    A view of the closed air intake. The upper air intake is open.

    Yak-130 uses 9 hardpoints to carry weapons up to 3000 kg. Two weapon hardpoints are placed on the tips of the wings and six hardpoints are placed under the two wings and one hardpoint is placed under the fuselage. The fuselage hardpoint cannot host large equipment because it is placed between the landing gear hatches.

    Yak-130 hardpoints

    In export versions of Yak-130, the flight control system ‘Avionica’ is used. This flight control system belonging to the American company Avionica and is used in fighters such as F15, F16, F18, Mirage 2000, Typhoon, Rafale and F35, and even in the export versions of Sukhoi 27, Sukhoi 30 and MiG 29.

    Yak-130 is equipped with zero-zero K-36LT3.5 seats manufactured by NPO Zvezda. Pilots have 360 degree vision. The front cabin has a visibility of -16 degrees and the rear cabin has a visibility of -6 degrees.

    The all-digital Yak-130 avionics cockpit passes the Mil Standard 1553 defined by the United States of America and can be adapted to customer needs. This all-glass cabin allows both pilots to use a night vision camera and is equipped with three color liquid crystal displays measuring 24.15 cm by 20.32 cm. A Head Up Display (HUD) is used in the front cabin of the Yak 130 so that the pilot can see the target and flight information by looking at it.

    The pilot’s helmet in the front cabin is equipped with a special display for determining the target, and the cabin is also equipped with an audio warning system and an internal and external communication system, produced by Popov Plant.

    This training fighter jet provides the possibility of choosing the type of training flight and simulating the tactics of combat aircraft for easier training of pilots. Yak-130 supports the navigation system including laser gyroscope and global positioning system of Russian GLONASS and American GPS.

    The internal fuel tanks of the Yak-130 fighter include one tank in the body and two tanks under the wing. This fighter can carry fuel tanks under the wings on hardpoints close to the body. External fuel tanks have a capacity of 450 liters each, which brings the total portable fuel to 2650 liters. The possibility of aerial refueling is also available for this fighter, but it is installed on it as a custom.

    Armament:
    The advanced architecture of the Yak-130 avionics complex allows a wide range of Western weapons to be compatible with it. Western air-to-air weapons such as the AIM-9L Sidewinder and Magic 2 or weapons such as the AGM-65 Maverick are examples of these weapons.

    Yak-130 uses eastern weapons such as Vikhr laser guided missile, R73 infrared air-to-air missile, Kh-25 ML air-to-surface missile, KAB series free-falling bombs weighing up to 500 kg, S8 rockets and cluster bombs.

    This fighter does not have a cannon by default and uses a GSh-23 pod instead, which is usually installed in the fuselage hardpoint.

    Image of Yak 130 ammunition – click to view in full size

    Yak-130 radar:
    The Yak 130 combat training fighter uses a radar with a power of 8 to 12.5 GHz called BARS-130 produced by NIIP Zhukovsky.
    This radar is capable of detecting air targets with a cross section of 5 square meters at a distance of 85 km and locking at a distance of 65 km. In addition, it has the ability to identify friend from enemy (IFF), air combat, detect sea and land targets, and also synthetic-aperture radar (SAR).

    Engine:
    Yak-130 in the prototype used the DV-2 engine produced by the Slovakian Povazske Strojarne company belonging to the Slovak Republic with a power of 2200 kg (21.58KN). In later examples, the Yak 130 fighter used the Al-222-25 engine with a power of 2,520 kg of force (24.7KN) made by the Ukrainian company Motor Sich, Zaporozh’e Progress Design Bureau and the Russian company Moscow Salyut Motor Building Production Enterprise.

    The Al-222-25 engine was also used by the Italian fighter M-346 Master.

    Russia produces Al-222-25 engine named RD-35M with 28.45KN power.
    Today, DV-2S engine with 24.5KN power is also produced, which is used for export purposes in the production of Yak 130.

    Exports:
    Algeria, as the first customer of this fighter, placed an order for 16 of them in 2006, and succeeded in receiving these fighters in 2011.

    In 2010, Libya ordered 6 aircraft and Vietnam ordered 8 Yak 130 training fighters. In December 2012, Belarus managed to purchase four Yak-130 fighter jets, which it received in 2015. The Belarusian Air Force received four more in 2016 and four more in May 2019.

    The Myanmar Air Force received three Yak-130 training fighters in late 2016. The country took delivery of another 6 planes in December 2019. Algeria is the user of 16 Yak 130 training fighters.

    Syria also bought 36 Yak 130, which should have been delivered to this country by the end of 2016. But this was postponed due to the war in this country.

    In 2019, Vietnam signed a $350 million contract to purchase 12 Yak 130s, which were delivered to Vietnam in November 2021.

    On December 2, 2023, Iran received two Yak 130 fighters. The number ordered by Iran is not known. According to reports related to the purchase of Sukhoi 35 fighter by Iran, the Yak 130 can be considered as a training fighter for Sukhoi 35.

    Specifications of Yak-130 combat training fighter:
    Role: Fighter trainer an light combat aircraft
    Producer: Yakovlev
    Origin: Russia
    First flight: 1996
    Entered service: 2010
    Crew: 2 pilots
    Length: 11.49 meters
    Wingspan: 9.84 meters
    Height: 4.76 meters
    Wing cross section: 23.52 square meters
    Empty weight: 4600 kg
    Gross weight: 7250 kg
    Maximum take-off weight: 10290 kg
    Engine: 2× Ivchenko-Progress AI-222-25 turbofan engines, 24.52 kN (5,510 lbf) thrust each
    Maximum speed: 1060 km/h
    Cruise speed: 887 km/h
    Maximum range: 2100 km
    Operational range: 555 km
    Flight ceiling: 12500 km
    g limits: +8.0 −3.0
    Rate of climb: 65 m/s
    Trust to weight ratio: 0.7
    Armament:
    Hardpoints: 9 (1 on each wingtip, 3 under each wing, and 1 under the fuselage) with a capacity of up to 3,000 kg (6,614 lb), with provisions to carry combinations of:
    Rockets: 80mm S-8 rocket, S-25 rocket
    Missiles: R-73 infrared-homing air-to-air missiles
    Bombs: FAB-M62, ZB-500, KAB-500Kr

    Yak-130 combat training fighter – click to view full size

    More pictures of Yak-130 combat training fighter:

    Infographics of “Yak-130 combat training fighter” Persian, Russian, Azeri:

    Sources:
    Yakovlev Yak-130
    Yak-130
    FIRST YAK-130S DELIVERED TO VIETNAM
    The Yakovlev Yak-130

  • Military Knowledge: Majid Short-Range Air Defense System

    Military Knowledge: Majid Short-Range Air Defense System

    The Majid Air Defense System is named in memory of the Iranian martyr Majid Ghorban-Khani. This air defense system has been produced by the Defense Industries Organization (DIO) of the Ministry of Defense and Armed Forces Logistics of the Islamic Republic of Iran in a bid to upgrade short-range and low-altitude defense capabilities and it has high mobility and passive guidance for better survival in the battlefields of the today’s world.

    History:
    After the end of the 8-year war imposed by the Iraqi Baath regime on Iran as well as the studies conducted in the Islamic Republic, there was a strong feeling of need for more coherent defense potential against flying targets that were flying at low altitudes. The presence of close air support fighter jets that flew at low altitudes and bombed the front lines during the Sacred Defense (Iraq-Iran war) showed that the quality of systems like Rapier surface-to-air missile system and their small number is not enough to confront enemy fighter jets and create a safe sky. For this reason, in the 1990s, the Islamic country started buying and developing air systems like Ya Zahra air defense system.

    After the first [Persian] Gulf War and the United States’ extensive use of various types of cruise missiles, the Islamic Republic of Iran decided to buy systems such as Tor Soviet-era air defense missile system from Russia to confront the threat of cruise missiles. The process of development and study in the field of dealing with cruise targets continued until the 2010s and nowadays a wide range of missile systems and anti-aircraft canons have been produced and utilized to deal with various targets such as drones, cruise missiles, helicopters, and close air support fighter jets.

    In 2020, the then deputy Minister of Defense and Armed Forces Logistics of the Islamic Republic of Iran announced the completion stages of a system called Majid, but no other details were published. The Majid Air Defense System was unveiled and introduced for the first time in the parade on April 18, 2021. The air defense system included two missiles and an airborne radiation detection system installed on an Aras 2 vehicle.

    Some specifications of the Majid Air Defense System were released in a video introducing the Alborz three dimensional phased-array radar and the Borhan weapons control and command system on September 1, 2021. In this video, an image of the Borhan control screen was seen, indicating the specifications of the Majid Air Defense System as well as the ability of this system to be linked to the Borhan control and command system.

    The video of the unveiling of Alborz radar and Borhan system, here is a picture of the linking of Majid system to Borhan system.

    Design:
    The fully mobile short-range Majid Air Defense System consists of two main parts. One part is its missiles and the other part is an electro-optical detection and tracking system, both parts are installed and used on an Aras 2 tactical vehicle. All parts of the system are located in the vehicle’s cargo section.

    The weapon station includes four AD-08 missiles (capable of being increased to eight) on both sides and an electro-optical system in the center. The weapon station has a 360-degree rotation capability, and the electro-optical system also has a 360-degree rotation capability independent of the weapons station. This system is also installed on a 4×4 Iveco Daily truck in addition to the Aras 2 tactical vehicle.

    The reason for such a change in a truck could be to create better camouflage during movement and a lower chance of detecting this system.

    Carrier Vehicle:
    The Aras 2 tactical vehicle is a 4×4 tactical vehicle manufactured by Iran’s Ministry of Defense. This vehicle offers high mobility, high speed, and off-road capability.
    The Aras 2 tactical vehicle is a 4×4 tactical vehicle manufactured by Iran’s Ministry of Defense. This vehicle offers high mobility, high speed, and off-road capability.

    This provides the Majid system with the ability to ambush or quickly relocate after tracking a target. The Iveco daily truck is a light 4×4 commercial truck made by the Italian company IVECO. This truck has a greater transport capacity than Aras 2 tactical vehicle and has probably been used to carry more missiles. Another possibility is better camouflage by the Iveco daily truck due to more space on the truck so that it can easily move on roads.

    Electro-optical tracking and targeting system:
    The electro-optical tracking and targeting system used in the Majid Air Defense System includes two cameras that are placed on top of each other and in the center of the weapon station.

    The electro-optical tracking and targeting system has a continuous 360-degree rotation capability independent of the weapon station. This system includes a daytime camera and a thermal camera, capable of operating at all times of day and night and in all types of weather.

    The electro-optical tracking and targeting system used in the Majid Air Defense System can detect targets at a maximum range of 15 kilometers and guide four missiles simultaneously towards targets, allowing it to simultaneously protect itself from four different directions.

    Electro-optic system cameras belonging to Majid air defense system

    In normal mode, electro-optical systems rotate towards the target and guide a missile that has been fired until it hits.

    In this state-of-the-art mode, the electro-optical system only tracks one target and merely guides one missile. But with continuous rotation of the electro-optic system, it is possible to find different targets in all directions and then give a firing order.

    In this mode, the camera can continuously monitor its surroundings, and to a great extent it can reduce the possibility of being surprised as well as the destruction of the system. In this guidance method, the electro-optic system becomes a search and targeting system capable of finding several targets that can guide several missiles.

    In this video, the missile is fired at the same time as the electro-optical system rotates. This means that the system does not need a lock on the target.

    The AD-08 missile:
    The missile used in the Majid Air Defense System is a short-range missile with a thermal imager. This missile is sealed inside a tubular launcher and four of them are installed on the weapon station.

    Given the presence of electrical connectors on each launcher, another launcher can be placed on top of the previous one. As a result, the Majid Air Defense System will be able to use eight missiles.

    A graphic image of the Majid air defense system with 8 missiles (credit @marshallmo26 on X)

    The missile has four stabilizing fins at the end and four control fins near the nose cone. The fins on the missile are foldable, allowing the missile to be placed inside a canister.

    The Majid Air Defense System missile uses smokeless solid fuel. This type of fuel reduces the chance of detecting the launch site and increases the surprise of the enemy. Also, the AD-08 missile uses a thermal imaging camera at its nose cone, which guides and hits the target using this camera.

    The electro-optical system issues a firing command after detecting the target. The missile moves towards the point announced by the system and then searches for the target by the use of its camera, locks onto it, and moves towards the target to destroy it. This method is the same as the fire-and-forget method, and as a result, the system can move immediately after firing. The use of a passive or non-active detector and the main system’s capacity to avoid locking onto the aim misleads the target.

    The target will not be aware of thermal locking until the missile locks onto it. Also, being smokeless makes it impossible for the enemy to determine the path of movement of the missile and calculate information such as collision direction, speed, and so on to detect the launch location of the missile, which will take a long time.

    In addition to this fact, due to using fire-and-forget capability, it has quick relocation capability. Therefore, if an enemy uses a decoy to detect the location of the system, given the mentioned conditions, the Majid Air Defense System does not leave much trace for detection and greatly increases its survival.

    Types of Majid Air Defense System Missiles:

    After examining published images of missiles and Majid Air Defense System, it seems that there may have been two versions of this missile: The initial version of the Majid Air Defense System was seen in the test footage, and the second version was showcased at ARMY-2023 exhibition and Doha Qatar exhibition.

    Initial Version:
    The missile in the initial version has two sections in terms of diameter. The nose section has a smaller diameter, as well as the middle and end section, which have a larger diameter. A thermal camera is located in the nose cone, then there are control fins, warhead, and fuel compartment and in the end, there are stabilizing fins and engine are located at end.

    The prototype of the missile has a nose with a smaller diameter than the new model

    New Version:
    In the new or perhaps original version, the missile has three sections in terms of diameter. The location of the thermal camera is in the missile nose cone, which has the maximum diameter for placement in the canister. After that, there are control fins and a warhead, where the missile has a reduced diameter and appears to be the same as the original missile nose.

    After the warhead, the missile diameter increases from the middle to the end and it appears to be the same as the missile tip. This section contains missile fuel, stabilizing fins, and a missile engine, which seems to be the same as the initial version.

    Also, the final or original version of the missile has a uniform and integrated appearance generally in terms of body section and exterior. This missile has a different camera from the initial version in the camera section as well.

    The new version of the AD-08 missile, which missile diameter increases from the middle to the end

    The pictures below show the new model of the AD-08 missile, which was showcased for marketing at the Russian ARMY2023 exhibition. In the pictures, it is clear that a different camera is used than the prototype.

    Systems linked to Majid air defense system:

    Borhan weapons control and command system:
    As mentioned earlier, the Majid system has the capability of linking to the Borhan system. The Borhan system is a command and control center for low-range and low-altitude weapons, which acts as the last level of command to create integration between systems in the last layer of defense.

    This system can receive information from electro-optical and radar systems. After receiving and analyzing the information from all the sources, Burhan transfers them to the command and gives orders according to the type and nature of the target to all types of low-altitude systems available in the scene.

    An image of the linking of the Borhan and Majid systems

    Kashef 99 Radar:
    Kashef 99 radar is a 3D phased array radar capable of detecting small flying targets. This radar is designed to detect targets with low radar cross section, low altitude and short range such as quadcopters. Kashef 99 can simultaneously detect 300 targets within a range of 12 km.
    Kashef 99 is installed on a Toyota vehicle, which increases its mobility. It seems that there is a possibility of installing this radar on other vehicle as well. Due to the high power in detecting small birds, the Kashef radar is probably a part of the Battlefield Management System for the last layer of defense.

    Kashef 99 radar with the ability to detect 300 small drones at a distance of 12 km

    Prominent Features:
    – The speed and agility of the Majid Air Defense System
    – The ability to use various carriers
    – The Fire-and-forget capability
    – The Fire-and-forget capability
    – The use of smokeless missiles resulting in better camouflage
    – The ability to link with Borhan radar and system
    – The independent operation in ambush mode
    – The ability to operate within an integrated defense network
    – The ability to develop and enhance system capabilities

    Specifications of Majid short-range air defense system:
    Type: Short-range air defense system
    Producer: Ministry of Defense of the Islamic Republic of Iran
    Origin: Iran
    Unveiled: April 18, 2021
    In service: since 2021
    Crew: Unknown
    Carrier vehicle: Aras 2 tactical vehicle and Iveco Daily truck
    Weight: unknown
    System range: 18 km
    Range of engagement: 8 km
    Altitude of fire: 6 km
    Maximum target speed: Mach 2 (2450 km/h)
    Number of simultaneously engaged targets: 4 targets
    Response time: 3 seconds
    Battery: each battery capable of firing 4 missiles (can be increased to 8 missiles)

    AD-08 missile:
    Length: 2.67 meters
    Diameter: 156 mm
    Warhead weight: 14 kg
    Missile weight: 75 kg
    Range: 8 km
    altitude of fire: 6 km
    Guidance: Passive IR homing
    Speed: more than Mach 2

    Majid Short-Range Air Defense System – click to view full size

    More images of Majid short-range defense system:

    Infographics of Majid air defense system Russian(Маджид Система Защиты Ближнего Действия), Hebrew(מג’יד מערכת הגנה אווירית), Persian(سامانه مجید) and Azeri(Məcid Qısa Məsafəli Müdafiə Sistemi):

    Sources:
    سامانه پدافندی مجید رونمایی شد
    گزارش تسنیم از سامانه موشکی مجید؛ محافظ جدید مراکز حساس در برابر تهدیدات پهپادی و کروز
    ‘No radar evading aircraft can escape Alborz, a new Iranian radar’: Iran’s Air Defense
    «مجید» برگ برنده ایران در آخرین لایه پدافند هوایی
    AD-08 Air Defense Missile Weapon System
    Iran unveils its new AD-08 air defense missile system based on IVECO Daily 4×4 light truck

  • Military Knowledge: Karrar Main Battle Tank

    Military Knowledge: Karrar Main Battle Tank

    History:
    Due to Iran’s armored requirements and the increasing advancement of anti-armor weapons and armor technology throughout the world, there was a need for a tank at the level of modern tanks in the Islamic Republic of Iran Armed Forces. Despite allocation of limited budget, the armed forces embarked on upgrading the existing T-72S tank. Although in the past, Zulfiqar 1 and 3 tanks had been built as prototypes in the country, they were never widely adopted due to the inability to produce them in large numbers given the country’s budget limit.

    The Karrar tank was unveiled on March 12, 2017, in a ceremony attended by the then-Minister of Defense, General Hossein Dehghan. It was emphasized in the ceremony that the production line for the Karrar tank is also located in the Bani Hashem Armor Industrial Complex in Doroud County, Lorestan province. However, the introduction of this tank into service began slowly several years later. The production line was reopened in August 2020, and since then, the delivery process has been faster than before. The operational version of the Karrar tank differs from the unveiled version.

    Design:
    The Karrar tank features a welded and modern turret with a 125mm gun and a remote-controlled 12.7mm machine gun, as well as a coaxial 7.62mm machine gun.

    There are 12 smoke grenade launchers with an 81mm caliber on both sides of the turret, with six launchers on each side. The use of smoke grenades on both sides of the tank provides a larger range for creating smoke screens to disrupt laser-guided missiles

    12 grenade launchers installed on Karrar

    The Karrar tank includes a fire control system that consists of various components such as a muzzle reference system and a weather station. The muzzle reference system consists of two pieces, one at the beginning of the gun and one at the mouth of the gun, which detects the smallest angle of the gun that is not visible to the naked eye. As a result, the accuracy of direct gun fire is greatly increased.

    The weather sensors, by performing calculations on variables such as wind speed, humidity, air temperature, etc., increase the accuracy of ballistic shots. The Karrar tank uses a Vaisala WXT536 weather station belonging to a US company.

    The Karrar tank uses a day and night vision system in front and back of the tank. This system includes an IR/EO day and night vision camera in the front left window of the driver’s hatch and a day and night vision camera at the back of the tank between the external fuel tanks.

    The all-around surveillance system (360-degree periscope) of the commander of the tank is another available system on the Karrar tank. This system includes seven fixed periscope windows installed in the commander’s hatch. The all-around surveillance system provides the ability to install eight periscopes, but one of the positions is occupied by the remote-controlled machine gun base and it has been blinded, so no periscope is installed there.

    The Karrar tank utilizes a surveillance and targeting system for the gunner, which is located on the turret of the tank. The two doors of this surveillance system are manually operated and they do not have remote control. In addition, this surveillance and targeting system does not have a washer or snow remover, which is a major weakness. In war conditions, there is a possibility of dirt and snow accumulating on it, which will disrupt the performance of the surveillance and targeting system without a cleaning system.

    Karrar tank surveillance and targeting system collection

    Armament:
    As it was mentioned before, the main weapon of the Karrar tank is the 2A46 series 125mm cannon, which is the same cannon used in T72 and T90 tanks. This cannon can fire various anti-armor and anti-structure ammunition. It also has the ability to fire laser-guided missiles.
    The first version of the Karrar tank contained armor for the cannon, which was located at the connection point of the cannon to the body precisely on the cannon. The mentioned armor provided significant protection for the cannon against post-impact bullet cracks on the body.

    The secondary weapon of the Karrar tank is a remote-controlled 12.7mm machine gun. This weapon has its own day and night vision sight and is guided by the tank commander. It is not clear whether this machine gun can be independently guided by the gunner or not, but the possibility of its guidance by the tank gunner is not unlikely.

    Remote controlled 12.7 mm machine gun

    Armor protection:
    In addition to the main armor, the Karrar is also equipped with reactive armor in the front part of the chassis to protect itself. According to the available images, in this section, Karar uses Kontakt-1 reactive armors that are produced in Iran.

    Read more: Military Knowledge: Kontakt-1 Explosive Reactive Armour

    In this section, the Karrar tank uses 11 separating blades to separate the reactive armor blocks on the front slope of the chassis. In addition to separating the blocks from each other and preventing the transfer of explosive effects to the adjacent blocks, these blades also cause the blocks to be arranged more regularly. Because the effect of explosion of the reactive armor blocks (explosion wave, heat and shrapnel) is more lateral, the separation blades are also placed laterally.

    In side protection, the Karrar tank uses armor similar to the Relikt plates. This section is a combination of 5 layers: two middle layers of vulcanized rubber, two steel layers reinforcing the rubber layer and a thicker steel layer, which is the last layer closest to the tank.

    In terms of turret protection, the design is very similar to the T-90MS tank. In this section, reactive armors with more resistance and similar to Relikt or Kontakt-5 reactive armor are used. The main difference between the Karrar design and the T-90MS in this section is the dimensions of the reactive armor. These plates are installed on the turret with a steep slope, the thickness of which increases in the end part. The number of blocks used in the Karrar tank turret is 58. 32 blocks are located on the front and side of the turret, which use different dimensions, and 15 blocks are used to cover the side edges of the front slope of the roof and 11 blocks are used to cover the central part of the roof.

    The main challenge to fully cover the turret is related to covering the part connecting the gun to the turret, the armor used must be able to move up and down along with the gun. It seems that this part of Karrar tank does not have enough protection.

    Karrar tank uses cage armor (or slat armor) in the end parts of the body and turret. These armors cause early activation of the anti-armor missile warhead, and due to the distance they have from the main body and tank armor, it reduces the explosive effect of the missile warhead, which ultimately leads to a decrease in missile penetration. In addition to being cheap, this type of armor is a suitable option for use in areas that are less threatening, i.e. the back of the tank.

    In the rear part of the tank chassis, there are two barrel fuel tanks as external fuel tanks. This part of the tank does not have cage armor. The lack of armor in this section is due to three reasons: one is due to the low probability of hitting in open environment battles, and the second reason is the presence of external fuel tanks itself on Karrar, which does not allow the installation of cage armor, and the third reason is the possibility of cage armor hitting the ground and causing damages.

    It would have been better to install flexible cage armors based on the T72B3 tank. These armors can be moved in the presence of external fuel tanks, and when the fuel tanks are not installed, they provide the required protection for the tank. It is also possible to use armors that are flexible and do not have the problem of hitting the ground by modeling the cage armor of the Challenger-2 tank.

    One of the weaknesses of the T-72 series tanks, which is caused by its initial design, is the poor protection of the bottom part of the tank chassis. This issue still exists in the main chassis of the Karrar tank and no action has been taken to fix it. This issue becomes more important when we know that the tank’s main ammunition is stored in the floor of the chassis by means of the automatic loading system and in case of a mine explosion, the probability of the explosion of these ammunition is also very high. To fix this defect, this part can be strengthened by adding resistant and anti-shock plates in the front and lower parts, which are more sensitive.

    The bottom of the Karrar tank chassis, which does not have additional armor

    Protection system:
    Karrar tank uses a protection system with Soft Kill mechanism. This system, which is equipped with a laser beam detector and an infrared disruptor, includes four modules, in such a way that two modules are placed in the front part of the turret and two modules are placed in the rear part of the turret, and each one covers a specific angle.

    The laser beam detector used in the protection system module reacts to the radiation of the laser beam from the guidance system and to the laser beam of the range finder system and warns the crew. When the crew received the warning, they threw smoke grenades and created a smoke screen, causing disruption of the laser beam reflection from the tank body.

    The infrared disruptor used in the protection system module has a COB (Chip On Board) lamp with a 17×17 array. This system, by imitating xenon light radiation or thermal illuminator used at the end of anti-armor missiles, causes errors in missile guidance by the missile guidance system.
    This infrared disruptor has a general field of view of 60 degrees, a near infrared emission wavelength (Near IR), a preparation time of 60 seconds, a working continuity of up to 6 hours, a lifetime of 800 working cycles (each cycle includes 6 hours of work and one hour of shutdown), the power consumption is less than 80 watts and the working temperature is -20 to +55 degrees Celsius.

    This system is presented to disrupt the performance of missiles such as TOW and M47 Dragon or second generation armored missiles in general, but it will also be effective against missiles such as 9K111 Fagot, 9M113 Konkurs, etc. by making modifications.

    Karrar tank Soft Kill protection system

    Engine power and mobility:
    The maximum possible weight of the Karrar tank is stated to be 48.5 tons, and according to the evidence of the use of an engine with a power of 1000 horsepower on the tank, the ratio of power to weight of this tank is 20.6 horsepower per ton, as a result we see an increase in the mobility of the Karrar compared to the T72-S version.

    The type of Karrar tank engine has not been announced, but considering its 1000 horsepower and the fact that the T-90A model uses a V-92 engine with 1000 horsepower. It can be assumed that the Karrar tank engine is the same V-92 that was imported through Russia.

    Karrar tank specifications:
    Type: Main Battle Tank
    Produced: Since March 12, 2017
    Manufacturer: Bani Hashem Armor Industrial Complex
    Origin: Iran
    Length: 6.8 meters (hull) – 9.53 meters (with gun)
    Width: 3.6 meters
    Height: 2.23 meters (without remote-controlled gun)
    Mass: 46 to 48.5 tons (exact weight not announced)
    Crew: 3 (driver, commander and gunner)
    Engine: Enhanced engine with 1000 horsepower
    Speed: 60-70 km/h
    Operational range: 550 km (plus with 200-280 km more from fuel tank)
    Main armament: 125 mm 2A46M/M-2/M-5 smoothbore gun with stabilizer
    Secondary armament: Coaxial 7.62mm machine gun and a remotely controlled 12.7mm machine gun / 14.5mm machine gun

    Karrar Main Battle Tank – click to view full size image

    More images of Karrar tank:

    Infographics of Karrar tank in Russian(Каррар танк), Arabic, Hebrew(טנק קאראר), Azeri(Kərrar Tankı) and Farsi(تانک کرار):

    Sources:
    کرار” نخستین تانک پیشرفته ایرانی رونمایی شد + ویژگی‌ها و تصاویر
    مشخصات فنی تانک کرار که وزیر دفاع رونمایی کرد/تولید یکی از پیشرفته‌ترین تانک‌های دنیا
    تانک کرار

  • Infographic: US Air Attacks On Yemen

    Infographic: US Air Attacks On Yemen

    The USS Cole bombing was a suicide attack by al-Qaeda against USS Cole, a guided missile destroyer of the United States Navy, on 12 October 2000, while it was being refueled in Yemen’s Aden harbor. Seventeen US Navy sailors were killed and thirty-seven injured in the deadliest attack against a United States naval vessel since the USS Stark incident in 1987.

    After the Al-Qaeda attack on the US ship USS Cole in Aden port, and also the incident of September 11, 2001 in New York City, the then US administration concluded that it should take action against this terrorist group in Yemen as well as Afghanistan.

    Following former US president George Bush’s decision to start attacking Al-Qaeda in Yemen, the US military and security agencies in coordination with the then Yemeni government led by Ali Abdullah Saleh began their attacks in this country. These attacks continued after popular protests in Yemen and the downfall of Ali Abdullah Saleh’s government, and after such developments, the eight-year battle between the Ansar Allah movement and the Saudi-led coalition continued.

    According to Western media reports, the US has so far carried out 378 attacks, including aerial (by fighter jets and combat drones), missile and ground attacks in this Arab country, which has resulted in the deaths of 1,400 to 1,800 people. So far, a large part of the details and information about these 379 operations have not been published, and the following list has been compiled based on the information available about drone operations that have been reported so far. The operation list is as follows:

    1- The US MQ-1 Predator drone attack on the vehicle of al-Qaeda militants in Marib province, November 5, 2002. This attack resulted in the death of six members of al-Qaeda, including the leader Salim Sinan Al-Harethi, known as Abu Ali Al-Harethi (accused of helping to bomb the USS Cole in Aden).

    2- The mistaken attack of the American drone on a gathering in Wadi Obayda in Marib province on May 24, 2010. This attack, instead of an al-Qaeda rally, resulted in the death of five people, including Jaber al-Shabwani, the deputy governor of Marib province, who was mediating between the government and the militants. This murder caused the bloodshed of the Shabwani tribes and their conflict with the government forces. They also attacked an oil pipeline in Marib twice.

    3- The attack of the American drone on the car of two people suspected of being members of the Al-Qaeda group named Abdullah and Masad Mubarak on May 5, 2011. The aim of this attack was to kill Anwar al-Awlaki, a propaganda member of al-Qaeda, but he was not hit in this attack.

    4- The attack of the American fighter jet or drones on the residence of Ali Abdullah Naji al-Harethi, a member of al-Qaeda, and several other suspects, including Ammar Abadah Nasser al-Waili in Zanjibar city on June 3, 2011. Al-Harethi was one of the companions of Abu Musab al-Zarqawi in Iraq and al-Waili was present in the war in Afghanistan and was ordered by Bin Laden to establish a training camp in Saada.

    5- The attack of the American fighter jets or drones on a police station in the district of Mudiyah, located in the province of Abyan on July 14, 2011. The media and the Yemeni government at the time reported the casualties of this attack between 6 and 50 dead. Also, on the same day, the American drone targeted the car of Fahad al-Qasso, a senior member of al-Qaeda in Yemen, near the same area, and he survived the attack.

    6- The attack of American drones with the participation of Yemeni army fighter jets on Al-Qaeda positions in the areas of Al-Wahda, Al-Amoudi and Al-Khamila in Abyann province on August 1, 2011. As a result of these attacks, 15 militants suspected of being members of Al-Qaeda, including Nasser al-Shadadi, one of the senior members of Al-Qaeda, were killed and 17 others were wounded.

    7- American warplanes and drones attack suspected al-Qaeda positions in the outskirts of Zanjibar city in Abyan province on August 24, 2011. This attack killed 30 people and injured 40 others.

    8- The American fighter jet attack on a mountain pass in Abyan province on September 21, 2011, which resulted in the death of four Al-Qaeda members. At the same time, seven Al-Qaeda fighters were killed in the coastal city of Shuqra.

    9- American drone attack on Anwar al-Awlaki, one of the senior propaganda members of Al-Qaeda in Al-Jawf province on September 30, 2011. In addition to Al-Awlaki, three other people were killed in this attack, including Samir Khan, the American-born editor of Inspire magazine. This attack has been called the first attack in which the US military intentionally attacks its own citizens.

    10- American drone attack on al-Qaeda hideouts in the east of Zanjibar, the capital of Abyan province, on October 5, 2011. This attack resulted in the death of five Al-Qaeda members.

    11- American fighter jet or drone attack on an unknown mosque in Shabwa province on October 14, 2011. Some American media, quoting the Ministry of Defense of the Yemeni government at the time, claimed that seven Al-Qaeda members were killed in this attack, including Ibrahim Al-Banna, the media officer of Al-Qaeda (Egyptian origin), but this information is not correct, and currently the United States has offered a reward of 5 million to find Al-Banna.

    12- In another attack on October 14, 2011, the American drone assassinated the 17-year-old son of Anwar al-Awlaki along with eight other people in Shabwa province.

    13- American drone attack on the location of al-Qaeda members in the city of Jaar in Abyan province on December 22, 2011. In this attack, Abdulrahman al-Wahishi, a relative of Nasser al-Wahishi, the leader of al-Qaeda branch in Yemen, was killed along with eight others.

    14- American drone attack on the gathering place of Al-Qaeda members near Lowdar city in Abyan province on January 31, 2012. During this attack, 11 al-Qaeda members were killed, including Abdul Moneim al-Fatani, one of the perpetrators of the attack on the USS Cole in October 2000.

    15- The American drone attack on al-Qaeda’s hideout near Al-Bayda on March 9, 2012, which led to the death of Abdul Wahab al-Hamiqani, one of the local commanders of al-Qaeda, and 16 others.

    16- American drone attack on the gathering of al-Qaeda militants in the city of Jaar in Abyan province between March 9 and 11, 2012. This attack killed 20 people suspected of being members of Al-Qaeda group.

    17- American drone attack on Al-Qaeda weapons warehouse in Jaar city, between March 9-11, 2012. Three al-Qaeda members were also killed in this.

    18- An American drone attack on a vehicle carrying Al-Qaeda militants in Al-Bayda province on March 14, 2012, which resulted in the death of four Al-Qaeda members.

    19- American drone attack on the location of al-Qaeda militants in Lowdar city on April 11, 2012. This attack resulted in 14 deaths.

    20- An American drone attack on the residence of Muhammad Saeed Al-Amdeh (Gharib al-Ta’zi), one of the senior members of al-Qaeda, in Al-Samadeh region, between Marib and Al-Jawf provinces on April 22, 2012.

    21- American drone attack on the location of Fahd Muhammad Ahmed al-Qasu and another Al-Qaeda member in the south of Shabwah province on May 6, 2012.

    22- The attack of an American drone on a wedding ceremony in the Radaa area of Al-Bayda province on December 12, 2013, which led to the death of 15 civilians. The US claims that 9 to 12 Al-Qaeda militants were killed in this attack, and the claim that civilians were killed is not true.

    23- American drone attack on a car carrying two Al-Qaeda members in Al-Qatman area of Hadhramout province on January 8, 2014.

    24- American drone attack on the car of al-Qaeda militants in Al-Mifaa area in Shabwa province on March 3, 2014. This attack killed three Al-Qaeda members, and it is believed that Mujahid Jaber Saleh al-Shabwani was one of the dead.

    25- On April 20 and 21, 2014, American drones attacked al-Qaeda positions in southern Yemen, which, according to the Ministry of Defense of the resigned government of Yemen, led to the death of 22 members of this group.

    26- American drone attack on the location of Nasser Abdul Karim Al-Wahishi, one of the leaders of al-Qaeda in Hadhramaut province (probably Al-Mukalla city) on June 12, 2015.

    27- The attack of the American fighter or drones on the al-Qaeda camp in the Hajar region of Hadhramaut province on March 22, 2016. This attack led to the death of 40 to 50 members of this group.

    28- American drones attacked the government intelligence headquarters in Zanjibar city and other positions of Al-Qaeda members in the areas of Naqeel Al-Haila and Al-Hazan in Abyan province on March 27, 2016. The casualties of al-Qaeda in these attacks have been announced as eight.

    29- American fighter or drone attack on al-Qaeda positions in Shabwah province on October 4 and 18, 2016.

    30- American fighter or drone attack on the location of Al-Qaeda members in Marib on October 21, 2016. Five Al-Qaeda members were killed in this attack.

    31- The attack of American drones on unspecified areas in Al-Bayda province on January 21, 2017, which resulted in the death of three people. This attack was the first US airstrike in Yemen since the beginning of Trump’s presidency. The United States claims that one of the killed people, Abu Anis al-Abi, was one of the field commanders of al-Qaeda and two other members of this group, but local sources called them construction workers.

    32- On October 2, 2017, American drones and fighters carried out 30 attacks on al-Qaeda positions in the three provinces of Hadhramaut, Shabwa and Abyan.

    33- American drone attack on a car carrying al-Qaeda members in Shabwa province on July 6, 2018. This attack killed seven people.

    34- American drone attack on the location of Jamal al-Badawi, one of the agents of the Al-Qaeda attack on the USS Cole in Marib province on January 1, 2019.

    35- The attack of three American drones on al-Qaeda positions in Al-Bayda province on June 24, 2019. These attacks led to the death of 5 people suspected of being members of the Al-Qaeda group.

    36- The attack of American drones on Jo Al-Nasim area in Wadi Obeidah and an unspecified place in the administration of Obeidah located in Marib province on January 25, 2020. The attack on Obeidah resulted in the death of an unknown person.

    37- American drone attack on al-Hazmeh area in Marib province on January 27, 2020. During this attack, Abdullah al-Adani, a member of Al-Qaeda, was killed.

    38- An American drone attack on a car at the Al-Qaeda checkpoint in the village of Hassoun al-Mashrif in the administration of Wold Rabi in Al-Bayda province on January 29, 2020. America claims that it killed Qasim Al-Rimi, the leader of al-Qaeda in Yemen, in this attack.

    39- American drone attack on the car of al-Qaeda members on the eastern road of Marib on November 13, 2021.

    40- American drone attack on the gathering of Al-Qaeda members in a house in Al-Hadba area in the northeast of Marib city on November 30, 2022. This attack led to the death of several people, including Abi al-Khair Abdulwahid al-Najdi, the person in charge of engineering and making explosives of Al-Qaeda group. Also, Hassan al-Hazrami and Ahmad Zaki, other prominent members of al-Qaeda, were also wounded.

    41- An American drone attack on a vehicle carrying al-Qaeda militants near the Al-Haira gas station in the Al-Samada region on the Marib-Al-Abar road on January 30, 2023. In this attack, three occupants of the car were killed, including Yasir Abdullah Rashid Al-Amiri from the administration of Wasab Al-Ali in Dhamar province, Hossein Hadbol al-Makni (Hassan al-Hazrami) in charge of making bombs and explosives for al-Qaeda, and his brother Musa Hadbol (Mohed al-Hazrami).

    42- American drone attack on a house in Al Jalal area, located in the east of Marib city, on February 26, 2023. This attack led to the death of Hamad bin Hamoud al-Tamimi (Abd al-Aziz al-Adnani), a Sharia official and one of the prominent commanders of al-Qaeda in the Arabian Peninsula, and one of his bodyguards.

    43- American drone attack on a bus near Shaqman gas station in Hajba area, located in the south of Marib city on August 30, 2023.

    Out of these attacks, one attack was carried out during George W. Bush’s tenure, 185 operations during Barack Obama’s presidency, 188 operations during Donald Trump’s era, and five attacks during the Joseph Biden administration.

    It is worth mentioning that the main goal of the US attacks in Yemen was to prevent Al-Qaeda from gaining power in the Arab country. However, these attacks have not had any significant impact on the developments in Yemen, and Al-Qaeda still operates in the governorates of Hadhramaut, Shabwah, and Abyan. In contrast, the operations by Ansar Allah fighters in Saada, the northern governorate of Al-Bayda, Al-Jawf, Marib, and Sanaa have been more effective in combating terrorism in Yemen. Al-Qaeda terrorists’ presence in many of those areas has been eliminated for years.

    It should be noted that the decision to use Al-Qaeda terrorists in the war against Ansar Allah was made by Saudi Arabia and the United Arab Emirates (UAE). This shows that the United States had no problem with the decision until the ceasefire between the Saudi-led coalition and Ansar Allah movement was established. Following the developments, they resumed their attacks on Al-Qaeda elements, especially in Marib.

    Despite the direct attacks by the US, Al-Qaeda’s activities in Yemen continue, mainly concentrated in the governorates of Hadhramaut, Shabwah, and Abyan. They are heavily engaged in fighting with the militants affiliated to the Southern Transitional Council (STC) in northern Abyan and are trying to recruit more human resources in the Shabwah tribes. They have also disappeared into the desert areas of Hadhramaut. However, unlike their presence and influence in these areas, no area is entirely under their control. This situation has allowed them to maintain their presence in Yemen and keep their Takfiri rivals, especially ISIS, out of competition.

    Finally, it should be asserted that unlike southern separatists and other secessionist movements in Yemen, Al-Qaeda has a broader view of this region and aims to control the Arabian Peninsula. However, this issue is limited to threats by their senior officials in speeches and has not yet been practically realized. Perhaps this trend has led the United States to reduce its attention to Al-Qaeda’s presence in Yemen, and their attacks have become more of a security and symbolic measure.

    US Air Attacks On Yemen – click to view full size
  • Military Knowledge: Mohajer 10 Drone

    Military Knowledge: Mohajer 10 Drone

    Following the unveiling of the Mohajer-10 drone, in addition to adding a new member to the Mohajer drone series, a new UAV has also been added to Iran’s 2000-kilometer drone series, which will increase the diversity of drone product baskets and consequently increase the combat power of Iran’s armed forces.

    A video of the unveiling of the Mohajer-10 UAV and its flight test

    Design:
    Various organizations, including the Islamic Republic of Iran Army, the Qods Aviation Industries, and Iran Aviation Industries Organization (IAIO) have participated in the manufacturing of Mohajer-10 drone. According to one of the officials of the Ministry of Defence and Armed Forces Logistics, this drone has been designed and developed based on the needs announced by the armed forces, especially the ground and naval forces of the Islamic Revolution Guards Corps (IRGC) and the Islamic Republic of Iran Army.

    At the first glance, the fuselage of this drone has similarities to the United States’ MQ-9 Reaper fuselage. There are also similarities between the body of Mohajer-10 and Kaman 22 (UAV) of the Islamic Republic of Iran Army. The front part and the nose of Mohajer-10 drone is similar to Kaman 22, which is where satellite communication antenna is located.

    Similarity of nose between Kaman 22 and Mohajer 10

    Mohajer-10 drone also has a similar tail to Kaman 22 and uses a combination of three wings. Two V-shaped wings are located on top of the fuselage near the engine and a smaller wing is located under the body.

    Read more: Kaman 22 Combat Drone

    Similarity of the tail between Kaman 22 and Mohajer 10

    The main difference between Mohajer-10 and Kaman 22 is in the shape of their wings. In Kaman 22, wings have a special bend and twist in design but in Mohajer-10 wings have a simpler appearance and more stretch.

    The main point about Mohajer-10 is its landing gear. The rear landing gear on Mohajer-10 drone in the unveiled version is foldable like Shahed-129 drone landing gear. The rear and front landing gear on Mohajer-10 are folded backward and are placed inside the fuselage during flight. The folding landing gear reduces drag during flight, and it reduces fuel consumption and increases flight range.

    Similarity of the rear landing gear of Shahed-29 and Mohajer-10

    However, in a video released of test flight of Mohajer-10 drone, this drone uses fixed rear landing gear. This simple landing gear that was also used in Mohajer-6 drone consists of a metal wire buckle and a flexible holder. The way it works is that due to flexibility of landing gear, metal wire prevents excessive opening of landing gear and flexibility also reduces pressure on structure at the time of landing.
    Therefore, there are two possibilities: The first possibility is that the published video is related to the initial (prototype) and experimental version of Mohajer-10 and it has been completed later. And the second possibility is that the Mohajer-10 drone has two cheap and expensive versions. In the cheap version, it uses simple landing gear and weaker optics, and in the expensive version, it uses foldable landing gear and a stronger camera (the camera used in Shahed-149).

    The prototype version of the Mohajer 10 UAV that uses a fixed landing gear

    Mohajer-10 drone also has the ability to carry a parachute for emergency landing, which seems to have inherited this capability from Mohajer-6 drone. This emergency parachute is located in a separate location behind satellite equipment and its straps are tied in two sections at the tail of the drone and near the engine.

    The parachute for emergency landing

    Given the similarities among Mohajer-10 drone, Kaman 22 UAV and Shahed-129, as well as the participation of the Iranian army among the manufacturers and developers of Mohajer-10 drone, it seems that this drone has benefited from the experience of building capabilities of the IRGC and the Ministry of Defense; so, the cooperation provides Iran’s armed forces with a high-quality and affordable version of the drone series. Most likely, this drone will enter service in bulk in the IRGC and army by repeating the successful experience of Mohajer-6 drone, and it will replace Mohajer-6 and Shahed-129 drones.

    Dimensions:
    The dimensions and size of Mohajer-10 have not been officially announced, but based on available images, we can obtain the dimensions of Mohajer-10 drone. Based on images, which have been released so far, Mohajer-10 will have a length of 9 meters and a height of 2.4 meters, and its wing length will be 14 meters.

    Camera and sensor system:
    Mohajer-10 drone uses a high-quality camera that was previously used on Shahed-149 (Gaza) drone. This system, which is one of Iran’s most advanced electro-optical systems, has a thermal imaging camera and laser rangefinder in addition to a day vision camera with a zoom power of at least 100 to 120 times as well. One of the highlights of this system is the use of catadioptric telescopic lens that multiplies magnification. Using this camera will significantly increase the quality of filming and photography of drones, which is considered a great advantage. In general, electro-optical systems are considered one of the main parts or perhaps the most important part of the drone.

    Read more: Shahed-149 (Gaza) Reconnaissance Combat Drone

    The electro-optical systems and ammunition used in Mohajer-10 drone

    Armaments:
    Mohajer-10 drone has four hardpoints under its wings for carrying ammunition. This drone was carrying three Ghaem-5 precision-guided bombs with optical (TV) guidance, anti-armor Almas missile, and Arman guided air-launched bomb at the time of unveiling (image above). It seems that this drone can carry up to a maximum of eight bombs and missiles.

    Mohajer-10 can carry various types of Ghaem series bombs, various types of Sadid series bombs, Almas anti-armor missile, Arman air-launched glider bombs, and so on.

    Arman guided air-launched bombs are the latest type offered from this class of bombs that have been lightened and optimized for carrying by drones. Given the development of this drone on previous platforms such as Kaman-22 and Shahed-129, there is also a possibility to carry a wide range of weapons on Mohajer-10 such as: electronic warfare pods developed for Kaman-22 drone, Kaman-12 drone, Mohajer-6 drone, Sadid series bombs.

    4 hardpoints under the wings to carry up to 8 missiles and bombs

    Mohajer-10 drone has a flight endurance of 24 hours at an altitude of seven thousand meters and an operational radius of 2 thousand kilometers, and it benefits from a maximum speed of 210 kilometers per hour. The maximum fuel capacity of this drone is 450 liters and its maximum payload weight is 300 kilograms.

    Specifications of Mohajer-10 drone:
    Role: Combat and reconnaissance drone
    Unveiled: 22 August 2023
    Origin: Iran
    Producer: Qods Aviation Industries, and Iran Aviation Industries Organization (AIO)
    Length: 6.5 meters
    Height: 4.2 meters
    Wingspan: 18.2 meters
    Operational range: 2000 km
    Speed: 210 km/h
    Flight ceiling: 7000 meters
    Engine: Piston
    Maximum take-off weight: ~ 1000 kg
    Weapon payload: 300 kg
    Fuel weight: 450 kg
    Hardpoints: 4 under the wings, capable carrying up to 8 missiles and bombs
    Armament: Ghaem series bombs, Sadid series bombs, Almas anti-armor missile, Arman air-launched glider bombs, electronic warfare pods, etc.

    Mohajer 10 long-range drone – click to view full size

    More images of Mohajer 10 drone:

    Infographics of Mohajer 10 UAV in Russian(Мохаджир 10), Arabic(مهاجر 10), Farsi, Azeri(Mühacir 10) and Hebrew(מוהאג’יר 10):

  • Military Knowledge: AH-64 Apache Attack Helicopter

    Military Knowledge: AH-64 Apache Attack Helicopter

    History:
    In the Advanced Attack Helicopter (AAH) program, the United States Department of Defense wanted a helicopter with more firepower, performance and range than the AH1-Cobra, and the new helicopter should also be able to fly at a very low altitude (nap-of-the-earth). -NoE) as well. So the Apache helicopter was developed to replace the AH-1 Cobra helicopter.

    Proposals were submitted by Bell, Boeing Vertol/Grumman team, Hughes, Lockheed, and Sikorsky. In July 1973, the U.S. Department of Defense selected finalists Bell and Hughes Aircraft’s Toolco Aircraft Division (later Hughes Helicopters).

    Each company built prototype helicopters and went through a flight test program. Hughes’ Model 77/YAH-64A prototype first flew on 30 September 1975, while Bell’s Model 409/YAH-63A prototype first flew on 1 October 1975. After evaluating the test results, the Army selected Hughes’ YAH-64A over Bell’s YAH-63A in 1976. Reasons for selecting the YAH-64A included its more damage tolerant four-blade main rotor and the instability of the YAH-63’s tricycle landing gear arrangement.

    The AH-64A then entered phase 2 of the AAH program under which three pre-production AH-64s would be built, additionally, the two YAH-64A flight prototypes and the ground test unit were upgraded to the same standard. Weapons and sensor systems were integrated and tested during this time, including the laser-guided AGM-114 Hellfire missile. Development of the Hellfire missile had begun in 1974, originally known by the name of Helicopter Launched, Fire and Forget Missile (‘Hellfire’ being a shortened acronym), for the purpose of arming helicopter platforms with an effective anti-tank missile.

    In 1981, three pre-production AH-64As were handed over to the U.S. Army for Operational Test II. The Army testing was successful, but afterward it was decided to upgrade to the more powerful T700-GE-701 version of engine, rated at 1,690 shp (1,260 kW). The AH-64 was named the Apache in late 1981, following the tradition of naming Army helicopters after Native American tribes. It was approved for full-scale production in 1982. In 1983, the first production helicopter was rolled out at Hughes Helicopter’s facility at Mesa, Arizona.

    YAH-64A equipped with a Hellfire missile

    Hughes Helicopters was purchased by McDonnell Douglas for $470 million in 1984. The helicopter unit later became part of The Boeing Company with the merger of Boeing and McDonnell Douglas in August 1997. Today, MD Helicopters, a subsidiary of Boeing, is responsible for the production of AH-64 Apache helicopters.

    Since 1984, some aerospace companies such as AgustaWestland have produced a number of parts for the Apache. Teledyne Ryan Aeronautical was the manufacturer of the Apache fuselage, which was handed over to Korea Aerospace Industries in 2004. This change in fuselage manufacturer led to a long legal dispute between Teledyne Ryan and Boeing.

    Design:
    The AH-64 Apache has a four-blade main rotor and a four-blade tail rotor. The crew sits in tandem, with the pilot sitting behind and above the co-pilot/gunner. Both crew members are capable of flying the aircraft and performing methods of weapon engagements independently.

    The AH-64 is powered by two General Electric T700 turboshaft engines with high-mounted exhausts on either side of the fuselage. Various models of engines have been used on the Apache; those in British service use engines from Rolls-Royce. In 2004, General Electric Aviation began producing more powerful T700-GE-701D engines, rated at 2,000 shp (1,500 kW) for AH-64Ds.

    The crew compartment and rotor blades are designed to sustain a hit from 23 mm (0.91 in) rounds. The airframe includes some 2,500 lb (1,100 kg) of protection and has a self-sealing fuel system to protect against ballistic projectiles. This compartment also incorporates a transparent blast shield between the pilot and gunner seats so that at least one crew member can survive in the event of a direct hit, but the canopy and windows are otherwise unrated against ballistic threats.

    The aircraft was designed to meet the crashworthiness requirements of MIL-STD-1290, which specifies minimum requirement for crash impact energy attenuation to minimize crew injuries and fatalities. This was achieved through incorporation of increased structural strength, crashworthy landing gear, seats and fuel system.

    On a standard day, when temperatures are 59 °F (15 °C), the AH-64 has a vertical rate of climb of 1,775 feet per minute (541 m/min), and a service ceiling of 21,000 feet (6,400 m). However, on a hot day, when temperatures are 70 °F (21 °C), its vertical rate of climb is reduced to 1,595 fpm (486 m/min), and service ceiling is reduced to 19,400 feet (5,900 m) due to less dense air.

    One of the revolutionary features of the Apache was its helmet mounted display, the Integrated Helmet and Display Sighting System (IHADSS); among its capabilities, either the pilot or gunner can slave the helicopter’s 30 mm automatic M230 Chain Gun to their helmet, making the gun track head movements to point where they look.

    The M230E1 can be alternatively fixed to a locked forward firing position, or controlled via the Target Acquisition and Designation System (TADS). On more modern AH-64s, the TADS/PNVS has been replaced by Lockheed Martin’s Arrowhead (MTADS) targeting system.

    British Apache pilot with IHADSS

    U.S. Army engagement training is performed under the Aerial Weapons Scoring System Integration with Longbow Apache Tactical Engagement Simulation System (AWSS-LBA TESS), using live 30 mm and rocket ammunition as well as simulated Hellfire missiles. The Smart Onboard Data Interface Module (SMODIM) transmits Apache data to an AWSS ground station for gunnery evaluation.

    The gunner’s position in the AH-64D Longbow Apache.

    The AH-64’s standard of performance for aerial gunnery is to achieve at least 1 hit for every 30 shots fired at a wheeled vehicle at a range of 800–1,200 m (870–1,310 yd). British Apache pilot with IHADSS The AH-64 was designed to perform in front-line environments, and to operate at night or day and during adverse weather conditions.

    Various sensors and onboard avionics allows the Apache to perform in these conditions; such systems include the Target Acquisition and Designation System, Pilot Night Vision System (TADS/PNVS), passive infrared countermeasures, GPS, and the IHADSS.

    Additional avionics and sensor improvements includes an extended-range radar capable of detecting small ships in littoral environments, software adaptions to handle maritime targets, and adding Link 16 data-links for better communications with friendly assets.

    Variants:

    AH-64A:
    The AH-64A is the original production attack helicopter. The crew sit in tandem in an armored compartment. It is powered by two GE T700 turboshaft engines. The A-model was equipped with the −701 engine version until 1990 when the engines were switched to the more powerful −701C version.
    U.S. Army AH-64As are being converted to AH-64Ds. The service’s last AH-64A was taken out of service in July 2012 before conversion at Boeing’s facility in Mesa, Arizona. On 25 September 2012, Boeing received a $136.8M contract to remanufacture the last 16 AH-64As into the AH-64D Block II version and this was planned to be completed by December 2013.

    AH-64B:
    In 1991, after Operation Desert Storm, the AH-64B was a proposed upgrade to 254 AH-64As. The upgrade would have included new rotor blades, a Global Positioning System (GPS), improved navigation systems and new radios. U.S. Congress approved $82M to begin the Apache B upgrade. The B program was canceled in 1992. The radio, navigation, and GPS modifications were later installed on most AH-64As via other upgrades.

    AH-64C:
    Additional funding from Congress in late 1991 resulted in a program to upgrade AH-64As to an AH-64B+ version. More funding changed the plan to upgrade to AH-64C, which would include all of the changes to be included in the AH-64D except for mast-mounted radar and newer −700C engine versions. However, the C designation was dropped after 1993. With AH-64As receiving the newer engine from 1990, the only difference between the AH-64C and the AH-64D was the radar, which could be moved from one aircraft to another; thus the decision was made to simply designate both versions as AH-64D.

    AH-64D Apache Longbow:
    The AH-64D Apache Longbow is equipped with a glass cockpit and advanced sensors, the most noticeable of which being the AN/APG-78 Longbow millimeter-wave fire-control radar (FCR) target acquisition system and the Radar Frequency Interferometer (RFI), housed in a dome located above the main rotor.

    AN/APG-78 fire control radar mounted on the main rotor of an Apache helicopter

    The radome’s raised position enables target detection while the helicopter is behind obstacles (e.g. terrain, trees or buildings). The AN/APG-78 is capable of simultaneously tracking up to 128 targets and engaging up to 16 at once; an attack can be initiated within 30 seconds. A radio modem integrated with the sensor suite allows data to be shared with ground units and other Apaches, allowing them to fire on targets detected by a single helicopter.

    The aircraft is powered by a pair of uprated T700-GE-701C engines. The forward fuselage was expanded to accommodate new systems to improve survivability, navigation, and ‘tactical internet’ communications capabilities. In February 2003, the first Block II Apache was delivered to the U.S. Army, featuring digital communications upgrades. The Japanese Apache AH-64DJP variant is based on the AH-64D; it can be equipped with the AIM-92 Stinger air-to-air missiles for self-defense.

    Interior view of the AH-64D Apache Longbow helicopter and its radar screen

    AH-64E:
    Formerly known as AH-64D Block III, in 2012, it was redesignated as AH-64E Guardian. It has improved digital connectivity, the Joint Tactical Information Distribution System, more powerful T700-GE-701D engines with upgraded face gear transmission to handle more power, capability to control unmanned aerial vehicles (UAVs), full IFR capability, and improved landing gear. New composite rotor blades, which completed testing in 2004, increase cruise speed, climb rate, and payload capacity. Deliveries began in November 2011. Full-rate production was approved on 24 October 2012, 634 AH-64Ds will be upgraded into AH-64Es.

    Changes in production lots 4 through 6 include a cognitive decision aiding system and new self-diagnostic abilities. The updated Longbow radar has an oversea capacity, potentially enabling naval strikes; an AESA radar is under consideration. It will have a L-3 Communications MUMT-X datalink in place of two older counterparts, communicating on C, D, L, and Ku frequency bands to transmit and receive data and video with all Army UAVs. Lots 5 and 6 will have Link 16 data-links. The AH-64E is to be fit for maritime use. The U.S. Army expressed interest in extended-range fuel tanks for greater endurance. As of April 2020, 500 AH-64Es have been delivered.

    AH-64F:
    In 2014, Boeing conceptualized an Apache upgrade prior to the introduction of the U.S. Army’s anticipated attack version of the Future Vertical Lift (FVL) aircraft, forecast to replace the Apache by 2040. The conceptual AH-64F would have greater speed via a new 3,000 shp turboshaft engine from the Improved Turbine Engine Program, retractable landing gear, stub wings to offload lift from the main rotor during cruise, and a tail rotor that can articulate 90 degrees to provide forward thrust. In October 2016, the Army revealed they would not pursue another Apache upgrade to focus on funding FVL; the Army will continue buying the Apache through the 2020s until Boeing’s production line ends in 2026, then FVL is slated to come online in 2030.
    In 2014, Boeing conceptualized an Apache upgrade prior to the introduction of the U.S. Army’s anticipated attack version of the Future Vertical Lift (FVL) aircraft, forecast to replace the Apache by 2040. The conceptual AH-64F would have greater speed via a new 3,000 shp turboshaft engine from the Improved Turbine Engine Program, retractable landing gear, stub wings to offload lift from the main rotor during cruise, and a tail rotor that can articulate 90 degrees to provide forward thrust. In October 2016, the Army revealed they would not pursue another Apache upgrade to focus on funding FVL; the Army will continue buying the Apache through the 2020s until Boeing’s production line ends in 2026, then FVL is slated to come online in 2030.

    Compound Apache:
    In October 2018, Boeing began testing the AH-64E Block 2 Compound, a compound helicopter design which added a larger fixed wing and a pusher propeller to the Apache airframe to provide additional lift and thrust, respectively. In addition, the engine exhaust was redirected downwards. Collectively, the modifications were anticipated to improve speed to 185 kn (343 km/h; 213 mph), range to 460 nmi (850 km; 530 mi), payload to 5,900 lb (2,700 kg), and fuel economy. A 30% scale model completed wind tunnel testing in January 2019. The Compound Apache has been pitched as an interim replacement for the Apache before its replacement under the Future Vertical Lift program.

    Sea Apache:
    During the 1980s naval versions of the AH-64A for the United States Marine Corps and Navy were examined. Multiple concepts were studied with altered landing gear arrangements, improved avionics and weapons. The USMC conducted a two-week evaluation of the Apache in September 1981, including shipboard operation tests. Funding for a naval version was not provided; the USMC continued to use the AH-1.

    The Canadian Forces Maritime Command also examined naval Apaches. In 2004, British Army AgustaWestland Apaches were deployed upon the Royal Navy’s HMS Ocean, a Landing Platform Helicopter, for suitability testing; there was U.S. interest in the trials. During the 2011 military intervention in Libya, the British Army extensively used Apaches from HMS Ocean. In 2013, US AH-64Ds were tested on several U.S. Navy ships.

    Deployment and flight of the AH-64D helicopter from the helicopter carrier HMS Ocean

    Export Apaches:
    Several models have been derived from the AH-64A, AH-64D and AH-64E for export. The British-built AgustaWestland Apache (assembled from kits purchased from Boeing) is based on the AH-64D Block I with several different systems, including more powerful engines, folding rotor blades, and other modifications for operation from Royal Navy vessels.

    A picture of an AgustaWestland Apache on the landing pad of the helicopter carrier HMS Ocean

    Specifications of AH-64E Guardian helicopter:
    Role: Attack helicopter
    In service: since 1986
    Origin: USA
    Manufacturer: Boeing Defense, Space & Security
    Crew: 2
    Length: 14.68 meters
    Height: 4.72 meters
    Rotor diameter: 14.63 meters
    Engine: 2 General Electric T700-GE-701
    Speed: 279 km/h
    Ascent rate: 853 meters per minute
    Weight: 6838 kg
    Maximum take-off weight: 10432 kg
    Combat range: 480 km
    Maximum range: 1896 km
    Flight ceiling: 6096 meters
    Armament:
    1× 30mm M230 Chain Gun with 1,200 rounds
    4× hardpoints under the wings

    AH-64 Apache helicopter – click to view full size

    More pictures of the Apache attack helicopter:

    Infographics of Apache AH-64 attack helicopter in Arabic, Russian, Persian, Azeri and Kurdish:

    Sources:
    Boeing AH-64 Apache
    AH-64 Apache – Boeing
    ah64 apache attack helicopters

  • Military Knowledge: Toophan Anti-Tank Missiles

    Military Knowledge: Toophan Anti-Tank Missiles

    History:
    The Islamic Republic of Iran, as the first purchaser of the BGM-71 TOW missile in 1971, launched a repair and assembly line for BGM-71TOW and FGM-77A Dragon missiles in cooperation with Emerson Energy Systems and Hughes Missile Systems at the Iran Electronics Industries (IEI). In May 1975, the project of joint production of BGM-71TOW and AGM-65 Maverick missiles were stalled due to disagreements over pricing issue. Following the victory of the Islamic Revolution in 1979, negotiations were completely halted and the United States did not allow technology transfer to the Islamic Republic of Iran.

    During the Holy Defense (Iran-Iraq War of 1980 to 1988), the Islamic Republic had a great need for anti-tank missiles to counter the massive armor of the Ba’athist Iraqi army. Iran’s initial inventory of anti-armor missiles was TOW missiles, which was added to by purchasing Malyutka (9M14 Malyutka) missiles from the black market. The Iranian fighters were very satisfied with TOW missiles and they stated a success rate of 95%. Therefore, Iran proceeded to reverse engineer TOW missiles.

    The Toophan missile and the experiences gained from this missile were used in the Sadid-1 missile and afterward, this success continued in the Sadid and Ghaem precision-guided bomb families.

    Design:
    As stated, the Toophan missile is designed and manufactured based on the US-made BGM-71 TOW anti-armor missile. The Toophan anti-armor missile is packaged inside a disposable tube and this tube is loaded onto the launcher at the time of firing. Toophan can be fired from two types of ground-based and air-based missile launchers.

    The ground-based missile launcher is installed on various vehicles, armored personnel carriers, tanks and vessels and it consists of a tripod, electro-optic sight, missile-containing tube, and command center. The electro-optic sight consists of two lenses; one for the daytime camera to detect targets during the day and the other for thermal vision to track the xenon lamp at the end of the Toofan missile. The daytime camera can be replaced with a night vision or another thermal camera to detect targets at night as well.

    The Toophan anti-armor missile family uses semi-automatic command to line of sight (SACLOS) guidance. In this type of guidance, the operator must keep the camera on the target until the missile hits the target. The presence of a xenon lamp is for determining the position of the missile and in this way, the thermal lens determines the position of the missile and the main camera determines the position of the target and both pieces of information are sent to the control center (Digital Missile Guidance Set-DMGS); then, this center processes the received information. It sends the necessary commands for path correction via wire to the missile and the missile also corrects its path based on those commands.

    As mentioned, the Toophan missile has an air-based launcher platform. Some AH-1J International helicopters of the Islamic Republic of Iran Air Force have the ability to carry and launch TOW missiles, which are known as Tow-Cobra. This helicopter needs an electro-optic sight called M65 or Telescopic Sight Unit for firing TOW missiles, which has a 13x zoom capacity and is installed in the nose of the helicopter. This sight actually has the same application as an electro-optic sight mounted on a ground tripod. The helicopter’s electro-optic sight first targets and then aims, and also sends information needed for path correction via wire to TOW by tracking missiles. In Iranian Toophan variant, exactly these steps are observed.

    Electro-optical site installed on AH1-J helicopter

    Types of Toophan missiles:
    As it has been mentioned above, the Toophan missile family was planned to produce 11 types of missiles in the industries of the Ministry of Defense of the Islamic Republic of Iran, and we managed to find 10 specifications of the missiles, which are being explained underneath. Regarding the eleventh type of Toophan missile, we think it was a heavy upgrade based on the Spike model and the missile was renamed, which we will deal with at the end.

    Toophan Anti-Tank Missiles – click to view full size

    1- Toophan-1 missile:
    It is a reverse-engineered BGM-71 TOW version B missile. The US variant has a range of 3,750 km and a penetration rate of 430 mm, while the Iranian Toophan-1 missile has a range of 3,850 km and a penetration rate of 550 mm.

    Published specifications of Toophan-1

    Specifications of Toophan-1 missile:
    Maximum range: 3850 meters
    Minimum range: 70 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 18.5 kg
    Warhead weight: 3.6 kg
    Type of warhead: HEAT shaped-charge
    Package weight: 42 kg
    Missile length: 117 cm
    missile diameter: 15.3 cm
    Armor penetration rate: 550 mm

    2- Toophan-2 missile:
    Toophan-2 was developed with the aim of increasing penetration rate, And by adding a penetrating extended probe and a heavier two-stage warhead, it not only gained the power to penetrate 760 mm rolled armor, but also has the ability to pass through all types of reactive armor. The extended probe in Toophan 2 missile has a small warhead to destroy the reactive armor so that the main warhead engages with the main armor. The extended probe is inside the missile, after firing it comes out of the tube, opens and is placed in its place as the missile head.

    Published specifications of Toophan-2

    Specifications of Toophan-2 missile:
    Maximum range: 3850 meters
    Minimum range: 70 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 19 kg
    Warhead weight: 4.1 kg
    Type of warhead: Tandem HEAT shaped-charge
    Missile length: 117 cm
    Length of missile with the extended probe: 145 cm
    Missile diameter: 15.3 cm
    Armor penetration rate: 760 mm

    3- Toophan-2M missile:
    Iran’s defense industry sought to upgrade and develop the Toophan-2 missile, this led to the production of the Toophan-2M variant. This upgraded missile had the ability to penetrate 900 mm of armor. In the overall design of the Toophan-2 missile, the existence of an extended probe and a two-stage warhead has been preserved. The new missile has a larger nose diameter than its previous model due to carrying more explosives.
    The specifications of Toophan-2M have not been published in full, but due to its similarity with the Toophan-2 variant, its specifications can be guessed to some extent.

    The diameter difference between Toophan-2 and Toophan-2M missiles

    Specifications of Toophan-2M missile:
    Maximum range: 3850 meters
    Minimum range: 70 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 21 kg
    Warhead weight: 6.1 kg
    Type of warhead: Tandem HEAT shaped-charge
    Missile length: 117 cm
    Length of missile with the extended probe: 145 cm
    Missile diameter: 15.3 cm
    Armor penetration rate: 900 mm

    4- Toophan-3 top attack missile:
    Toophan-3 is a special member of the Toophan anti-armor missile family. This missile attacks armored targets from above and attacks the weakest point of tanks. Top Attack anti-armor missiles have two mechanisms, the first type is diving on the target and the second type explodes on top of the target, which Toophan-3 is of the second type.

    The Toophan-3 missile flies at a height of 2 to 3 meters above the ground and when it passes over the target, the missile’s sensors detect the target and give the command to detonate the Explosively Formed Penetrator (EFP) warhead. The EFP is a special type of shaped charge that deform a metal plate into a slug or rod shape and accelerate it toward the target.

    The advantage of using top attack missiles like Toophan-3 is that they can attack targets behind hills or obstacles.

    Toophan-3, like other members of the Toophan anti-armor family, uses line-of-sight guidance (SACLOS) and uses wires to transmit course correction information.

    Published specifications of Toophan-3. The picture also shows how Toophan-3 works.

    Specifications of Toophan-3 missile:
    Maximum range: 3500 meters
    Minimum range: 650 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 19.1 kg
    Warhead weight: 1.7 kg
    Warhead type: EFP
    Missile length: 117 cm
    Missile diameter: 15.3 cm
    Armor penetration rate: at least 80 mm in armor

    5- Toophan-3M top attack missile:
    Like the Toophan-3 missile, this missile is a top attack missile and uses the EFP warhead and SACLOS guidance. The range of this variant has increased to 3,750 meters and the minimum penetration power has increased from 80 mm to 150 mm.

    Specifications of Toophan-3M missile:
    Maximum range: 3750 meters
    Minimum range: 100 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 21.5 kg
    Warhead weight: 4 kg
    Warhead type: EFP
    Missile length: 117 cm
    Missile diameter: 15.3 cm
    Armor penetration rate : at least 150 mm in armor

    6- Toophan-4 missile:
    Toophan-4 is the first member of the Toophan anti-armor family that is equipped with a thermobaric warhead. This variant also uses SACLOS method for guidance. Toophan 4 missile was displayed for the first time at the Baghdad Defense Exhibition in 2017.

    Published specifications of Toophan-4 and how it works

    Specifications of Toophan-4 missile:
    Maximum range: 3750 meters
    Minimum range: 100 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 20 kg
    Warhead weight: 3.5 kg
    Warhead type: Thermobaric
    Missile length: 117 cm
    Missile diameter: 15.3 cm

    7- Toophan-5 missile:
    Like the Toophan-2 missile, Toophan-5 is designed to penetrate explosive reactive armor (ERA). This missile also has an extended probe containing explosives and a larger warhead to be able to penetrate reactive armor and pass through the main armor. But Toophan-5 uses a type of laser beam riding for guidance.
    Another difference between Toophan-5 and previous missiles is that it has three rows of fins, one row is located in the beginning of the missile and near its tip, and the other two rows are placed in the middle and end of the missile like other types of Toophan. The presence of this type of fins makes the missile react faster and make it more stable during flight. It seems that the main reason for using three fin rows is for its type of guidance.

    An image of the Toophan-5 missile, which clearly shows three rows of fins.

    Due to the type of guidance in Toophan-5 missile, a different launcher is used to fire and guide this missile. This launcher uses three types of lenses. One is for the day vision camera, which is used to find targets during the day. The second lens is for the thermal vision camera, which is used for targeting at night or for targeting after a smoke screen. The third lens is intended to shine the laser beam to the end of the missile during flight and guide it towards the target; This beam is irradiated to the center of the target selected by the operator.

    Special launcher for launching Toophan-5 missile

    It is worth mentioning that the wire guidance type of Toophan-5 missile was also displayed at the Baghdad International Exhibition in 2017, which indicates that the cheaper version the missile is also in production line.

    Specifications of Toophan-5 missile:
    Maximum range: 3500 meters
    Minimum range: 100 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 23 kg
    Warhead weight: 6.2 kg
    Type of warhead: Tandem HEAT shaped-charge
    Missile length: 117 cm
    Length of the missile with the extended probe: 145 cm
    Missile diameter: 15.3 cm
    Armor penetration: 900 mm

    8- Toophan-6 missile:
    Toophan-6 was first unveiled at the 2017 Baghdad International Exhibition. Like Toophan-4, this missile uses a thermobaric warhead and wire guidance. Toophan-6 uses a 5 kg warhead, but Toophan-4 uses a 3.5 kg warhead. This missile can be fired from the conventional tripods, all types of vehicles and helicopters.

    Specifications published about the Toophan-6 missile

    Specifications of Toophan-6 missile:
    Maximum range: 3500 meters
    Minimum range: 100 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 21 kg
    Warhead weight: 5 kg
    Warhead type: Thermobaric
    Missile length: 117.2 cm
    Missile diameter: 15.3 cm

    9- Toophan-7 missile:
    Toophan-7 is the third thermobaric member of the Toophan family, which was introduced after Toophan-4 with 3.5 kg and Toophan-6 with 5 kg of explosives. Toophan-7 with a thermobaric warhead and shrapnel fragment capability has 5.6 kg of explosives. The missile uses semi-automatic command-to-line-of-sight (SACLOS) guidance by wire.

    Specifications published about the Toophan-7 missile

    Specifications of Toophan-7 missile:
    Maximum range: 3500 meters
    Minimum range: 100 meters
    Effective range: 3.5 km
    Effective range at night: 2.5 km
    Missile weight: 21 kg
    Warhead weight: 5.6 kg
    Warhead type: thermobaric
    Missile length: 117 cm
    Missile diameter: 15.3 cm

    10- Ghaem anti-helicopter missile:
    Ghaem or Qaem anti-helicopter missile is a semi-heavy guided missile that is intended for use against UAVs and low flying or stationary helicopters. This missile looks very similar to the Toophan-1 missile and it is difficult to distinguish it.
    The exact specifications of this missile have not been revealed, but it is said that it’s a laser-guided missile and is resistant to electronic warfare.

    Ghaem anti-helicopter missile

    Ghaem-M missile:
    This missile, like the Ghaem missile, is an anti-helicopter missile and has the ability to destroy air targets with low speed and low altitude, especially attack helicopters. with the difference that this missile uses several proximity fuses that improve its performance. Also, in this variant, a fragmentation warhead with 500 shrapnels and a weight of 1.7 kg was used. These two changes have been made in order to cause more damage if the missile does not hit the target directly.
    In the published images, it seems that the engine gas output in the middle part of the missile has become larger, which indicates the possibility of using a larger engine to reach a range of 6 km. Also, there is a laser beam receiver at the end of the missile, which confirms the laser beam guidance method like Tofan-5 missile. Unfortunately, the altitude of fire is not mentioned in the published information about this missile. But if the altitude of fire is 5 km, it will be able to deal with most drones and helicopters.

    Specifications of Ghaem-M missile:
    Maximum range: 6000 meters
    Minimum range: 500 meters
    Missile weight: 19.5 kg
    Warhead weight: 1.7 kg
    Type of warhead: Fragmentation (500 shrapnels)
    Missile length: 116 cm
    Missile diameter: 15.3 cm
    Maximum speed: 310 meters per second
    Average speed: 240 meters per second

    11- Almas anti-tank missile:
    Almas missile is an anti-armor missile that has always been considered as an independent category. However, when it comes to looking at the configuration of the Almas anti-tank missile, we will realize the great similarity in the essence of the Almas missile and the Toofan missile. Both Toophan and Almas missiles have two rows of wings and an engine in the middle section, with hot gas from the engine coming out next to the middle wings.

    In Almas missile, the middle wings are closed forward while in Toophan missiles these wings are closed backward. In Almas missile, the middle wings have a simple shape, but in Toophan missile, the shape of the middle wings is special.

    Almas anti-tank missile is a top-attack missile with fire and forget capability. The guidance method of Almas missile is similar to the first type, using a camera on a tripod, tracking and targeting are accomplished and then the missile is fired towards a target and the missile independently goes towards the target and attacks it from above.

    It seems that with the addition of this generation and its very significant changes compared to the base model of Toophan, it was necessary to change its name and end the Toophan missile project.

    Almas fire-and-forget top attack missile

    More images of Toophan ATGMs:

    Infographics of Toophan anti-armor missiles in Arabic (صواريخ طوفان المضادة للدروع), Russian (Противотанковые ракеты Туфан), Kurdish, Azeri (Tufan Anti Zireh Raketləri), Persian (موشک ضد زره توفان) and Hebrew (טופאן טילים נגד טנקים):

    Source:
    Toophan
    Basic TOOPHAN & TOOPHAN 3-M (Top Attack) | Mindex (mindexcenter.ir)
    Iran’s Toophan anti-tank missile and its different types (iranpress.com)
    Toophan
    Anti-tank Iranian missile systems of the Tufan series (topwar.ru)
    Toophan
    اعلام رسمی دستیابی ایران به موشک ضد زره با سرجنگی «ترموباریک»

  • Infographic: Unidentified Gunmen Assassinate 366 People In South Syria In 2022

    Infographic: Unidentified Gunmen Assassinate 366 People In South Syria In 2022

    ISWNews Analysis Group – A media outlet affiliated to the militants active in the Arab country reported that the statistics on the killings of people in southern Syria, which have been released newly, show that about 366 Syrian soldiers plus former militants, and Syrian government officials and so on were killed all through 2022.

    The published statistics are as follows:
    1- Assassination of 186 members of the Syrian armed forces and allies.
    2- Assassination of at least 17 Syrian political officials
    3- Assassination of 56 former militants (people who joined the Syrian armed forces after the reconciliation plan)
    4- Assassination of 64 former militants (people who returned to normal life after the reconciliation plan and turned into civilians)
    5- Assassination of 26 members of terrorist groups such as ISIS, Free Syrian Army, and so on
    6- Assassination of 17 drug dealers

    It is worth mentioning that the southern regions Syria have always been susceptible to chaos, armed conflicts, assassination, and so on, because there have been dormant terrorist cells and the initial militants in those areas since the onset of foreign-backed war in the Arab country.

    The spread of assassination and insecurity in southern Syria has clearly affected economic activity and people’s lives; so, despite the fact that several years have passed, insecurity has not yet been completely eradicated. Therefore, the lack of a clear horizon for the end of insecurity is driving many residents of southern Syria to come to the conclusion that they have to migrate from their residential areas.

    Click to view full size image
  • Military Knowledge: Abu Mahdi Cruise Missile

    Military Knowledge: Abu Mahdi Cruise Missile

    The Abu Mahdi cruise missile was developed and built under the “Meshkat” project. The project Mashkat is a project in which the Russian KH-55 cruise missile was reverse engineered by Iran; And based on that, at first the Ya-Ali cruise missile with a range of 700 km, then the cruise missiles Soumar with a range of 700 km, Hoveyzeh with a range of more than 1,300 km and finally an anti-ship cruise version named “Abu Mahdi” with a range of more than 1,000 km were made. The Meshkat project has another long-range cruise missile that has not been officially unveiled and there are no pictures of it.

    Abu Mahdi cruise missile is the first Iranian naval cruise missile with a range of 1000 km, which can be used against both sea and land targets, And can be launched from the fixed and mobile ground launchers and warships. Therefore, this missile with such a range is considered among the strategic cruise missiles.

    It is worth noting that few countries have the ability to domestically manufacture such a cruise missile in this range and more ranges, and other countries have to pay exorbitant costs to purchase this type of strategic cruise missile. For example, Russian Kalibr, the US’s Tomahawk and French MdCN cruise missiles are included in this category.

    History:
    The long-range cruise missile “Martyr Abu Mahdi Al-Muhandis” was unveiled for the first time together with ballistic missile “Martyr Haj Qasem” in August 20, 2020, on the occasion of Iran’s Defense Industry Day. At the unveiling ceremony, Amir Hatami, the then Minister of Defense, stated that the range of this cruise missile is more than 1000 km.

    At the time of the unveiling, a video of the test-fire of the Abu Mahdi missile was published, with the words “Talaiyeh” written on it. According to the process of naming cruise missiles from Soumar, Hoveyzeh and then Paveh, using the names of war zones of the Iraq-Iran war on Iranian ground cruise missiles is a common practice in Iran. However, with the martyrdom of this prominent resistance commander, Abu Mahdi Al-Muhandis, Iran put the name of this martyr on the country’s first land-attack cruise missile.

    A picture of Abu Mahdi cruise missile test-fire in 2020 with the name of Talaiyeh written on it

    This missile with changes in the engine section and with a new name was unveiled again on July 25, 2023 during a ceremony and its mass production line was officially opened by the Ministry of Defense of Iran. Also, in this ceremony, the Abu Mahdi missile officially entered the service of the IRGC and Army combat units.

    Design:
    Abu Mehdi long-range cruise missile has used the features of Soumar and Hoveyzeh cruise missiles in its design. According to the published images, different parts of the Abu Mahdi missile can be examined as follows

    Different parts of Martyr Abu Mahdi long-range cruise missile

    The main radar of the missile is located in the nose, and after the radar, a compartment or cabin is intended for the computer.

    After the radar is the warhead, which is indicated by the words WARHEAD CABIN on the missile. Abu Mahdi cruise missile uses a penetrating warhead with a 410-kilogram high-explosive warhead that can cause a lot of damage to the target.

    After the warhead, there is a ground detection radar and other missile guidance systems.

    In the middle section, the missile wings and the fuel tank are located. This missile has folding wings structure that allow it to be placed inside the sea and land launch containers. The Abu Mehdi’s wings use a square design with a round tip, which is completely identical to the previous design.

    The fuel tank and the wings are placed in one part, and the fuel tank extends to the missile engine, And the engine is placed under the missile. At the time of the initial unveiling in August 2020, the Abu Mehdi’s engine was similar to the Hoveyzeh cruise missile engine; But in the version that was unveiled in 2023 and has reached mass production, a different engine is used. The name of this engine has not been officially announced, but it can be assumed that this engine is an optimized turbojet engine (probably Tolou type) with the same flight conditions as the initial unveiling model.

    The engine difference between the prototype version and the mass-produced version of the Abu Mahdi cruise missile

    At the end of the missile, there are control fins and rocket booster. The control fins are responsible for changing the direction of the missile. The Abu Mahdi cruise missile uses a large booster with retractable mesh stands like the Hoveyzeh and Soumar models.

    Close-up video of the Abu Mahdi missile and its launcher box
    A video of the test-fire of the Abu Mahdi cruise missile from the ground mobile launcher and testing the guidance and accuracy of this missile

    In the case of the Abu Mahdi missile, considering the high range of the missile and the fact that it engages with sea targets that are mobile, two issues are very critical. The first issue is the initial detection of the target and the second issue is guiding the missile towards the moving target.

    Detecting the target in the sea and correcting the missile’s flight path in relation to the moving target:
    Abu Mehdi cruise missile has a range of 1000 km, which definitely takes more than an hour to travel such a distance. Considering that this cruise missile is designed based on the KH55 missile and the KH55 has a speed of about 700 km/h, then the Abu Mehdi cruise will probably have a speed approximately equal to this missile, and this means that it will take about 85 minutes to travel a distance of 1,000 km. If a ship is traveling at 32 knots (about 60 km/h), then it has moved about 85 km from its initial location since the missile was fired, and finding such an object is beyond the capabilities of the missile’s small seeker radar.
    One of the method to solve this problem is to use helicopters, fighter jets, fast boats or drones. All these items are at risk of discovery and destruction. However, the use of stealthy drones such as Shahed-171 greatly increases the probability of success in detecting and chasing the vessel.

    Read more: Shahed 171 (Simorgh) And Shahed Stealth Drones Family

    Another method is to use spy satellites to discover the primary and the secondary position of the target. It is also possible to track the radar by the radars of surface vessels and coastal radars. It is also possible to use the radars of surface vessels and coastal radars to track the target.

    Missile guidance systems

    1- The main seeker and radar:
    RADAR HATCH is written on the nose of the missile. This brings to mind that the main radar can be accessed through this hatch and it is possible to change the mode of the radar; In other words, this hatch is for the radar adjustment and checkup.
    This missile uses active radar homing (ARH) and passive radar (PRH). It is also possible to use both modes. For example, the missile can use the passive mode until it approaches the target and use its active radar mode when it is near the target.

    Radar hatch on the nose of missile

    In another image, there is a hatch with the words ATB CABIN. This hatch is for access to the radar processor. Also, this cabin has a small air intake for cooling.

    Air intake and radar processor cabin on Abu Mahdi missile

    – Active radar homing (ARH):
    It is a missile guidance method in which the missile containing a radar transceiver and its special computer independently tracks the target in the final stage of guidance. In this method, the missile is sent to the target position, and if the target characteristics are changed, new characteristics are sent to it along the way.
    Considering Abu Mahdi’s range of 1000 km, this radar method will be active during target detection, which is suitable for attacking land targets and sea targets. Of course, this radar can also help the flight system during the flight.

    – Passive radar homing (PRH):
    Passive radar is a radar systems that detect and track objects by processing reflections from non-cooperative sources of illumination in the environment. Passive radar is not able to produce radar waves, but this type of radar has the ability to detect the sources of the waves and allows it to attack the radar of air defense systems. Missiles with passive radars are very hard to detect, but easier to break their locks. These types of radars require very powerful computers to be able to separate and process a large amount of environmental waves.
    In the case of the Abu Mahdi missile, due to the lack of sufficient space, there is only the possibility of having a small advanced computer to detect the radar waves and its propagation direction, which can be used to attack radar targets.

    According to the published video of Abu Mahdi cruise missile test, several corner reflectors are used in the upper part of the target, which is to engage the missile’s radar, and the missile finally hits the middle part of the metal structure, which is completely similar to the performance of conventional anti-ship cruise missiles. High accuracy of hitting the target is seen in the tests.

    The corner reflector on the dummy target and the point where the missile hits the middle of the dummy target

    This method of target detection was also used for anti-ship missiles such as Ghadir, Ghadr, Kosar, etc. In this method, the missile finds the target using its search radar and then scans the target and finds the middle part of the target and attacks it. This collision causes maximum damage to the vessels, which ultimately leads to the vessel being split in half and sinking.

    2- Inertial guidance:
    An inertial navigation system (INS) is a navigation device that uses motion sensors (accelerometers), rotation sensors (gyroscopes) and a computer to continuously calculate by dead reckoning the position, the orientation, and the velocity (direction and speed of movement) of a moving object without the need for external references, which keeps the position of the missile on its right path.

    3- GPS guidance:
    In this method, the missile is guided to the target using the Global Positioning System (GPS). This system, along with the inertial guidance system, can greatly increase the accuracy of the missile. The accuracy of some types of missile with this type of guidance reaches an accuracy of less than 1 meter. It is also possible for Abu Mahdi to access GLONASS and BeiDou navigation systems, which is the Russian and Chinese version of GPS.

    4- TERCOM system:
    Terrain contour matching or TERCOM uses a contour map of the terrain that is compared with measurements made during flight by an on-board radar altimeter. A TERCOM system considerably increases the accuracy of a missile compared with inertial navigation systems (INS). The increased accuracy allows a TERCOM-equipped missile to fly closer to obstacles and at generally lower altitudes, making it harder to detect by ground radar.
    Topographical maps are very accessible today because they are used for commercial purposes and Abu Mehdi takes advantage of this.


    In the lower part of the Abu Mahdi missile, a part with a different shape and material can be seen, which seems to be the location of the altimeter radar or terrain detection. This radar is responsible for a part of the mission for guiding the missile along with the INS, And it significantly increases the accuracy of the missile.

    Terrain detection radar located in the lower part of the missile

    The technical specifications of the Abu Mahdi long-range cruise missile have not been officially announced, but considering the family of missiles in project Meshkat, and also the technical specifications of the KH55 cruise missile, it is possible to accurately estimate the specifications of the Abu Mahdi cruise missile, which we will mention below.

    Abu Mahdi cruise missile specifications:
    Type: Land-attack and anti-ship cruise missile
    Unveiled: 20 August 2020
    Origin: Iran
    Manufacturer: Aerospace Industries Organization (AIO)
    Length: 600 cm
    Wingspan: 310 cm
    Diameter: 55 cm
    Weight: 1650 kg
    Warhead: 410 kg HE
    Accuracy: 3 meters CEP
    Range: more than 1000 km
    Flight altitude: under 50 meters
    Guidance: GPS/INS – TERCOM – ARH/PRH
    Engine: Turbojet
    Speed: about 700 km/h
    Launch platform: Fixed and mobile ground launchers and ships

    Abu Mahdi long-range cruise missile – click to view full size

    More pictures of the Abu Mahdi cruise missile:

    Abu Mahdi cruise missile infographic in Persian (موشک کروز ابومهدی), Russian (крылатая ракета Абу Махди), Arabic, Hebrew (טיל שיוט אבו מהדי), Chinese (阿布·马赫迪 巡航导弹), Azeri (Raketi Əbu Mehdi) and Kurdish (موشەکی کروز ئەبومەهدی):

    Source:
    Kh-55

    Inertial navigation system
    TERCOM
    رونمایی ایران از موشک‌های حاج قاسم و شهید ابومهدی
    آیا موشک «ابومهدی» همان موشک «هویزه» است؟

  • Military Knowledge: M142 HIMARS Multiple Rocket Launcher

    Military Knowledge: M142 HIMARS Multiple Rocket Launcher

    The M142 HIMARS (High Mobility Artillery Rocket System) is a light multiple rocket launcher developed in the late 1990s for the United States Army and mounted on a standard United States Army Family of Medium Tactical Vehicles (FMTV) truck frame. The HIMARS carries one pod with either six Guided Multiple Launch Rocket System (GMLRS) rockets or one Army Tactical Missile System (ATACMS) missile. It is based on the United States Army’s FMTV five-ton truck, and is capable of launching all rockets specified in the Multiple Launch Rocket System Family of Munitions (MFOM). HIMARS ammunition pods are interchangeable with the M270 MLRS; however, it is limited to a single pod as opposed to the standard two for the M270 and its variants. HIMARS rocket system has the ability to launch rockets and precision guided missiles.

    History:
    The requirement for HIMARS first came about in 1982, when the 9th Infantry Division (Motorized) saw the need to acquire a light multiple rocket launcher as a counterfire asset. The requirement failed to gather support from the Field Artillery School and languished for a number of years. With the waning of the Cold War and the growing interest in low-intensity operations, both the Field Artillery School and Missile Command realized that the M270 MLRS was too heavy for rapid deployment and pushed for the funding of HIMARS. The Gulf War gave new impetus towards fielding a lightweight MLRS, when the M270 proved too costly in airlift assets to deploy in theater and the launchers did not arrive with the initial wave of U.S. troops.

    The HIMARS concept was tested on April 1991 at White Sands Missile Range, using a modified Honest John launcher. Proof-of-concept prototype of HIMARS at White Sands Missile Range, April 1991 HIMARS was then developed as a private venture by Loral Vought Systems, later Lockheed Martin Missiles and Fire Control, to meet this requirement. The system first appeared publicly in 1993.

    Honest John rocket and its launcher

    In 1996, the U.S. Army Missile Command awarded Lockheed Martin a $23.2 million contract to build four prototypes. The vehicles were delivered to the XVIII Airborne Corps in April 1998 for a two-year evaluation with 3rd Battalion, 27th Field Artillery Regiment. In July 1998, the Army conducted a test firing of the ATACMS.

    In December 1999, the Aviation and Missile Command awarded Lockheed Martin a $65 million contract for engineering and manufacturing development. Under this contract, Lockheed Martin delivered six HIMARS in late 2001 for Army evaluation.

    In April 2003, the Army awarded Lockheed Martin a $96 million contract to begin low rate initial production. Around this time, the Marine Corps placed an order for two units for evaluation purposes.[16] The launcher system and chassis are produced by Lockheed Martin Missiles & Fire Control in Camden, Arkansas as of 2019.

    Design:
    The HIMARS is similar in design to the M270 Multiple Launch Rocket System (MLRS), with the main exception being that it is a wheeled vehicle as opposed to a tracked vehicle. HIMARS uses a 6×6 armored vehicle with high mobility and a total weight of 16,250 kg, but the M270 uses an armored vehicle with a total weight of 24,040 kg. M270 has two ordnance pods capable of carrying 12 GMLRS rockets or 2 ATACMS missiles or a combination of these two types. While HIMARS has an ordnance pod capable of carrying 6 GMLRS rockets or one ATACMS missile.

    The FMTV truck was originally manufactured by Armor Holdings. Until 2007, this company was bought by BAE Systems Mobility & Protection Systems, and this British company, as the main producer of FMTV parts, was fully producing these trucks until 2010. Then, from 2010 to 2017, the FMTV truck was produced and sold by Oshkosh. But since 2017, these trucks are assembled and produced by Lockheed Martin Missiles and Fire Control (MFC).

    This truck uses a Caterpillar 3115 ATAAC engine with 290 horsepower, which allows it to reach a speed of 85 km/h. The maximum range of this truck is 480 km.

    As mentioned earlier, HIMARS uses a launcher module with an integrated crane to load different ordnance pods, which can carry multiple pods depending on the ammunition it fires. This crane, which requires two crews, loads a new pod within 4-5 minutes. HIMARS launcher has three crew including driver, gunner and commander.

    HIMARS and crane, launcher module and six rocket pods

    Armament:
    The HIMARS is capable of carrying and firing conventional rockets, precision-guided artillery rockets, as well as its own missiles that are in the US arsenal. These items include the following munitions:

    MLRS:
    Multiple launch rocket system (MLRS) rockets are a set of 227 mm rockets. This type of rockets have very low accuracy. The types of MLRS rockets are:

    • M26 rockets carrying 644 DPICM M77 submunitions. Range: 15–32 kilometres.
    • M26A1 ER rockets carrying 518 M85 submunitions. Range: 15–45 kilometres.
    • M26A2 ER rockets carrying 518 M77 submunitions. Range: 15–45 kilometres.
    • AT2 German M26 variant carrying 28 AT2 anti-tank mines. Range: 15–38 kilometres.
    • M28A1 Reduced-Range Practice Rocket (RRPR) with blunt nose. Range reduced to 9 km.
    • M28A2 Low-Cost Reduced-Range Practice Rocket (LCRRPR) with blunt nose. Range reduced to 9 km.

    GLSDB:
    The GLSDB is a ground-launched low-diameter precision munition. This bomb is a combination of the M26 rocket and the GBU-39 SDB, which was developed and produced by SAAB and Boeing. The Ground Launched Small Diameter Bomb (GLSDB) is a weapon that allow Boeing’s GBU-39 Small Diameter Bomb (SDB), originally developed for use by aircraft, to be ground-launched from a variety of launchers and configurations. It combines the SDB with the M26 rocket, enabling it to be launched from ground-based missile systems such as the M270 Multiple Launch Rocket System and M142 HIMARS. The range of this precision-guided munition is 150 km.

    Read more: Military Knowledge: Ground Launched Small Diameter Bomb

    GMLRS:
    Guided Multiple Launch Rocket System (GMLRS) 227mm rockets have an extended range and add GPS-aided guidance to their Inertial Navigation System. As of 1 December 2021 50,000 GMLRS rockets have been produced, with yearly production now exceeding 9,000 rockets.

    • M30 rockets carrying 404 DPICM M101 submunitions. Range: 15–92 km. 3,936 produced between 2004 and 2009, production ceased in favor of the M30A1. The remaining M30 rockets are being updated with either the M30A1 or M31A1 warhead.
    • M30A1 rockets with Alternative Warhead (AW). Range: 15–92 km. GMLRS rocket that replaces the M30’s submunitions with approximately 182,000 pre-formed tungsten fragments for area effects without unexploded ordnance. Entered production in 2015.
    • M30A2 rockets with Alternative Warhead (AW). Range: 15–92 km. Improved M30A1 with Insensitive Munition Propulsion System (IMPS). Only M30 variant in production since 2019.
    • M31 rockets with 91 kg high-explosive unitary warhead. Range: 15–92 km. Entered production in 2005. The warhead is produced by General Dynamics and contains 23 kg of PBX-109 high explosive in a steel blast-fragmentation case.
    • M31A1 rockets with 91 kg high-explosive unitary warhead. Range: 15–92 km. Improved M31 with new multi-mode fuze that added airburst to the M31’s fuze point detonation and delay.
    • M31A2 rockets with 91 kg high-explosive unitary warhead. Range: 15–92 km. Improved M31A1 with Insensitive Munition Propulsion System (IMPS). Only M31 variant in production since 2019.
    • ER GMLRS rockets with extended range of up to 150 km. Rockets use a slightly increased rocket motor size, a newly designed hull, and tail-driven guidance while still containing six per pod. It will come in unitary and AW variants. The first successful test flight of an ER GMLRS occurred in March 2021. Lockheed Martin anticipates adding the ER to its production line in the fiscal year 2023 contract award, and is planning to produce the new rockets at its Camden facility. Full operational capability is planned for 2025.

    ATACMS:
    The Army Tactical Missile System (ATACMS) is a series of 610 mm surface-to-surface missile (SSM) with a range of up to 300 km. Each rocket pod contains one ATACMS missile. As of 2022, only the M48, M57, and M57E1 remain in the US military’s arsenal.

    • M39 (ATACMS BLOCK I) missile with inertial guidance. The missile carries 950 M74 Anti-personnel and Anti‑materiel (APAM) bomblets. Range: 25–165 km. 1,650 M39 were produced between 1990 and 1997, when production ceased in favor of the M39A1. During Desert Storm 32 M39 were fired at Iraqi targets, and during Operation Iraqi Freedom a further 379 M39 were fired. The remaining M39 missiles are being updated to M57E1 missiles. The M39 is the only ATACMS variant, which can be fired by all MLRS and HIMARS variants.
    • M39A1 (ATACMS BLOCK IA) missile with GPS-aided guidance. The missile carries 300 M74 APAM bomblets. Range: 20–300 km. 610 M39A1 were produced between 1997 and 2003. During Operation Iraqi Freedom 74 M39A1 were fired at Iraqi targets. The remaining M39A1 missiles are being updated to M57E1 missiles. The M39A1 and all subsequently introduced ATACMS missiles can be used only with the M270A1 (or variants thereof) and the HIMARS.
    • M48 (ATACMS Quick Reaction Unitary; QRU) missile with GPS-aided guidance. The missile carries the 230 kg WDU-18/B penetrating high explosive blast fragmentation warhead of the US Navy’s Harpoon anti-ship missile, which was packaged into the newly designed WAU-23/B warhead section. Range: 70–300 km. 176 M48 were produced between 2001 and 2004, when production ceased in favor of the M57. During Operation Iraqi Freedom 16 M48 were fired at Iraqi targets; a further 42 M48 were fired during Operation Enduring Freedom. The remaining M48 missiles remain in the U.S. Army and US Marine Corps’ arsenal.
    • M57 (ATACMS TACMS 2000) missile with GPS-aided guidance. The missile carries the same WAU-23/B warhead section as the M48. Range: 70–300 km. 513 M57 were produced between 2004 and 2013.
    • M57E1 (ATACMS Modification; MOD) missile with GPS-aided guidance. The M57E1 is the designation for upgraded M39 and M39A1 with re-grained motor, updated navigation and guidance software and hardware, and a WAU-23/B warhead section instead of the M74 APAM bomblets. The M57E1 ATACMS MOD also includes a proximity sensor for airburst detonation. Production commenced in 2017 with an initial order for 220 upgraded M57E1. The program is slated to end in 2024 with the introduction of the Precision Strike Missile (PrSM), which will replace the ATACMS missiles in the US arsenal.

    PrSM:
    The Precision Strike Missile (PrSM) is a new series of GPS-guided missiles, which will begin to replace ATACMS missiles in 2024. PrSM carries a newly designed area-effects warhead and has a range of 60–499 km. PrSM missiles can be launched from the M270A2 and the HIMARS, with rockets pods containing 2 missiles. As of 2022 the PrSM is in low-rate initial production with 110 missiles being delivered to the US military over the year. PrSM will enter operational service in 2023.

    The set of rockets and missiles used in two systems M142 HIMARS and M270 MLRS

    HIMARS orders and delivery:
    In January 2000, Lockheed Martin was awarded an EMD (Engineering and Manufacturing Development) contract to provide six HIMARS launchers. Two more HIMARS launchers were ordered under a two-year user evaluation program for the US Marine Corps.

    The US Army and Marine Corps signed a Low Rate Initial Production (LRIP) contract in March 2003 for 89 launchers for the Army and four launchers for the USMC. In January 2004, a second LRIP contract was awarded for 25 launchers for the Army and one for the USMC. A third contract involving 37 launchers for the Army and one launcher for the USMC was signed in January 2005. A total of 900 launchers are planned to be purchased by the United States Army.

    In September 2006, the United Arab Emirates submitted a Foreign Military Sales (FMS) request for 20 HIMARS launchers with ammunition including 101 ATACMS block 1A missiles and 104 MLRS rockets, along with 130 GMLRS and 130 GMLRS single rocket pods. The first unit was delivered at the end of 2009.

    In January 2007, Lockheed Martin awarded another contract for 44 HIMARS systems for the US Army and 16 systems for the USMC.

    The United States announced the proposed sale of 18 HIMARS launchers plus 32 GMLRS pods and 30 MLRS practice rocket pods to Singapore in 2007. The first HIMARS launcher was delivered in July 2010 and entered service with the Singapore Armed Forces (SAF) in September 2011.

    In January 2011, the US Army awarded a $139.6 million contract to Lockheed Martin for 44 HIMARS launchers, bringing the total number of HIMARS launchers to 375.

    In December 2012, the government of Qatar requested seven M142 HIMARS launchers with UFCS (HIMARS System Training, Repair and Maintenance Section), among other weapons, from the US government. The UAE requested 12 HIMARS launchers along with 100 M57 ATACMS T2K missiles and 65 M31A1 GMLRS rocket pods in September 2014.

    In July 2017, the US Army signed a $73.8 million contract with Lockheed Martin as part of the second phase of the Long Range Precision Fires (LRPF) program; The contract included technology upgrades and risk controls to develop a prototype of the munition, which could be fired from the M142 Himars launcher.

    In August 2017, the Romanian government submitted a request for the purchase of 54 HIMARS launchers to the US Defense Security Cooperation Agency (DSCA). The sale includes 81 GMLRS M31A1 rockets along with 81 GMLRS M30A1 alternative warheads, which is a type of cluster munition with 16,000 tungsten fragments, along with a number of ATACMS M57 missiles and other weapons at an estimated cost of $1.25 billion.

    In August 2018, the US Army awarded a $218 million contract to Lockheed Martin to produce 18 HIMARS launchers and related hardware as part of the FMS contract by the end of December 2020. Lockheed Martin also awarded a $289 million contract with the US military in September 2018 to produce 24 M142 HIMARS launchers and related equipment through July 2022.

    As of October 2018, Lockheed Martin has delivered approximately 500 HIMARS launchers to the US military and its international customers. (with an average rate of 33 units per year)

    Lockheed Martin received a FOREIGN MILITARY SALES-FMS contract worth $1.14 billion to deliver GMLRS to Poland, Bahrain and Romania in March 2019. In July 2019, the US Army Contracting Command was awarded a $492 million contract to deliver M142 HIMARS launchers and related hardware to the US Army, US Marine Corps, Romania and Poland through 2022.

    Lockheed Martin was awarded a $431 million contract in December 2022 to produce the M142 HIMARS for the US Army and FMS partners.

    In February 2023, the US State Department approved a $10 billion FMS package including the sale of 18 HIMARS launchers to Poland. Lockheed Martin delivered the first shipment of HIMARS launchers to Poland in May 2023.

    In April 2023, Lockheed Martin signed a $615 million manufacturing contract with the US military to build HIMARS launchers and related equipment. Also, the United States Department of State confirmed the possible sale of HIMARS rockets to Morocco worth $524.2 million dollars.

    M142 HIMARS specifications:
    Type: Multiple Rocket Launcher and Tactical Missile System
    Length: 7 meters
    Width: 2.4 meters
    Height: 3.2 meters
    Crew: 3 people
    Weight: 16250 kg
    Armament:
    MLRS rockets with a range of 45 km
    GLSDB munitions with a range of 150 km
    GMLRS rockets with a range of 92 kilometers
    ER GMLRS rockets with a range of 150 km
    ATACMS missiles with a range of 300 km
    PrSM missile with a range of 499 km
    Development and production: In the late 1990s
    In service: Since 2010
    Origin: USA

    M142 HIMARS multiple rocket launcher – click to view full size

    Source:
    M142 HIMARS
    Lockheed Martin’s HIMARS Launcher Successfully Fires Air Defense Missile
    Marines Fire HIMARS From Ship in Sea Control Experiment With Navy
    Lockheed making moves to increase HIMARS production to 96 per year
    HIMARS – High-Mobility Artillery Rocket System, USA
    M142 HIMARS

  • Military Knowledge: Saab JAS 39 Gripen Fighter Jet

    Military Knowledge: Saab JAS 39 Gripen Fighter Jet

    History
    In the late 1970s, Sweden sought to replace its aging Saab 35 Draken and Saab 37 Viggen. Early proposals included the Saab 38, also called B3LA, intended as an attack aircraft and trainer, and the A 20, a development of the Viggen that would have capabilities as a fighter, attack and sea reconnaissance aircraft. Several foreign designs were also studied, including the General Dynamics F-16 Fighting Falcon, the McDonnell Douglas F/A-18 Hornet, the Northrop F-20 Tigershark and the Dassault Mirage 2000. Ultimately, the Swedish government opted for a new fighter to be developed by Saab.

    On 30 June 1982, with approval from the Riksdag, the FMV issued contracts worth SEK 25.7 billion to Saab, covering five prototypes and an initial batch of 30 production aircraft. By January 1983, a Viggen was converted to a flying test aircraft for the JAS 39’s intended avionics, such as the fly-by-wire controls. The JAS 39 received the name Gripen (griffin) via a public competition, which is the heraldry on Saab’s logo.

    Saab launched the first Gripen on April 26, 1987, on the occasion of the company’s 50th anniversary. This company managed to make the first flight in 1988 by developing the JAS 39 design. In 1993, its first aircraft was delivered, which was able to enter the service of the Swedish Air Force in 1996.

    For the international marketing of this aircraft, Saab made joint efforts with aerospace companies outside of Sweden. In the export market, early Gripen models achieved moderate success with sales to countries in Central Europe, South Africa, and Southeast Asia.

    A 2007 report by the European Union Institute for Security Studies stated the total research and development costs of Gripen were €1.84 billion. According to a study by Jane’s Information Group in 2012, the Gripen’s operational cost was the lowest among several modern fighters; it was estimated at $4,700 per flight hour. The Swedish Ministry of Defense estimated the cost of the full system, comprising 60 Gripen E/F, at SEK 90 billion distributed over the period 2013–42. The Swedish Armed Forces estimated that maintaining 100 C/D-model aircraft until 2042 would cost SEK 60 billion (€6.6 billion in 2013), while buying aircraft from a foreign supplier would cost SEK 110 billion (€12.1 billion).

    Design
    The JAS 39 Gripen fighter jet is a light single-engine supersonic multirole fighter jet with a delta wing and canard configuration with relaxed stability design and fly-by-wire flight controls. The engine used in this fighter jet is called Reaktionsmotor 12 (RM12), which is a licence-built derivative of the General Electric F404−400. The RM12 engine is produced by the Swedish company Volvo Aero, which was sold to the English company GKN Ltd in 2012.

    Volvo RM12 engine

    The Gripen fighter jet uses the PS-05/A radar, which is a 156 kg pulse doppler radar currently installed on the A, B, C and D models. The PS-05/A radar works in the 8-10 GHz band and has an energy output of 1 kW (more than 10 kW maximum output) and can automatically identify, locate and track multiple targets in the upper and lower spheres, land and sea or air in any weather condition. The PS-05/A family radars were developed by Ericsson in collaboration with GEC-Marconi.

    Variants and upgrades

    • Gripen A, or JAS 39A: initial single seat version that entered service with the Swedish Air Force in 1996. A number have been upgraded to the C standard or been converted to 39D at a 2:1 ratio.
    • Gripen B, or JAS 39B: two-seat version of the 39A for training, specialised missions and type conversion. To fit the second crew member and life support systems, the internal cannon and an internal fuel tank were removed and the airframe lengthened 0.66 m.
    • Gripen C, or JAS 39C: NATO-compatible single seat version with extended capabilities in terms of armament, electronics, etc. Can be refuelled in flight. Variant was first deliveried on 6 September 2002.
    • Gripen D, or JAS 39D: two-seat version of the JAS 39C, with similar alterations as the JAS 39B.
    • Gripen NG: Follow-on the Gripen Demo technology demonstrator. Changes from the JAS 39C include the more powerful F414G engine, Raven ES-05 AESA radar, increased fuel capacity and payload, and two additional hardpoints. These improvements reportedly increased costs to an estimated 24,000 Swiss Francs (US$27,000) per hour, and the flyaway cost to 100 million Swiss Francs (US$113M).
    • Gripen E, or JAS 39E: single-seat production version developed from the Gripen NG program, priced at US$85 million per unit. Sweden and Brazil have ordered the variant. Brazil’s designation for this variant is F-39E.
    • Gripen F, or JAS 39F: two-seat version of the JAS 39E. Eight ordered by Brazil, to be developed and assembled in Brazil; planned for pilot training and combat, being optimized for back seat air battle management, with jamming, information warfare and network attack, besides weapon system officer and electronic warfare roles Brazil’s designation for the variant is F-39F.
    Click to view full size

    Specifications

    JAS 39C/D specifications:
    Crew: 1 JAS 39C / 2 JAS 39D
    Length: 14.9 m JAS 39C / 15.6 m JAS 39D
    Wingspan: 8.4 m
    Height: 4.5 m
    Empty weight: 6,800 kg
    Max takeoff weight: 14,000 kg
    Fuel capacity: 3,000 L (internal); 3,500 L (external)
    Payload: 5,300 kg
    Powerplant: 1× Volvo RM12 afterburning turbofan engine, 54 kN thrust dry, 80.5 kN with afterburner
    Maximum speed: Mach 2 (2,100 km/h)
    Combat range: 800 km
    Ferry range: 3,200 km
    Service ceiling: 15,240 m (50,000 ft)
    Armament
    Guns: 1× 27 mm Mauser BK-27 revolver cannon with 120 rounds (single-seat models only)
    Hardpoints: 8 (two hardpoints under fuselage, two under each wing, and one on each wing tip, with one of these for FLIR / ECM / LD / Recon pod) with a capacity of 5,300 kg.

    JAS 39E/F specifications:
    Crew: 1 JAS 39E / 2 JAS 39F
    Length: 15.2 m JAS 39E / 15.9 m JAS 39F
    Wingspan: 8.6 m
    Height: 4.5 m
    Empty weight: 8,000 kg
    Max takeoff weight: 16,500 kg
    Fuel capacity: 4,360 L (internal); 4535 L external with 3 drop tanks
    Payload: 7,200 kg
    Powerplant: 1× General Electric F414-GE-39E (RM16) afterburning turbofan engine, 61.83 kN thrust dry, 98 kN with afterburner
    Maximum speed: 2,100 km/h
    Combat range: 1,500 km
    Ferry range: 4,000 km
    Service ceiling: 16,000 m (52,000 ft)
    Armament
    Guns: 1 × 27 mm Mauser BK-27 revolver cannon with 120 rounds (single-seat models only
    Hardpoints: 10 (three hardpoints under fuselage, two under each wing, one on each wing tip, and one dedicated for FLIR / LD / Recon pod) with a capacity of 7,200 kg.

    Avionics
    Selex ES-05 Raven AESA radar
    Skyward-G IRST system
    Air-to-air and air-to-surface tactical data link system
    Wide Area Display (WAD) (single screen display)
    Targo helmet mounted display (HMD)
    ANVIS advanced night vision system/head up display (HUD)

    Saab JAS 39 Gripen Fighter Jet – click to view full size

    Saab JAS 39 Gripen posters in Russian, Arabic and Azeri:

    Source:
    Saab JAS 39 Gripen
    PS-05/A
    How Gripen E’s AESA Radar Gets a Large Field of View
    Gripen E-series

  • Military Knowledge: Ya-Ali Cruise Missile

    Military Knowledge: Ya-Ali Cruise Missile

    The entire process of designing and producing of this missile was carried out by the Aerospace Industries of the Islamic Revolutionary Guard Corps of Iran.

    The missile was first unveiled on 11 May 2014 when Iranian leader Grand Ayatollah Ali Khamenei visited the Aerospace Force of the Army of the Guardians of the Islamic Revolution. In the same exhibition, the Ya Ali (AS) cruise missile was announced as a land cruise missile with a turbojet engine, a range of 700 km and a warhead of 200 kg. In another interview in 2014, General Hajizadeh, commander of IRGC Aerospace Force announced that this missile can be installed and used by the IRGC’s Sukhoi 22.

    Based on the images released from the unveiling ceremony of Ya Ali (AS) cruise missile, it can be said that this missile has a cylindrical body, fixed rectangular wings, a jet engine at the end of the body and an air intake below it, and control fins at the end of the body.

    The dimensions of this missile have not been officially announced, but in some sources, the length of the missile is 4.9 meters and its diameter is 35 centimeters.

    No detailed information is available about the engine of this missile. Two Toloue-4 and TJ100 engines are considered as the main options, the most likely of which is the Toloue-4 engine. The Toloue-4 engine is installed on Ghader and Noor cruise missiles as well as the Karrar drone.

    The guidance system of this missile has not been officially announced, but this missile can obviously use Terrain contour matching (TERCOM) or Digital Scene Matching Area Correlator (DSMAC) method. However, considering the time of unveiling and use of this missile, the most likely method is to use an altitude measuring radar along with the inertial system and GPS, which helps the autopilot in guiding the missile. One of the weaknesses of this missile is not using a camera in the last stage of hitting, which could increase the accuracy of this missile.

    Ya-Ali (a.s) cruise missile is considered the first achievement of Meshkat project. This project is defined to achieve a 2000 km cruise missile; Its first prototype is the Ya-Ali cruise missile. After this missile, Soumar and Abu Mahdi cruise missiles were also built with higher ranges.

    Specifications of Ya-Ali cruise missile:
    Length: 4.9 meters
    Diameter: 35 cm
    Range: 700 km
    Warhead weight: 200 kg
    Engine: Toloue-4 turbojet
    Launch platform: capable of firing from land, air and sea launchers
    Origin: Iran
    Designer and manufacturer: Islamic Revolutionary Guard Corps Aerospace Force

    Ya-Ali cruise missile – click to view full size

    Posters of Ya-Ali cruise missile in Farsi, Arabic (صاروخ كروز يا علي), Russian (Крылатая ракета Йа Али), Hebrew (טיל שיוט יא עלי), Chinese (亚阿里巡航导弹), Kurdish (موشەکی کروزی یاعەلی) and Azeri (Ya Əli (Ə) Qanadlı Raketi):
