  • Military Knowledge: Kizilelma Drone, Turkish Army’s First Jet Engine Drone

    Military Knowledge: Kizilelma Drone, Turkish Army’s First Jet Engine Drone

    Kizilelma’s history:

    After Turkey was excluded from the F-35 production and delivery program by the United States, it commenced developing an advanced drone with a phased array radar and artificial intelligence capabilities in 2018 through Baykar.

    The Turkish Air Force aimed to purchase between 110 and 120 F-35A CTOL aircraft. However, Turkey’s official order was for only 6 aircraft, of which one, identified as 0001-18, was delivered in Texas, and a Turkish pilot was trained in the United States. Following Turkey’s acquisition of the S-400 missile system, the US Senate passed legislation on June 18, 2018, prohibiting the export of the F-35 fighter to Turkey.

    Prior to the US sanctions, the Turkish Ministry of Defense had shown interest in the vertical take-off variant of the F-35. Due to the delivery issues with this fighter, it announced that the Turkish Navy would instead utilize domestically produced unmanned aerial vehicles (UCAVs), such as the Bayraktar TB3, in the short term.

    At that time, Turkey was planning to construct a helicopter carrier to support ground operations, which was intended to operate with the F-35B fighter. This vessel is now in service under the name Anadolu and has been adapted to operate the Kızılımla drone.

    Despite Turkey being removed from the F-35 parts supply and the cancellation of the fighter jet sale, it had been producing key airframe and engine components for the F-35 program until 2022. Capitalizing on the partnership and the technology transferred, Turkey aimed to develop a stealth drone, leveraging most available components.

    For the drone’s engine, two Ivchenko-produced turbofan engines, the AI-25TLT and AI-322F, were chosen, with the AI-25TLT powering the prototypes. Engine integration was completed successfully on September 29, 2022, and two months later, on November 20, 2022, the taxi test was also successful.

    The Red Apple (Kızılımla) achieved its first successful flight 13 days after the taxi test, on November 3, 2022. Baykar shared a video on March 15, 2025, showcasing the flight test of its newest model, the Kızılımla. The video highlights minor modifications to the Kızılımla when compared to earlier versions.

    Video published on March 15, 2025 of the Kızılımla flight test

    In October 2024, Baykar President Selçuk Bayraktar announced that mass production of the Kızılımla had begun and that one drone had been produced. The company plans to produce more than 10 units by 2026. Efforts are ongoing to develop and optimize the drone, including its radar and sensors.

    Kızılımla’s design:

    The Kızılımla drone features a lightweight body made of carbon composite thermoplastic materials and incorporates a stealthy design. It is powered by a Ukrainian turbofan engine. The Kızılımla includes two air intakes positioned on the fuselage’s sides and a trapezoidal wing structure situated at the fuselage’s center.

    To enhance maneuverability, two canards are positioned at the drone’s nose. Additionally, it has two vertical rudders arranged in a V-shape at the rear for improved control, while the horizontal rudder at the back has been eliminated.

    This drone is equipped with an internal weapon compartment containing two weapon racks, along with three hardpoints under each wing, providing the Kızılımla a total of six hardpoints for ordnance.

    An image of the Kizilelma drone showing the general shape of the wings.

    The Kizilelma drone serves as both a combat drone (UCAV) and a wingman drone. A wingman drone operates alongside the main fighter jet, equipped with a radar to gather battlefield data before the fighter jet engages. In this role, the wingman drone can sacrifice itself to shield the manned fighter jet from unexpected attacks. Typically, wingman drones are engineered for air-to-air combat, benefiting from stealthy designs.

    The Kizilelma drone is built for a variety of missions, including air-to-air combat, strategic strikes, close air support (CAS), suppression of enemy air defenses (SEAD), destruction of enemy air defenses (DEAD), and interception and communication disruption (SIGINT/ELINT).

    Additionally, the Kizilelma drone can take off from short runways (LHD) or from drone carriers such as Anadolu and other aircraft carriers.

    Video of the Kizilelma drone test next to the Turkish Air Force F-16 fighter jet

    Kizilelma’s Engine:

    Two types of engines have been introduced for the Kizilelma drone, which, according to the infographic published by Baykar, will be used to build three types of this drone.

    • Kizilelma Drone Version A: This version is equipped with an AI-25TLT turbofan engine that does not have an afterburner.
    • Kizilelma Drone Version B: This version features an AI-322F turbofan engine with an afterburner.
    • Kizilelma Drone Version C: This version is equipped with two AI-322F turbofan engines, both with afterburners.

    These three versions will differ in terms of speed, range, and flight altitude. According to the available information, all three types will be developed over time, with Version A still under development.

    Infographic published by Baykar Defence

    The infographic indicates that the ongoing development project incorporates the AI-25TLT turbofan engine, which does not feature an afterburner. This military engine was initially created by the Ivchenko OKB in Soviet Ukraine and is now manufactured by the Sich company, based in Zaporizhzhia. Beyond the AI-25TLT, Sich also produces engines for aircraft and helicopters, in addition to turbines and industrial gas installations for marine use.

    The Kizilelma features a camera located beneath its nose and a phased array radar produced by ASELSAN. The specific details of the camera and radar have not been disclosed. Nonetheless, the images available suggest that the camera is seamlessly integrated into the body, helping to minimize the drone’s radar cross-section. Additionally, this drone is equipped with a sophisticated electronic warfare system.

    A view of the camera used in the Kizilelma drone on a drone model at the exhibition

    This drone appears to incorporate the Israeli-made ADA-O anti-jamming system, which ensures GPS functionality for ground platforms amidst electronic warfare targeting GPS signals. The system is compatible with various armored platforms, vehicles, artillery, and different aerial platforms. Generally, it aims to counter jamming of GNSS on a global scale. It has also been deployed on Israeli Hermes and Eitan drones. This evidence suggests that alongside American technologies utilized in the Ukrainian airframe and engine, an Israeli system was integral to the development of this drone.

    Armament:

    The Kizilelma drone is capable of carrying 1.5 tons of ordnance, including laser-guided bombs, TEBER and Lacin precision-guided bombs, Gökdoğan and Bozdoğan air-to-air missiles, and SOM-J, HGK, LGK, and Minyatür Bomba air-to-surface cruise missiles.

    Specifications of the Kızılelma multirole combat drone (Kızılelma-A model):

    Type: Multi-role combat drone
    Manufacturer: Baykar Defense
    Manufacturer: Turkey
    First flight: 2022
    Length: 14.7 m
    Wingspan: 10 m
    Height: 3.3 m
    Engine:
    One AI-25TLT turbofan engine in Kızılelma-A
    Two AI-322F turbofan engines in Kızılelma-B
    Combat Range: 926 km
    Maximum Speed: 1,100 km/h (Mach 0.9)
    Cruise speed: 735 km/h (Mach 0.6)
    Altitude: 45,000 ft (14,000 m)
    Endurance: 5 hours
    Maximum takeoff weight: 6,000 kg
    Weapon payload: 1,500 kg
    Radar: Active phased array (AESA)
    Armament:
    – Two hardpoints in the internal weapons bay and six hardpoints under the wings (three on each wing)
    Cruise missiles SOM, LAÇİN Kit Guided Freefall Bombs, Turkish Miniature Bombs, GÖKDOĞAN (Shahin) Air-to-Air Missile, and BOZDOĞAN or Merlin Infrared Air-to-Air Missile

    Sources:
    Bayraktar KIZILELMA
    Bayraktar KIZILELMA Unmanned Combat Aircraft System
    ” Kızılelma ” 2023’de semalarda olacak!
    Baykar Bayraktar Kizilelma
    UAV Bayraktar Kizilelma: New Generation Turkish Combat Drone
    Bayraktar KIZILELMA ilk motor entegrasyon testini başarıyla tamamladı
    Kızılelma takes to the sky!
    Bayraktar Kızılelma
    IAI Unveils ADA-O to enable land platforms deal with GNSS anti-jammers

  • Military Knowledge: MQ-9 Reaper Drone

    Military Knowledge: MQ-9 Reaper Drone

    History of the MQ-9 Design and Development:

    The MQ-9 Reaper drone is the result of the evolution of one of the most successful UAV projects in the United States: the MQ-1 Predator. This project was initially initiated by the American company General Atomics Aeronautical Systems, Inc. (GA-ASI) as a private venture.

    In 1998, as the U.S. military’s operational needs expanded to include unmanned systems with greater range, altitude, and payload capacity, GA-ASI engineers began designing a new platform based on the Predator. This new platform, later known as the Predator B, also received financial support from NASA.

    The first flight of the Predator B prototype took place in February 2001. Although the drone appeared similar to the MQ-1 Predator, it was completely redesigned in terms of dimensions, engine power, and body layout. The most significant design change was the introduction of an upward-facing V-shaped tail, which improved flight stability compared to the classic downward-facing tail of the MQ-1 Predator.

    During the testing phase, two types of engines were installed on the drone: a Honeywell TPE-331-10T turboprop engine, which provided acceptable performance, and a Williams FJ44-2A turbofan engine, which was eventually discarded due to its high cost and limited efficiency.

    In February 2003, the United States Air Force officially joined the project by ordering a turboprop-powered variant, the MQ-9A. They received two prototypes, known as YMQ-9A, for evaluation in testing weapons, reconnaissance capabilities, and maneuverability.

    The MQ-9 Reaper was developed for the United States Air Force as a direct response to a Department of Defense (DoD) directive aimed at supporting overseas operations, known as “Overseas Contingency Operations.” In the early 2000s, the rise of asymmetric threats created the need for a drone capable of extensive reconnaissance and surveillance, as well as the ability to target and destroy moving targets in real time with high accuracy.

    The Reaper far exceeded the operational performance of the MQ-1 Predator. It can fly at altitudes exceeding 15,200 meters (50,000 feet) and has a flight endurance of up to 27 hours. Equipped with advanced systems such as the AN/APY-8 Lynx combined aperture radar and the Raytheon AN/AAS-52(V) MTS multispectral electro-optical system, the Reaper significantly enhanced its reconnaissance and targeting capabilities. Furthermore, the MQ-9A evolved into a fully operational offensive platform, capable of deploying a diverse array of guided weapons.

    In 2006, the United States Air Force formally designated the MQ-9A Reaper. The drone commenced operational service in 2007, completing its inaugural combat mission in Afghanistan.

    As of 2018, the US Air Force had ordered 366 Reapers from General Atomics, with more than 300 delivered by 2021. The US Air Force plans to retire its MQ-9A fleet by 2035.

    Appearance and performance characteristics of the MQ-9 drone:

    The Reaper measures 11 meters in length, stands 3.8 meters tall, and features a wingspan of 20 meters, making it considerably larger than the MQ-1. It has a base weight of 2,223 kilograms without payload, while its maximum takeoff weight reaches 4,760 kilograms. For the Extended Range (ER) variant, this maximum weight rises to 5,307 kilograms. Additionally, the ER version boasts a fuel capacity of 903 gallons (approximately 6,000 pounds), allowing for extended flight ranges.

    A view of an MQ-9 taxiing on a runway in Afghanistan, 2007

    The Reaper uses a Honeywell TPE331-10GD turboprop engine that produces 900 horsepower. This engine allows the drone to reach a maximum speed of 480 km/h, but its typical flight speed is in the range of 280 to 310 km/h.

    The manufacturer has officially announced that the MQ-9A has a flight endurance of 27 hours and a range of 1,850 km. In 2015, the US Air Force first tested the Extended Range (ER) version of the MQ-9A, which features external fuel tanks mounted under the wings and a more robust landing gear. The ER version boasts a flight endurance of 34 hours and a range of 2,592 km.

    In terms of armament, the MQ-9A is equipped with seven hardpoints and can carry up to 1,361 kg of ordnance. It has a variety of weapons options, including Sidewinder and Stinger air-to-air missiles, Hellfire missiles with a range of 8 to 12 km, GBU-12 Paveway II laser-guided bombs weighing 227 kg, GBU-38 JDAM GPS-guided bombs, and more advanced versions of the GBU-49 and GBU-54 Laser JDAM, which have a range of approximately 15 km.

    The MQ-9 is equipped with Raytheon’s advanced Multispectral Targeting System-B (MTS-B) electro-optical system, which features an infrared sensor, color and monochrome day vision cameras, short-wave infrared cameras, laser designators, and laser rangefinders.

    The system is capable of long-range surveillance, target acquisition, precise tracking of moving targets, range finding, and laser designator for a variety of air-to-surface munitions. In addition to the MQ-9 Reaper, the MTS-B is also used in the U.S. Navy’s MQ-4C unmanned aerial vehicle fleet.

    Read more: Military Knowledge: Raytheon’s Multispectral Targeting System-B (MTS-B)

    MTS-B electro-optical system

    MQ-9 Block 5 drone:

    The MQ-9 Block 5 is an enhanced version of the original MQ-9 prototype (Block 1), featuring improved endurance, range, and payload capacity. Key upgrades in the Block 5 model include wing fuel pods, reinforced landing gear, and a four-bladed propeller. It also has enhanced electrical power, more secure communications, and the capability for automatic landing. The MQ-9 Block 5 ER variant has an endurance of 34 hours and a range of 2,592 kilometers. In general, General Atomics is in the process of upgrading its MQ-9 fleet to ER versions.

    MQ-9B drone – Introducing other MQ-9 drone models:

    The MQ-9B drone builds on the MQ-9A model and is recognized as the SkyGuardian and SeaGuardian. It is larger and boasts enhanced capabilities compared to the MQ-9A. The MQ-9B’s length measures 11.6 meters, with a wingspan of 24 meters. Its maximum takeoff weight is 5670 kilograms, and it can reach a flight ceiling of 12200 meters. A significant factor in developing the MQ-9B was the need to meet NATO civil aviation regulations, allowing its operation in civilian airspace, whereas the MQ-9A is solely dedicated to military functions.

    MQ-9B SkyGuardian: The SkyGuardian, a variant of the MQ-9B, meets European civil aviation regulations. Known as the Certifiable Predator B, it is the first drone certified for use in civilian airspace. Notable features include a 40-hour endurance, a maximum altitude of 12,190 meters, and a 24-meter wingspan. Additionally, the SkyGuardian comes with cutting-edge systems, such as an EO/IR imaging sensor, an anti-icing system, and a TCAS collision avoidance system.

    MQ-9B SeaGuardian: The SeaGuardian, a specialized version of the MQ-9B, is tailored for maritime missions. It boasts an endurance of up to 18 hours (some reports indicate 30 hours) and can operate over a distance of 2,200 km, making it ideal for maritime surveillance and search-and-rescue tasks. A standout feature is the Leonardo Seaspray 7500E V2 AESA radar, capable of detecting maritime targets. Additionally, the drone is outfitted with sophisticated systems for deploying sonobuoys to monitor submarines.

    MQ-9B STOL: STOL means “short takeoff and landing.” The MQ-9B STOL can take off and land in challenging environments, including aircraft carriers. General Atomics introduced this concept in 2022. This kit allows for the replacement of wings, tail, and propeller to enhance short takeoff and landing performance.

    MQ-9B STOL drone

    MQ-9 UAV operational history:

    The Reaper drone has primarily conducted its operational activities in the Middle East. Its most significant operation to date was the assassination of Qassem Soleimani, commander of the Quds Force of the Islamic Revolutionary Guard Corps, in Baghdad on January 3, 2020. The United States regime used Hellfire missiles in this operation.

    Afghanistan (2007 to 2021): The Reaper’s combat presence was first established in Afghanistan, quickly gaining a reputation as a “hunter” platform. A notable incident occurred on September 13, 2009, when a Reaper that had lost control was shot down by a US F-15E fighter jet to prevent it from entering Tajik airspace. By 2010, Reaper drones were flying more than 33,000 close air support missions annually. Their usage peaked during the withdrawal of US forces in 2021, where they played a key role in supporting evacuation operations.

    Iraq and Syria (since 2007): Reaper drones have been extensively utilized in Operation Iraqi Freedom and the fight against ISIS in Operation Inherent Resolve. This includes the 2015 strike on Jihadi John in Raqqa, Syria, using a Hellfire missile. In 2023, as the conflict amongst various factions and the Israel-Hamas war intensified, Reapers carried out the majority of US airstrikes in Syria and were also employed to target Iranian-backed forces.

    Yemen: Initially, Reapers were used for reconnaissance missions against Al-Qaeda in the Arabian Peninsula (AQAP). However, following the Ansar Allah operation in Yemen and the overthrow of the Mansour Hadi government, they began to conduct operations against Ansar Allah. The first recorded downing of an MQ-9 occurred in 2017. Reaper missions in Yemen intensified as Ansar Allah ramped up operations in the Red Sea in 2023. From September 2023 to April 2025, Yemeni Ansar Allah shot down at least 19 Reapers (with a total of 23 since 2017), incurring losses collectively estimated at over $595 million. These losses highlight the Reaper’s vulnerability in high-intensity conflict zones.

    Read more: Yemeni Army: The Annihilator of American MQ-9 Drones!

    Gaza (since 2023): Following the onset of the Gaza War in October 2023, Reapers flew unarmed over the Gaza Strip to identify the locations of American hostages during Israeli operations. However, no detailed information is available regarding these operations.

    MQ-9 drone users:

    • United States includes NASA, Air Force, Navy, Marine Corps, Coast Guard, and Department of Homeland Security (US Customs and Border Protection)
    • United Kingdom
      – Early versions of the MQ-9A Reaper for surveillance operations in Afghanistan and the Middle East.
      – Protector RG Mk 1, a more advanced version to replace the MQ-9A, capable of carrying Brimstone 3 missiles and Paveway IV bombs.
    • Italy
      – Early versions of the MQ-9A Reaper for surveillance missions in NATO and Libya operations.
      – MQ-9A Block 5, an upgraded version.
    • Netherlands
      – Upgraded version of the MQ-9A Reaper Block V for surveillance and reconnaissance missions
    • Japan
      – Maritime version of the MQ-9B SeaGuardian for maritime threat surveillance.
    • United Arab Emirates
      – MQ-9B SkyGuardian for border reconnaissance and surveillance missions.
    • France
      – MQ-9A Reaper for counterterrorism and reconnaissance operations in Africa and the Middle East.
    • Spain
      – MQ-9A Reaper for surveillance and border security operations.
    • Poland
      – MQ-9B SkyGuardian version for reconnaissance and surveillance missions.
    • Morocco
      – MQ-9B SeaGuardian maritime version for coastal surveillance and border operations.
    • Taiwan
      – MQ-9B SkyGuardian version for surveillance and reconnaissance in border areas.

    MQ-9A Reaper specifications:

    Type: Reconnaissance and Combat
    Manufacturer: General Atomics Aeronautical Systems
    Country of Manufacture: United States
    First Flight: 2001
    Length: 11 m
    Wingspan: 20 m
    Height: 3.81 m
    Engine: Honeywell TPE331-10 900 hp
    Fuel Capacity: 1,800 kg – 2,721 kg in ER version
    Range: 1,850 km – 2,593 km in ER version
    Maximum Speed: 480 km/h
    Service ceiling: 15,420 m (50,000 ft)
    Endurance: 27 hours – 34 hours in ER version
    Maximum Takeoff Weight: 4,760 kg – 5,307 kg in ER version
    Empty Weight: 2,223 kg
    Payload: 1,747 kg
    Armament: 7 hardpoints with a capacity to carry 1,361 kg of ammunition

    More images of the MQ-9 drone:

    source:
    General Atomics MQ-9 Reaper
    MQ-9 Reaper
    MQ-9A Reaper
    General Atomics MQ-9 Reaper (Predator B)
    Predator The Secret Origins of the Drone Revolution
    The Remote-Control Air War Over Iraq and Afghanistan: A Pilot’s Story
    Theory, Design, and Applications of Unmanned Aerial Vehicles
    Drone Wars: Pioneers, Killing Machines, Artificial Intelligence, and the Battle for the Future
    MQ-9B Sky Guardian chosen over Reaper
    France retires Reaper Block 1 for Block 5 Extended-Range UAS

  • Iran Unveiled Ghaem-118 Missile, Which Closely Resembles the American Coyote-2!

    Iran Unveiled Ghaem-118 Missile, Which Closely Resembles the American Coyote-2!

    An intriguing point about this well-designed missile that has remained largely unnoticed by the media is that it bears a strong similarity to the Coyote Block 2 used in the US Army’s LIDS system. We have previously explored the LIDS system in a separate article, which you can read here: Military Knowledge: FS-LIDS And M-LIDS Anti-Drone Systems

    In recent years, the United States has deployed the mobile LIDS system (M-LIDS) on the battlefield to enhance the defense of occupied areas in eastern Syria against drone attacks by resistance forces. The reverse engineering of this product is quite significant!

    The Ghaem-118 interceptor missile is also very similar to the Coyote-2 interceptor in terms of technical specifications. The Ghaem-118 has a range of 25 kilometers and can detect and lock onto targets using three methods: radar, electro-optical, and infrared.

    The engine and booster section of the Ghaem-118 is quite similar to that of the Coyote-2 interceptor.

    The Ghaem-118 features a five-launcher system mounted on the Aras-3 vehicle, making its design more comparable to the American M-LIDS model, which serves as its mobile prototype.

    Additionally, an unnamed radar system observed next to the Ghaem-118 launcher bears a strong resemblance to the American AN/TPQ-50 fire control and detection radar, which has also been integrated into the LIDS system.

    Iran’s Ministry of Defense and the IRGC Ground Forces have not released the full specifications of the Ghaem-118. However, a video showcasing its field test has been made available. As more information about the Ghaem-118 is disclosed in the future, we will provide further insights in a separate article.

    Image of the American Coyote Block 2 missile
    Video of the American Coyote-2 test in the LIDS system
  • Military Knowledge: B-2 Spirit Stealth Bomber

    Military Knowledge: B-2 Spirit Stealth Bomber

    Introduction:
    In the 1980s, global advancements in air defense systems significantly threatened the United States Air Force’s capability to hit crucial enemy targets. To counter this challenge, the Air Force adopted cutting-edge stealth technology for a long-range bomber designed to carry substantial payloads, both conventional and nuclear. The B-2 Spirit, developed by Northrop Grumman, achieved a level of invisibility to advanced radars that was unprecedented at the time, utilizing a flying wing configuration, innovative composite materials, specialized coatings, and secret stealth technologies.

    B-2 bomber

    The aircraft was first unveiled to the public in November 22, 1988, at Air Force Plant 42 in California and completed its first test flight in July 17, 1989. After undergoing development, the first operational B-2 was delivered to the United States Air Force in December 17, 1993. The bomber, whose primary base is Whiteman Air Force Base in Missouri, has participated in various operations, the most significant of which include Operation Allied Force in Serbia in 1999, Operation Enduring Freedom in Afghanistan in 2001, and Operation Iraqi Freedom in Iraq in 2003.

    The B-2 Spirit can conduct combat missions for over 30 hours without a break, operated by a crew of two (a pilot and a mission commander). It has the capacity to carry precision-guided munitions weighing up to 40,000 pounds for each mission. Earlier B-2 models were subjected to extensive environmental tests, including 1,000 hours of temperature evaluations at the McKinley Climatic Laboratory, ranging from -65 to 120 degrees Fahrenheit. The results of these tests, later confirmed in Alaska, proved that the B-2 Spirit is not only capable of withstanding various climatic challenges but also effectively executes strategic missions with minimal radar detection by adversaries.

    History and development of the B-2 bomber:

    The concept of ​​designing a stealth bomber dates back to the 1940s and 1950s when Northrop sought to introduce a new approach to military aircraft by developing advanced flying wing designs like the YB-35 and YB-49. This design, lacking a traditional tail, significantly reduced the radar cross-section and could have revolutionized air tactics if completed. However, at that time, the absence of advanced control systems and technological limitations led to these projects being shelved.

    In the 1970s, advances in radar-absorbing technologies, advanced composite materials, and digital computing reignited the United States Air Force’s interest in developing a stealth bomber. The Vietnam War experience and the increasing threat of Soviet air defenses underscored the necessity for a strategic aircraft capable of penetrating deep into enemy territory undetected.

    In 1979, the United States Air Force launched the Advanced Technology Bomber (ATB) program, which aimed to develop a stealthy strategic bomber capable of striking deep into enemy territory. The project was highly classified, with information only available to a select few senior officials.

    Northrop and Lockheed competed for the program. Lockheed, known for its success with the F-117 Nighthawk stealth fighter, proposed a design aligned with those principles. However, Northrop ultimately proved its superiority by creating a flying-wing bomber, securing the contract for the program’s development in 1981.

    However, Northrop’s design, which integrated a distinctive aerodynamic shape, radar-absorbing materials, and fully digital flight systems, set the stage for a new era of strategic bombers. The outcome of this initiative, the B-2 Spirit, surpassed all previous bombers in both design sophistication and operational capabilities at the time.

    Visual comparison of Northrop (top image) and Lockheed and McDonnell-Douglas designs

    The soaring costs and technical difficulties of the program attracted significant criticism in Congress. By the early 1980s, the estimated project cost was $22.1 billion, but as it advanced, the combination of technical hurdles and escalating research and development expenses caused this estimate to climb to $44.7 billion by 1988. Ultimately, taking into account research and development, production, maintenance, and upgrades, the entire B-2 program cost totaled $101 billion, making each aircraft approximately $2.1 billion. In 1992, the Bush administration opted to cut the aircraft production from 132 to a mere 21. The anticipated cost for producing the 20 aircraft was about $26.8 billion. This assessment bolstered the case against any additional B-2 production. Consequently, Congress decided to stop further production, maintaining 20 operational aircraft and 1 experimental one in service.

    Its high maintenance costs and limited fleet prompted the US Air Force to announce in 2018 that the bomber would be retired by 2032, to be replaced by the B-21 Raider, a new generation of stealth bombers.

    B-2 design and technical features:

    A standout aspect of the B-2’s design is its distinctive flying wing structure, which lacks any vertical or horizontal tails. This feature is intended to minimize radar reflection. The tailless configuration, combined with its expansive wings, effectively lowers the radar cross-section (RCS), enhancing its stealth capabilities. Consequently, the B-2 can operate at high speeds and altitudes while remaining undetectable to enemy radars. Measuring 21 meters in length, 5.18 meters in height, and boasting a wingspan of 52.4 meters, this aircraft ranks among the largest stealth platforms globally.

    The B-2’s flying wing design

    Since the B-2 is a traditional airframeless aircraft, integrating strength into its structure required the use of advanced materials. For this purpose, special composites such as carbon fiber and metal compounds were used in the fuselage structure, as they are lightweight while also providing high strength and excellent radar absorption. Additionally, to withstand the stresses and pressures from flying at very high altitudes, the body was designed to endure extreme changes in temperature and air pressure.

    B-2 Avionics and Guidance Systems:

    Another notable feature of the B-2 is its advanced avionics. One of these systems is the AN/APQ-181 multi-purpose radar, designed to detect and track targets under various flight conditions. With its capability to operate in multiple bands, this radar enables the B-2 to identify its targets across a broad spectrum. The system employs radar stealth technology to conduct precise reconnaissance without being detected by enemy defense systems.

    The AN/APQ-181 radar is among the most advanced terrain mapping and tracking systems designed specifically for the B-2 Spirit stealth bomber. It operates in the G-band and features 21 operational modes, including terrain tracking, navigation, target acquisition, tracking, and weapons guidance.

    The AN/APQ-181 features a modular design that enhances capabilities and reduces failure rates. This system employs two electronically scanned array antennas, providing a broad field of view that covers the front and sides of the aircraft. The radar consists of 10 modular replaceable units (LRUs), with a combined weight of 955 kg and a volume of 1.485 cubic meters. Each antenna has a weight of 260 kg. Designed to meet the MIL-STD-1553 standard, the AN/APQ-181 system is resistant to electromagnetic interference as well as the effects of electromagnetic pulses (EMP). Additionally, the radar is optimized for challenging operating conditions, including low-altitude and high-speed flights. In response to the growing demand for the frequency spectrum by commercial communications systems, the US Air Force initiated a program in 2004 to upgrade this radar to an active phased array (AESA) system.

    Alongside radar, the B-2’s sophisticated navigation system incorporates GPS and astro-inertial technology, ensuring accurate guidance through lengthy and perilous routes. These systems are designed to function optimally, even in electronic warfare environments, with the ability to autonomously correct their course when necessary.

    Stealth of the B-2 bomber:

    Stealth is a key feature of the B-2, enabling the aircraft to stay concealed from modern detection systems such as multi-band radars and infrared sensors. To achieve this goal, the B-2’s airframe was designed to minimize radar reflection by reducing its radar cross-section (RCS). The delta-shaped flying wing configuration, along with the airframe’s sharply angled surfaces that reduce radar reflection, collectively enhance the B-2’s stealth capabilities. The B-2 reportedly has a radar cross-section of about 0.1 square meters.

    Image of the B-2 radar’s initial reflection angles

    Another stealth feature of the B-2 is the use of special radar-absorbing coatings called Radar Absorbent Material (RAM). These coatings are applied throughout the aircraft’s body to absorb radar waves, thereby minimizing its radar cross-section.

    To lower its thermal signature, the B-2’s engines are uniquely positioned within the body, and their exhaust is carefully shrouded to reduce heat visibility. Additionally, ventilation and cooling systems for the engine’s intake air, combined with efforts to decrease exhaust temperature, effectively minimize the B-2’s thermal signature.

    B2 engines specially designed within the body to minimize thermal signature

    Engine power and performance of the B-2 bomber:

    The B-2 bomber features four General Electric GE-100 non-afterburning turbofan engines, generating 77 kilonewtons (17,300 pounds) of thrust. These uniquely designed engines enable the B-2 to achieve speeds exceeding 630 mph (1,010 km/h) at an altitude of 40,000 feet (12,000 m). Additionally, the aircraft can cruise at 560 mph (900 km/h) at the same elevation. With an operational range of approximately 6,800 miles (11,000 km), the B-2 is equipped for long-range missions.

    Armament and carrying capacity of the B-2 bomber:

    The bomber can carry 40,000 pounds (18,000 kg) of ordnance, which may consist of both nuclear and conventional weapons. Since the Cold War concluded, modifications have enabled the aircraft to effectively deploy conventional armaments as well. It has the capacity to hold up to 80 500-pound bombs, 36 750-pound bombs, and 16 2,000-pound bombs in its two bays. Additionally, the bomber is outfitted with long-range weapons such as the AGM-154 Joint Standoff Weapon (JSOW) and the AGM-158 Joint Air-to-Surface Standoff Missile (JASSM).

    To complement the aircraft’s military capabilities, the B-2 is also designed to carry two massive Massive Ordnance Penetrator (MOP) bombs. The 14-ton GBU-57 bunker-busting bomb is ideal for destroying bomb-resistant structures such as bunkers and fortified underground facilities. The B-2 is one of the few platforms capable of delivering these bombs.

    The cockpit and flight crew of the B-2 bomber:

    The B-2 bomber features an advanced, automated cockpit managed by two pilots. The primary pilot sits on the left, while the mission commander is located on the right. This arrangement enables the flight crew to continuously and seamlessly monitor systems and conduct intricate operations. Additionally, the aircraft is equipped with sophisticated systems that minimize flight crew fatigue, enabling one member to rest or utilize the aircraft’s amenities during extended flights.

    B-2 bomber cockpit

    B-2 Missions and Operations:

    Since entering service in the 1990s, the B-2 Spirit has participated in numerous important military missions. Its first operational appearance occurred during the Kosovo War in 1999, where the B-2 played a significant role in destroying targeted sites, dropping 11 percent of the bombs used in the conflict. The aircraft also marked the first use of JDAM smart bombs.

    In the 2000s, B-2 bombers played a crucial role in the Afghanistan and Iraq wars. They undertook one of their longest missions, flying from Whiteman Air Force Base in the United States to Afghanistan and back after refueling. The B-2 also took part in attacks on Iraq from Diego Garcia in the Pacific and other US bases, dropping over 1.5 million pounds of munitions. Additionally, in 2011, B-2 bombers entered Libya as the first American aircraft involved in Operation Odyssey Dawn. By 2025, the bombers were again stationed at Diego Garcia, conducting bombing operations in Yemen.

    B-2 bomber specifications:

    Type: Strategic heavy bomber
    Manufacturer: Northrop Grumman
    Country of manufacture: United States
    First flight: 1989
    Entered service: 1993
    Crew: 2
    Length: 21 m
    Wingspan: 52.4 m
    Height: 5.18 m
    Engine: 4 × General Electric F118-GE-100 engines without afterburner
    Maximum range: 11,000 km
    Combat range: 9,600 km
    Cruise speed: 900 km/h
    Maximum speed: 1,010 km/h
    Rate of climb: 3,000 ft/min
    Service ceiling: 15,240 m
    Endurance: up to 40 hours (estimated)
    Empty weight: 71,700 kg
    Maximum takeoff weight: 170,500 kg
    Payload: 18,000 kg (official), 23,000 kg (estimated)
    Armament:
    Two internal bays with a capacity of 18,000 kg (46,000 lb) of ordnance
    80 × 500 lb class bombs (Mk-82, GBU-38)
    36 × 750 lb class cluster bombs (CBU)
    16 × 2,000 lb class bombs (Mk-84, GBU-31)
    16 × B61 or B83 nuclear bombs
    AGM-154 JSOW and AGM-158 JASSM missiles
    2 × GBU-57 heavy bunker buster bombs

    More images of the B-2 bomber:

    Sources:
    Defense Technical Information Center
    Northrop B-2 Spirit
    Northrop B-2 Spirit
    B-2 Spirit
    Report to Congressional Committees- B-2 Bomber Cost and Operational
    “2009 USAF Almanac, Fact and Figures” – Air Force Magazine
    Why the Air Force Only Has 20 B-2 Spirit Stealth Bombers
    B-2 Bomber: Status of Cost, Development, and Production
    The Bomber Roadmap” – Air Force Magazine
    Inside the Stealth Bomber

  • 359 Missile: Advancing Beyond the Legacy of 358 Missile!

    359 Missile: Advancing Beyond the Legacy of 358 Missile!

    Based on the provided images and information, the 359 loitering missile is larger than the 358 missile, with both its length and diameter nearly doubled.

    The missile features four movable wings at the front and four large fixed wings at the rear. These wings have been proportionately enlarged to match the dimensions of the fuselage. Notably, the rear fixed wings include small control surfaces at their tips, which enhance the missile’s maneuverability and control.

    Read more: 358 Missile; The World’s First Drone-Based Air Defense Missile!

    Control surfaces at the ends of the 359 missile’s rear wings

    The 359 missile features a new, larger engine that boosts its speed to 1,000 kilometers per hour. It has a range of over 150 kilometers and can reach a flight altitude of more than 30,000 feet (9,200 meters).

    One notable improvement of the 359 missile compared to the previous 358 model is its recoverable capability. Unlike the 358, which could not be recovered, the 359 is equipped with a recovery parachute. This means that if the missile fails to intercept a hostile target or is used for reconnaissance and surveillance operations, it can be safely recovered using the parachute.

    The recovery parachute of 359 missile

    The 359 missile is equipped with a significantly larger warhead, which provides enhanced destructive and explosive power compared to its predecessor, the 358 missile. This increased capacity makes the 359 a formidable weapon on the battlefield. Additionally, it can be equipped with an electro-optical payload specifically designed for reconnaissance and surveillance operations, allowing it to gather critical intelligence in situations where a high-explosive warhead may not be necessary.

    In terms of performance, the 359 missile has undergone comprehensive improvements, making it more advanced and effective than the 358. It is now capable of targeting adversaries at higher altitudes and achieving faster speeds. With a maximum flight altitude that surpasses 30,000 feet and a top speed of 1,000 kilometers per hour, the 359 missile can effectively engage airborne warning and control system (AWACS) aircraft as well as aerial refueling tankers.

    Moreover, the missile boasts an extended cruising range of over 150 kilometers, which significantly enhances Iran’s strategic capabilities in air defense. This extended range not only allows for greater flexibility in deployment but also improves the country’s ability to monitor and protect its airspace from potential aerial threats. Overall, the advancements in the 359 missile position it as a critical asset in Iran’s defense arsenal.

    Unveiling of the 359 missile in the television documentary Guardian of the Sky
  • Military Knowledge: Zhubin Suicide Drone

    Military Knowledge: Zhubin Suicide Drone

    The Zhubin, also known as the Fateh, can be described as a mature and efficient product. It was first publicly showcased during a training exercise in 2022 and entered mass production for the Army Ground Forces in 2024.

    This drone features a standard aerodynamic design characterized by an elongated dolphin-shaped body, flat trapezoidal wings, and a V-shaped tail. The body length is 120 cm, and each wing measures 70 cm, resulting in a total wingspan of 140 cm.

    The wings have a trapezoidal shape, which means their width tapers from the root to the tip. This design is commonly employed to evenly distribute air pressure across the wings and optimize lift. However, the reduction in width on the Zhubin drone is minimal and not immediately noticeable. Additionally, the wings are designed to integrate smoothly with the fuselage at a gentle angle, emphasizing stability at medium speeds. The seamless connection of the wings to the fuselage, likely utilizing “Blended Wing Body” techniques, reduces aerodynamic drag and enhances lift.

    Wings in Zhubin drone

    The dolphin-shaped design of this drone is based on streamlined principles to minimize both shape resistance and surface friction. The body tapers in diameter toward the rear, contributing to its aerodynamic efficiency. Its soft curves and absence of sharp corners along the body, wings, and tail reflect a commitment to biomimicry.

    While we cannot definitively identify the material used for the body, indications such as the type of molding and the smooth surface suggest that it is likely made from carbon fiber or fiberglass composites.

    Overall, the Zhubin drone has a relatively low mass of 6.3 kg. This lightweight design enables it to be powered by a low-power electric motor, allowing for flight durations of up to 30 minutes and altitudes of up to 200 meters.

    The nose of this drone features a unique quasi-conical and modular design. This design allows for the accommodation of various types of warheads, including penetrating and fragmentation options, since the drone’s nose is where the warhead is located. The Fateh drone is equipped with a 500-gram warhead made up of small fragments, making it effective for targeting unprotected groups of personnel and equipment.

    The Zhubin features a unique launch method. It is launched using a small pneumatic launcher with a metal base. The components of this launcher include a control module, a hollow metal rod, a pressure regulation system, and a gas cylinder. There is an empty space at the bottom of the drone’s body, just below the engine. During the launch, the launcher’s hollow metal rod is inserted into this space, and high-pressure gas is released to provide the necessary propulsion force for the drone’s initial acceleration. The gas is supplied by small, reusable capsules.

    A special variant of the Zhubin drone has been developed with the capability to be fitted with optical seekers, featuring television lenses in its nose. While specific information about this version’s performance is limited, some visible features include two linear radio antennas and a rotating satellite receiver mounted on top of the fuselage.

    The drone operates using an inertial-satellite guidance system, which may result in target destruction accuracy of up to a few meters. In contrast, the television guidance version offers much greater precision by transmitting images directly to the operator. The stated operational range of this drone is approximately 20 kilometers. However, this range is primarily constrained by radio frequency limitations. With an enhanced guidance system, it could potentially achieve a range of over 30 kilometers.

    One of the relatively interesting things about the Zhoubin drone was the flight of its prototype from a Fateh-class submarine of the Iranian Navy.

    Launch of a Zhubin drone from a Fateh-class submarine

    The Zhubin drone shares many similarities with the Warmate drone. In fact, the Zhubin can be regarded as a successful variant of the Polish Warmate, which has had a notable impact in Ukraine. The Warmate is a type of suicide drone featuring an electric motor and a modular warhead. It is designed and manufactured by WB Electronics, a subsidiary of the WB Group.

    The drone entered the initial production phase in 2016 and was officially adopted by the Polish Armed Forces in the fall of 2017. The primary purpose of the Warmate is to serve as a lightweight, precise, and flexible weapon for close-quarters operations, emphasizing the identification and targeting of various objectives on the battlefield.

    The Warmate drone has been in development since 2010, with the initial version unveiled in 2014. In 2017, the Polish army placed an order for 10,000 units valued at $20 million. The first batch was delivered in 2018 and was immediately deployed in the Ukrainian campaign starting in 2022. Other known customers for this drone include the United Arab Emirates, India, and South Korea.

    Specifications for the Warmate drone include a flight endurance of one hour, an operational range of 30 kilometers, a length of 1.1 meters, and a wingspan of 1.6 meters.

    Overall, the Warmate family serves as a strong model for the continued development of the army’s Zhubin family. The Warmate has various versions, including a launch pod with movable wings that can be kept ready for a long time. This version would be suitable for equipping armored and tactical vehicles.

    Conclusion:

    Suicide drones, such as the Zhoubin, serve a crucial role on modern battlefields as loitering munitions and offer several advantages for tactical operations. With their lightweight and portable design, these drones can easily be transported by ground forces—two people can carry them in a backpack and quickly prepare them for use on the battlefield. Their low mass and straightforward setup allow for rapid deployment in operational conditions, which is essential for responding to sudden threats.

    One of the most significant advantages of the Zhubin drone is its ability to hover over target areas. It can remain airborne for an extended period, identify targets, and attack them with high precision. This feature, combined with the capability to fly in groups, makes the Zhubin particularly effective in destroying moving or concealed targets, such as artillery pieces, bunkers, or concentrations of troops. Additionally, the drone can carry a variety of warheads—including fragmentation, thermobaric, armor-piercing, and explosive warheads—providing great flexibility for different mission requirements.

    The cameras mounted on the drone’s nose enable live image transmission to the operator, enhancing detection and targeting accuracy. Ground control systems, using encrypted communication, ensure operational security and allow for real-time mission adjustments or target changes. Moreover, these drones have a lower operational cost compared to guided missiles and can operate in groups, increasing their effectiveness for detection and attacks on the battlefield. Ultimately, these drones are a powerful tool for military forces in both tactical and combat operations, combining accuracy, versatility, and affordability.

    Specifications of the Zhubin UAV (Fateh UAV):
    Origin: Iran
    Unveiled: 2022
    Length: 120 cm
    Wingspan: 140 cm
    Engine: Electric
    Range: 20 km
    Flight altitude: 200 m
    Flight duration: 30 minutes
    Weight: 6.3 kg
    Warhead weight: 500 g
    Warhead type: Modular

    Zhubin suicide drone (Fateh suicide drone)

    A collection of Zhubin posters in Farsi, Russian, Arabic and Hebrew:

  • Military Knowledge: Raad Suicide Drones

    Military Knowledge: Raad Suicide Drones

    An overview of the Raad drone family

    The Raad family of drones is among the first Iranian unmanned munitions specifically designed for infantry use. These drones feature a standard aerodynamic design similar to other models like the Russian Lancet and the Israeli Hero. With a cylindrical body, two rows of wings, and electric propulsion, along with an electro-optical system integrated into the nose, the Raad drones have a familiar appearance.

    Read more: Military Knowledge: Lancet-3 Suicide Drone

    After modeling itself on Switchblade drones and developing an indigenous version called Meraj 521, the IRGC Ground Force has now also begun to explore the use of other prominent global models.

    Military Knowledge: Meraj-521 Loitering Munition

    Raad-1 drone:

    Currently, there are no available details regarding this drone, leaving its specifications and capabilities shrouded in mystery.

    Raad-2 drone:

    The Raad-2 suicide drone features a wingspan of 1.8 meters and a fuselage length of 1.5 meters. It is capable of flying for up to 17 minutes using an electric motor. With a declared operational range of 20 kilometers, the drone can achieve speeds estimated between 60 and 70 kilometers per hour. Additionally, the Raad-2 carries a 5-kilogram warhead, which can be fitted with various types of fragmentation or explosive warheads.

    It’s worth mentioning that prior to its official unveiling during the second phase of the Great Prophet-19 exercise in 2025, the Ra’ad-2 suicide drone was informally referred to as the Rezvan drone.

    Raad-3 drone:

    The Raad-3 drone has a mission similar to that of the Raad-2, but with some enhancements. It features an increased wingspan of approximately 1.85 meters and a slightly larger fuselage measuring about 2 meters in length. These larger dimensions, along with a more powerful engine, likely enable the drone to carry a greater energy storage capacity. As a result, its flight duration has been extended to 40 minutes, and it can now support a warhead weighing up to 12 kilograms.

    Despite the fact that the Raad family of drones, which have been produced in three versions so far, all use electric propulsion, their launching method is different.

    The Raad-2 UAV features a compact design with retractable wings, enabling efficient storage and launch from a cylindrical chamber. Its wings, each attached by a spring joint, are compressed towards the nose when in the chamber. Upon launch, a rocket booster propels the UAV out of the chamber, and the wings deploy by rotating 90 degrees. This innovative design allows the UAV to be stored and launched from a confined space using a hot gas blast.

    The moment the Raad-2 drone launches and exits the cylindrical chamber
    Launch of the Ra’ad-2 drone during the Great Prophet-19 exercise in 2025

    On the other hand, the box-launching capability of the Raad-2 UAV has enabled the development of multi-launchers for this drone. A specialized multi-purpose launcher has been created for both the Raad-2 and Ghaem-118 UAVs, allowing for the deployment of up to 8 box launchers on Toyota tactical vehicles as well as on the Aras family of vehicles.

    Ra’ad-2 multiple launchers on a tactical vehicle

    Unlike the Raad-2, the Raad-3 features fixed wings and is launched from a rail with the assistance of a rocket booster. The use of rail launchers to provide initial acceleration for drones is common, utilizing hydraulic, pneumatic, or JATO (Jet-Assisted Take-Off) systems. This approach is seen, for example, in different variants of the Russian Lancet-E and other similar drones.

    Raad-3 drone launched from the rail

    The Raad family of drones is equipped with an electro-optical system located in the nose, likely a simple and cost-effective type of television camera. This capability allows the drone to transmit images to the operator via radio communication with low latency. Consequently, the operator can use these images to identify the environment or make decisions about targeting specific objectives.

    It is expected that Raad drones, similar to their foreign counterparts, will eventually be capable of being outfitted with more advanced and multifunctional electro-optical systems, such as thermal or semi-visible cameras for nighttime operations. However, there is currently no official information confirming this.

    Regardless, it is evident that the development of loitering ammunition for infantry and special forces is crucial on modern battlefields.

    Raad-3 UAV Electro-Optical System

    In modern warfare, mobility has become a fundamental principle in the design of ground combat systems. Enhancing the survivability of weapons on the battlefield—especially against enemy counterfire and other threats—demands agility and rapid movement. In this context, mobile multiple rocket launcher systems (MLRS) and self-propelled guns equipped with automatic loading systems are effective weapons. They enable precise and rapid attacks while allowing for immediate repositioning after each operation. This strategy not only boosts firepower but also decreases the likelihood of detection and destruction by the enemy, which is crucial in dynamic, rapid-response combat scenarios. Thus, the significance of the Ra’ad family of drones can be understood within this framework.

    Raad-2 and Raad-3 suicide drones

    It is important to note that, in addition to the Raad family of drones, the IRGC Ground Forces also utilize another similar type of drone known as the Saeqeh family. According to available information, this family was produced as a more cost-effective option and comes in three versions.

    The Saeqeh-1 drone has a flight endurance of 30 minutes and an operational range of 20 kilometers, with the capacity to carry a 1-kilogram warhead. At least in the Saeqeh-1 version, this family of drones is equipped with only a small fixed forward-looking camera located in the nose.

    Saegheh-1 drone

    The concurrent development of these two families of drones raises questions about their roles within the IRGC Ground Forces combat organization. One key question is whether these drones can operate in a network-based manner. This would allow an operator to simultaneously control multiple drones, utilizing one Raad family drone for reconnaissance while deploying several Saeqeh drones for attack missions.

    Today, loitering munitions have evolved beyond their traditional roles, becoming essential in both offensive and defensive missions, including the suppression of enemy air defenses (SEAD). Recent conflicts in the Middle East and Ukraine have underscored the need for tactical advancements that meet infantry requirements, and this has become a pivotal focus for enhancing combat effectiveness. The Iranian armed forces have keenly recognized this trend, dedicating significant attention to developing new technologies and operational capabilities. Notably, this includes innovations such as the Ra’ad and Sa’eqeh suicide drones from the IRGC Ground Force, showcasing a commitment to advancing military strategies. It’s exciting to see how these developments can shape future operations and strengthen Iraninan defense systems!

    The history and evolution of loitering ammunition:

    The concept of “loitering” was first introduced in the military field in the early 1980s. It emerged in response to the widespread development of mobile air defense systems in the Soviet Union and, subsequently, in Eastern Bloc countries. Systems like the SAM-6 (SA-6 Gainful) challenged the doctrine of Western air superiority because, unlike traditional fixed defense systems, they were not permanently stationed in one location. Instead, these mobile systems were activated only when a threat arose and then concealed again after completing their mission.

    At that time, advanced reconnaissance technologies such as modern drones and imaging satellites with today’s capabilities did not exist. Existing spy planes were limited to the technology available during that era. Consequently, detecting mobile defense systems became one of the most challenging military problems.

    SAM6 air defense system mounted on an armored chassis

    For this reason, the United States, as one of the two main poles of the Cold War, along with the Zionist regime, which was involved in severe conflicts with Arab countries at that time, sought to develop weapons that could remain in the operational area for an extended period after launch. These weapons were designed to eliminate targets as soon as they were identified, unlike conventional air-launched or cruise missiles.

    The roots of this strategy can be traced back to the painful experiences of Israeli forces during the Yom Kippur War, where they faced the Soviet-made defense systems of Syria and Egypt. However, new tactics were quickly implemented during Operation Mole Cricket 19 in 1982, aimed at suppressing Syrian air defenses. In this operation, a significant number of unmanned aerial vehicles were used as bait to provoke ground-based defense systems, creating opportunities for the use of anti-radar weapons.

    The successful results of this operation encouraged further investment in drones and loitering munitions throughout the 1980s.

    The Harpy drone, which is based on the South African ARD-10 Lark, along with the American Tacit Rainbow anti-radar missile, were some of the earliest weapons to have this capability in the 1980s. These weapons could essentially “scroll” through the sky to identify and destroy targets at the appropriate moment. However, due to the absence of advanced optical sensors, complex image processing algorithms, and limited radio and satellite communications, these weapons relied heavily on anti-radiation seekers.

    Read more: Military Knowledge: Harop Suicide Drone

    As the 2000s progressed, the limitations of loitering munitions diminished, allowing their role to expand beyond suppressing enemy air defenses (SEAD). The integration of electro-optical systems with advanced image processing and sensors shaped the modern concept of these drones. A notable example is the transformation of the Harpy drone into the Harop. While militaries worldwide began to adopt drones during this period, the focus largely remained on cruise missiles and air-launched weapons. However, this perspective shifted significantly over the following two decades.

    The evolution of loitering munitions advanced with the creation of special forces and infantry versions, emphasizing drone miniaturization to reduce mass and occupied space. This allowed for faster transport and deployment by infantry. Traditional aerodynamic designs like delta wings proved less effective, prompting the exploration of unconventional alternatives. During the 2000s, the United States experimented with small-sized battlefield drones through projects like GLUAV, CCLR, and SBIR, which largely met with limited success. However, these efforts culminated in the development of the Switchblade Block-0 drone in 2004.

    Read more: Military Knowledge: Switchblade Loitering Munition

    Switch-blade drone

    Besides the Switchblade, the Hero series of drones, developed by Israel’s UVision Industries, was among the earliest operational models in this category. Established in 2011, UVision introduced the innovative X-wing design, which has since become a widely adopted standard across various drone manufacturers.

    Hero-30, Hero-120 and Hero-400 drones

    Raad drone posters in Farsi, Russian, Arabic and Hebrew:

  • Military Knowledge: Rampage Missile and EXTRA Rocket; Israel’s Most Widely Used Weapons Against Adversaries!

    Military Knowledge: Rampage Missile and EXTRA Rocket; Israel’s Most Widely Used Weapons Against Adversaries!

    An overview of the development and production history of the Rampage missile:

    The Rampage missile emerged from a collaboration between Israel Military Industries (IMI) and Israel Aerospace Industries (IAI). This partnership traces its origins to the development of the EXTRA series rockets at IMI, from which an air-launched version was created in collaboration with IAI. Initially named MARS (Multi-purpose, Air-launched Rocket System), this version was later marketed as Rampage and is currently produced by the military company Elbit Systems.

    The EXTRA (Extended Range Artillery) is a type of artillery rocket developed by Israel Military Industries (IMI) and has been used by the Israeli army, the Baku government, Vietnam, and Kazakhstan since 2013.

    The EXTRA rocket boasts a maximum range of 150 km, equipped with a 120 kg warhead, and maintains an accuracy of 10 meters at its maximum range.

    Its design features a solid-fuel propellant, stabilizing wings at the rear of the fuselage, and guide fins near the nose. The guidance and control system enhances the missile’s accuracy by four times that of unguided rockets, adjusting the ballistic trajectory to counteract wind drift and other meteorological effects.

    Extended Range Artillery Rocket – EXTRA

    The warhead of this guided rocket is also modular, suitable for carrying different types of submunitions or a single warhead. For example, the EXTRA can carry up to 400 bomblets, anti-runaway munitions or penetrating warheads.

    The Extra rocket is commonly used in the PULS rocket launcher system, formerly known as Lynx. The launcher was originally developed by Israel Military Industries (IMI) and was called Lynx. When IMI was sold to Elbit Systems, the launcher was upgraded and renamed PULS, which stands for Precise & Universal Launching System.

    Elbit Systems promotional video for the PULS Multiple Launch Rocket System

    The PULS system can carry two separate launch pods, each of which can host up to 18 Accular-122 rocket pods with a range of 36 km, 10 Accular-160 rocket pods with a range of 40 km, 4 EXTRA guided rocket pods with a range of 150 km, or two Predator Hawk tactical ballistic missiles.

    Due to the remarkable success of the EXTRA rocket, the development of its air-launched version was also commissioned.

    Rampage missile:

    The Rampage long-range air-to-surface missile is engineered for precision strikes against strategic targets from a safe distance. It minimizes risks to the aircraft and crew, enabling operations beyond the range of enemy air defenses. This offers a significant advantage when targeting high-value fixed or mobile assets, including command centers and air force bases.

    Officially unveiled in June 2018, the Rampage missile was initially developed by Israel Military Industries (IMI) and Israel Aerospace Industries (IAI). On November 25, 2018, Elbit Systems acquired IMI and rebranded it as Elbit Systems Land. Today, Elbit Industries produces the missile.

    Measuring 4.7 meters in length, 306 millimeters in diameter, and weighing 580 kilograms, the Rampage missile boasts excellent operational flexibility. It is compatible with a wide range of Eastern and Western fighter aircraft, eliminating the need for avionics changes. Rampage can be adapted to fighter jets through various methods, such as reprogramming the weapon system or deploying a separate avionics kit in the cockpit.

    The missile’s capability to operate in all weather conditions makes it a reliable option for quick-response attacks, functioning effectively both day and night.

    Additional features of this weapon include pre-programmed or in-flight mission execution, allowing target coordinates to be directly provided to the missile’s flight computer before firing.

    Guidance for the Rampage missile relies on a combination of satellite navigation and internal inertial navigation, with anti-jamming and fire-and-forget capabilities.

    The Rampage missile can be deployed by single-engine or so-called small fighter aircraft, each capable of carrying up to four missiles. The missile’s ease of use allows it to engage a single target or multiple targets simultaneously.

    Rampage missiles can be launched from altitudes of 3,000 to 4,000 feet, at speeds of Mach 0.7 to 0.95, and at angles of 0 to 35 degrees. Depending on the launch type, the missile hits the target at speeds of 350 to 550 meters per second (Mach 1.6), with an accuracy of less than 10 meters, and at a maximum angle of 90 degrees.

    The maximum range of this missile is stated in various sources to be up to 250 kilometers.

    It should be added that this missile is capable of using a diverse range of warheads, including multipurpose, bunker-busting, and fragmentation warheads.

    Operational history:

    The Israeli regime air force uses the Rampage missile extensively. The weapon’s operational history includes the assassination of Mustafa Ahmed Shahdi, deputy commander of Hezbollah’s Radwan forces, and Israeli airstrikes in Yemen.

    On December 26, 2024, the Israeli Air Force targeted several locations in Yemen, including Sana’a International Airport, the Haziz power plants in Sana’a and Ras Qanateb in northern Hodeidah, and military infrastructure in the ports of Hudaydah, Al-Salif, and Ras Qanateb on the west coast of Hudaydah. The operations were primarily carried out by F-15D Eagle, F-16I fighter jets, and KC-707 tankers. The F-16I fighter jets involved in these operations were armed with two Rampage air-launched missiles.

    Israeli attack on Sanaa airport control tower with Rampage air-launched missile

    It is likely that Israeli warplanes used Rampage air-launched missiles in the October 26 attacks against Iran, targeting the Qadir defense installations and radar site in Ahvaz, the Ilam radar site, and the Abadan refinery. The proximity of these targets, all located less than 200 kilometers from the southwestern border with Iraq, supports this possibility.

    Users of Rampage rocket:

    Israel: The Israeli Air Force is the first user of the Rampage missile. This weapon is typically seen in combination with F-16 fighters. Retired Kfir fighters can also be equipped with this missile. Sri Lanka, Ecuador, and Colombia still have this fighter jet in service and are considered potential customers of the Rampage missile.

    India: The Indian Air Force selected the Rampage missile for service in 2024. The force’s fleet includes Sukhoi-30 and MiG-29 fighters. The Indian Navy’s MiG-29 fighters also use this missile.

    Greece: The Hellenic Air Force is considering introducing the Rampage missile for its F-15 fighters.

    Rampage missile specifications:
    Type: Standoff air-to-surface missile
    Manufacturer: Israeli regime
    Unveiled: 2018
    Length: 4.7 meters
    Diameter: 306 mm
    Range: up to 250 km
    Speed: 1.6 Mach
    Accuracy: 10 meters CEP
    Weight: 580 kg
    Warhead: Multipurpose
    Warhead weight: 150 kg
    Flight altitude: 12,190 meters
    Guidance: GPS/INS – IR

    Rampage air-to-surface missile – click to view in full size

    More images of Rampage missile:

    Posters of Rampage missiles in Farsi, Russian and Arabic:

    Source:
    Rampage missile
    Cost effective rocket for aircraft unveiled
    IMI develops air-launched missile that sounds familiar
    New multiple rocket launchers for the Spanish Army
    EXTRA Long-range high precision rocket
    EXTRA – Extended range Rocket System
    Rampage Air-to-Ground Precise Strike Weapon, Israel

  • Military Knowledge: 358 Missile; The World’s First Drone-Based Air Defense Missile!

    Military Knowledge: 358 Missile; The World’s First Drone-Based Air Defense Missile!

    The 358 missile is the world’s first UAV-based defense missile, introducing a groundbreaking defense concept that combines the capabilities of unmanned aerial vehicles (UAVs) and missiles to target hostile aircraft effectively. Iran is the first nation to deploy this type of system in real battlefield conditions. Evidence suggests that this system was first employed by Iran’s regional ally, the Yemeni army (Ansar Allah Movement).

    History:

    According to information disclosed by the IRGC in the documentary “Parchamdar” (Flagship), footage has been released showing the moment an MQ-1B drone was shot down by a 358 missile. So far, four drones of this type have been shot down in Yemen, and the released video likely dates back to 2016 or 2017, during the field testing phase of the 358 missile. Consequently, the design and development of this weapon must have occurred one or two years before the destruction of the MQ-1B drone.

    Image of the destruction of an American MQ-1B belonging to the UAE on the Yemeni front by a 358 missile

    But the official sighting of this missile dates back to 2018 and 2019. In 2018, its wreckage was discovered by the Saudi army, and in 2019, an American warship intercepted and seized a shipment of Iranian weapons en route to Yemen in the Gulf of Aden.

    358 missile design:

    The 358 missile features a cylindrical body measuring 150 mm in diameter and 2.7 meters in length. It employs an infrared imaging seeker (IIR) in its nose to locate and lock onto targets.

    Following the camera, there is a 360-degree laser proximity sensor, and beyond the proximity sensors, a 10-kg fragmentation warhead with an effective radius of 30 meters.

    Components of the 358 missile

    At the front of the missile, just after the warhead, are four movable canards used for guidance. These canards are similar in appearance and function to those on the R-27 missile. They start narrow and sharp, widening towards the tip, and are large enough to provide part of the necessary lift force.

    Alongside the large steering canards, there are four very small triangular fins designed to stabilize airflow during extremely fast, unbalancing turns.

    The middle section of the missile contains the inertial guidance equipment and the missile computer. Additionally, because the antenna is located in this section, the communication equipment is also housed here.

    In the middle section, near the rear of the rocket, are four large fixed wings that generate lift. This section also houses the rocket’s fuel tank.

    At the rear of the missile are four small fixed stabilizer fins and the missile’s mini-jet engine. The engine has four air intakes recessed into the fuselage.

    This missile cannot take off independently, so a rocket booster is installed at the bottom of the missile to assist in the initial launch.

    An examination of shipments seized in 2019 and 2022 by the US and UK reveals that the engine used in the 358 drone is a Titan type from the Dutch company AMT. A review of the supply chain indicates that the engine was purchased indirectly from the manufacturer by a company in Hong Kong.

    The Titan engine has a diameter of 147 mm and a length of 385 mm. It weighs 3645 grams without a starter and 5211 grams with a starter. This engine provides a thrust of 392 newtons, which is equivalent to 88.12 pound-forces, and has a fuel consumption of 43.3 grams per kilonewton per second.

    Announced specifications of the Titan series engines produced by the Dutch company AMT

    The 358 missile has a loitering range of 100 km, a flight ceiling of 8,500 meters, and a speed of 700 km/h, with a total weight of 58 kilograms.

    There is no evidence that the missile can be recovered after firing, so it is used as a loiterer only in areas with a high probability of enemy aircraft. In other scenarios, the 358 missile is kept ready for launch when targets are detected by surveillance cameras and radars.

    The missile can be launched from simple launchers, similar to suicide drones. Additionally, truck launchers have been developed for this missile to enhance stealth.

    One of the most intriguing aspects of the 358 missile is its high level of customization. In its full configuration, the missile has 16 wings and fins. The operator can adjust the number of fins or change the position of the main wing based on specific needs and field conditions. This flexibility significantly enhances the missile’s maneuverability and usability.

    Installation location of the 358 missile wings and fins

    For example, during the official unveiling and hot testing of this missile in the joint air defense exercise “Eghtedar 1403“, the very small triangular fins on the front of the missile, as well as the small fins at the end of the missile, were removed.

    The use of the 358 missile in the Eghtedar 1403 exercise without the small triangular fins on the front section and the small fins at the end of the missile

    How it works:

    The 358 drone-based system consists of two main components: the 358 missile and thermal search cameras. This system can be utilized in two ways:
    The first method involves ground-based thermal search cameras scanning for targets such as drones and helicopters to introduce them to the 358 drone. Radar, serving as an auxiliary element of the system, can help determine the search direction for the ground-based cameras. Once the target is located, the 358 drone is launched and moves towards it. In the final stage, the drone locks onto the target with its thermal seeker and engages it.

    A type of thermal camera used to find aerial targets that has been used in Yemen.

    The second method involves the 358 missile loitering the skies of the battle area where helicopters and drones are likely to be present. By patrolling the tense battle zone, the drone searches for targets preloaded into its computer, such as helicopters and drones. In this mode, the 358 missile can operate either completely independently based on the information in its computer or receive target direction and location updates from the operator. Once it acquires the target, it locks on and engages.

    Promotional video of the preparation and firing of the 358 missile during the Eqtedar 1403 exercise

    Users:

    The 358 missile has been used by Iran, the Iraqi Islamic Resistance, Hezbollah, as well as Ansar Allah and the Yemeni army. Russia could also become a user of this missile if the need arises.

    In 2023, Russian Defense Minister Major General Sergei Shoigu visited an exhibition of Iranian military achievements. During this visit, Brigadier General Hajizadeh, Commander of the IRGC Aerospace Force, introduced the 358 missile and its truck-mounted launcher to Shoigu.

    Similar variants in Yemen:

    As mentioned, the 358 missile is also used by the Yemeni army and has demonstrated significant success in shooting down American and Saudi coalition aircraft.

    It is likely that Yemen has localized the production of this missile. In Yemen, the 358 missile is produced and used under the names Saqar-1 and Saqar-2. The Saqar-1 missile is similar to the 358 missile, while the Saqar-2 missile is an improved version of the Saqar-1 missile.

    Saqar-1 missile

    According to the information officially announced by the Yemeni army regarding the Saqar-1 missile, its specifications are identical to those of the Iranian 358 missile in all its components. However, the specifications of the Saqar-2 resemble those of the Iranian 359 missile, which we will discuss later in the article.

    Based on the information released by the Yemeni army about the Saqar-2 missile, this missile boasts a range of 150 kilometers, which is 50 kilometers more than the Saqar-1 (358 missile). Additionally, the flight altitude has increased from 28,000 feet (8,500 meters) in the Saqar-1 to 35,000 feet (10,600 meters). However, the images published during the latest Yemeni army parade on the occasion of the September 21 Revolution of the Saqar-2 missile actually show the same Saqar-1 missile (missile 358) with a configuration lacking the small triangular fins and fins at the end, as seen in the test and unveiling of the 358 missile in Iran’s Eqtedar 1403 exercise.

    An infographic of the Saqar-2 missile has also been released, stating the missile’s length to be 6 meters. However, upon examining the published images of the Saqar-2 missile during the Yemeni army parade, it is evident that the displayed missile is approximately 3 meters long, similar to the Saqar-1. Therefore, it is likely that the Yemeni army has not published the actual image of the Saqar-2 missile for security reasons. Alternatively, in the most optimistic scenario, a more powerful engine has been used in this version.

    359 missile:

    In 2025, during the broadcast of a television documentary, the Islamic Revolutionary Guard Corps of Iran unveiled a more advanced version of the 358 missile, known as the 359 missile.

    Based on the images and information provided, the 359 missile has larger dimensions than the 358 missile, and its length and diameter have almost doubled.

    Unveiling of the 359 missile in the television documentary Guardian of the Sky

    The missile is equipped with four movable canards at the front and four large fixed wings at the rear. The wings are enlarged in proportion to the fuselage. One of the interesting features of the fixed wings is that small control surfaces are used at the ends of the wings, which improve the maneuverability and control of the missile.

    Control surfaces at the ends of the 359 missile’s rear wings

    The 359 missile features a new and larger engine, which increases its speed to 1,000 kilometers per hour. It has a range of over 150 kilometers and a flight altitude of over 30,000 feet (9,200 meters).

    The warhead of the 359 missile is larger and has greater destructive and explosive power compared to the 358 missile. Additionally, if necessary, the 359 missile can be equipped with an electro-optical payload for reconnaissance and surveillance operations instead of a high-explosive warhead.

    Another notable feature of the 359 missile is its recoverability. According to published images, unlike the 358 missile, which was not recoverable, the 359 missile is equipped with a recovery parachute. Therefore, if the interception of hostile targets is unsuccessful for any reason, or if the 359 missile is used for reconnaissance and surveillance operations, it can be recovered using a parachute.

    Recovery parachute in 359 missile

    More images of the 359 missile:

    It’s worth noting that in 2020, the United States, inspired by the Iranian 358 defense missile, designed and developed a defense system called LIDS. The Coyote-2 interceptor in this system operates in a manner very similar to the 358 missile.

    Military Knowledge: FS-LIDS And M-LIDS Anti-Drone Systems

    358 missile specifications:
    Type: Loitering anti-aircraft missile
    Manufacturer: Islamic Revolutionary Guard Corps
    Country of manufacture: Iran
    Entered service: 2016 to 2019
    Length: 2.7 meters
    Diameter: 150 mm
    Wingspan: Approximately 1 meter
    Missile weight: 58 kg
    Warhead weight: 10 kg high-explosive fragmentation
    Warhead impact radius: 30 meters
    Maximum speed: 700 km/h
    Loitering range: 100 km
    Flying altitude: 8,500 meters (28,000 feet)

    Missile 358 posters in Persian, English, Russian, Chinese, Arabic and Hebrew:

  • Iran Unveils New Jet Suicide Drone: Dalahu (Hadid 110)

    Iran Unveils New Jet Suicide Drone: Dalahu (Hadid 110)

    It is worth noting that this drone, initially introduced as the Hadid-110 at the IRGC’s military achievements exhibition, officially entered the IRGC Ground Forces’ combat organization as the Dalahu drone on February 19, during the second phase of the Great Prophet 19 exercise.

    Unveiling of the Hadid 110 Jet Suicide Drone at the Iranian Military Achievements Exhibition, known as Eghtedar-1403

    The Hadid 110 or Dalahu drone is equipped with a mini jet engine and is launched by a rocket booster, similar to other conventional suicide drones.

    It features a delta wing configuration and a design with sharp edges to reduce its radar cross-section.

    According to provided information, the Dalahu drone’s mini-jet engine gives it a cruise speed of 510 km/h, a range of 350 km, and a flight ceiling of 30,000 feet. The drone’s warhead weighs 30 kg and it has a flight endurance of 1 hour.

    Unveiling of the Hadid 110 or Dalahu Jet Suicide Drone
  • Iran Unveils Underwater-Launched Suicide Drone (Video)

    Iran Unveils Underwater-Launched Suicide Drone (Video)

    In the video, an Unmanned Underwater Vehicle (UUV) surfaces, and the X-winged suicide drone, similar to the recently unveiled Rezvan drones, is launched from within the UUV using a rocket booster.

    Iran Unveils Underwater-Launched Suicide Drone

    The ability to launch drones from underwater vehicles provides a strategic advantage, making it more challenging for adversaries to detect and counter these threats effectively. By integrating these weapons with artificial intelligence capabilities, their effectiveness can be significantly enhanced.

    Indeed, the combination of Unmanned Underwater Vehicles (UUVs) and Unmanned Aerial Vehicles (UAVs) could pose a significant threat to hostile warships in strategic locations like the Persian Gulf, Arabian Sea, and especially the Red Sea! This technological advancement increases Iran and its allies’ defensive and offensive capabilities in these critical maritime regions.

    Iran Unveils Underwater-Launched Suicide Drone
  • Shahid Bagheri Drone Carrier Joins IRGC Navy Fleet (Video)

    Shahid Bagheri Drone Carrier Joins IRGC Navy Fleet (Video)

    Shahid Bagheri (C110-4) drone carrier was officially inducted into the Islamic Revolutionary Guard Corps Navy fleet on February 6. The ceremony was attended by Major General Mohammad Hossein Bagheri, Chief of Staff of the Armed Forces, Major General Hossein Salami, Commander of the IRGC, and Admiral Alireza Tangsiri, Commander of the IRGC Navy.

    Shahid Bagheri drone carrier measures 240 meters in length, 32 meters in width, and has a draft of 12 meters.

    This drone carrier features a 180-meter runway and an upwardly curved ramp, similar to those found on aircraft carriers, to facilitate drone takeoff. The ship is capable of carrying and operating various types of drones and helicopters. Additionally, it has a large space on the lower levels for housing multiple drones, missile-capable speedboats, and more.

    It is reported that the Shahid Bagheri drone carrier has the capacity to carry 60 drones and 30 fast missile boats. This capability significantly enhances its operational flexibility and firepower.

    Like all aircraft carrier or drone carrier class ships, this vessel utilizes an elevator to transport aircraft and other essential items from the hangar to the deck. Behind the bridge, there is a sizable area with a helicopter pad, designated for the ship’s primary helicopter(s). On the unveiling day, this section was covered with a tent for the ceremony and the commanders’ presence. Additionally, it appears that the main missile weapons of the Bagheri drone carrier are situated in this section as well.

    The videos show the 60% scale variant of the Qaem drone being transferred to the ship’s deck by elevator and the 20% scale variant undergoing a flight test. These videos are archived and are not from the day of the joining ceremony.

    Regarding armament, the Bagheri drone carrier is currently equipped with eight Kowsar 222 air defense missiles, each with a range of 17 km, positioned at the front and rear of the ship. Additionally, there are eight anti-ship missiles from the Qader/Nasir series, comprising four twin launchers, located behind the bridge. There is also a container in this section that probably contains two ballistic missiles. The vessel also features a single-barreled 30 mm cannon with an electro-optical system at the front and two triple-barreled 20 mm Asefeh Gatling guns situated at the rear and stern.

    Admiral Tangsiri’s explanation about IRIS Shahid Baqeri

    According to Admiral Tangsiri, Commander of the IRGC Navy, the Shahid Bahman Bagheri drone carrier is equipped with the following specifications and features:

    • Speed of 22 knots
    • Fast attack boats capable of firing missiles with a range of 30 kilometers
    • Drone combat group (reconnaissance, surveillance, and combat)
    • Attack and support helicopter combat flotilla
    • Submarine combat team
    • Six-bed specialized hospital and various medical and welfare facilities
    • 180-meter runway
    • Three separate fueling stations for helicopters, drones, and vessels
    • Electronic warfare teams
    • Missile defense systems
    • Special commando operations capabilities
    • Diving team
    • Long-range surface-to-surface missiles
    • Drone and helicopter control tower
    • Drone squadron
    • Eight two-story hangars
    • Ability to operate continuously for one year

    One of the most intriguing aspects of adding this drone carrier is the unveiling and deployment of the Qaem Jet drones. The Qaem (Ghaem) drone, also known as Qaher 313, has been observed in two versions—60% and 20%—on Shahid Bagheri drone carrier. It remains uncertain if the 100% scale variant of the Qaem drone will also be deployed on this carrier.

    As previously mentioned, Shahid Bagheri drone carrier is equipped with missile-launching fast craft. These fast craft are launched into the water using overhead cranes located on the sides of the ship.

    Iran can utilize drone carriers as floating bases in nearby waters or international waters to conduct various operations, including reconnaissance, intelligence, and combat missions. The United States, China, Russia, and Turkey have previously employed this capability at sea.

    The name of this ship, Shahid Bagheri, honors martyr Bahman Bagheri, who was martyred in 1988 during the Iran-Iraq War at Faw. Bahman Bagheri was a prominent martyr of the IRGC and served as the commander of communications at the IRGC Navy’s Nuh Base during the war.

    Ababil-3 drone landing and takeoff from the deck of the IRGC Navy’s Shahid Bahman Bagheri drone carrier

    Shahid Bagheri Drone Carrier specifications:
    Commissioned: February 6, 2025
    Length: 240 meters
    Beam: 32 meters
    Draft: 12 meters
    Speed: 22 kn
    Displacement: 42,000 tons
    Endurance: 1,000 days
    Missile arsenal:
    8 air defensive missiles
    8 anti-ship missiles
    Guns:
    1x 30 mm automatic cannon
    2x 20 mm Asefeh cannons
    Aircraft carried: 60 UAVs and various types of helicopters
    Boat carried: 30 fast missile boats
    Made by: Iran
