  • Military Knowledge: B-2 Spirit Stealth Bomber

    Military Knowledge: B-2 Spirit Stealth Bomber

    Introduction:
    In the 1980s, global advancements in air defense systems significantly threatened the United States Air Force’s capability to hit crucial enemy targets. To counter this challenge, the Air Force adopted cutting-edge stealth technology for a long-range bomber designed to carry substantial payloads, both conventional and nuclear. The B-2 Spirit, developed by Northrop Grumman, achieved a level of invisibility to advanced radars that was unprecedented at the time, utilizing a flying wing configuration, innovative composite materials, specialized coatings, and secret stealth technologies.

    B-2 bomber

    The aircraft was first unveiled to the public in November 22, 1988, at Air Force Plant 42 in California and completed its first test flight in July 17, 1989. After undergoing development, the first operational B-2 was delivered to the United States Air Force in December 17, 1993. The bomber, whose primary base is Whiteman Air Force Base in Missouri, has participated in various operations, the most significant of which include Operation Allied Force in Serbia in 1999, Operation Enduring Freedom in Afghanistan in 2001, and Operation Iraqi Freedom in Iraq in 2003.

    The B-2 Spirit can conduct combat missions for over 30 hours without a break, operated by a crew of two (a pilot and a mission commander). It has the capacity to carry precision-guided munitions weighing up to 40,000 pounds for each mission. Earlier B-2 models were subjected to extensive environmental tests, including 1,000 hours of temperature evaluations at the McKinley Climatic Laboratory, ranging from -65 to 120 degrees Fahrenheit. The results of these tests, later confirmed in Alaska, proved that the B-2 Spirit is not only capable of withstanding various climatic challenges but also effectively executes strategic missions with minimal radar detection by adversaries.

    History and development of the B-2 bomber:

    The concept of ​​designing a stealth bomber dates back to the 1940s and 1950s when Northrop sought to introduce a new approach to military aircraft by developing advanced flying wing designs like the YB-35 and YB-49. This design, lacking a traditional tail, significantly reduced the radar cross-section and could have revolutionized air tactics if completed. However, at that time, the absence of advanced control systems and technological limitations led to these projects being shelved.

    In the 1970s, advances in radar-absorbing technologies, advanced composite materials, and digital computing reignited the United States Air Force’s interest in developing a stealth bomber. The Vietnam War experience and the increasing threat of Soviet air defenses underscored the necessity for a strategic aircraft capable of penetrating deep into enemy territory undetected.

    In 1979, the United States Air Force launched the Advanced Technology Bomber (ATB) program, which aimed to develop a stealthy strategic bomber capable of striking deep into enemy territory. The project was highly classified, with information only available to a select few senior officials.

    Northrop and Lockheed competed for the program. Lockheed, known for its success with the F-117 Nighthawk stealth fighter, proposed a design aligned with those principles. However, Northrop ultimately proved its superiority by creating a flying-wing bomber, securing the contract for the program’s development in 1981.

    However, Northrop’s design, which integrated a distinctive aerodynamic shape, radar-absorbing materials, and fully digital flight systems, set the stage for a new era of strategic bombers. The outcome of this initiative, the B-2 Spirit, surpassed all previous bombers in both design sophistication and operational capabilities at the time.

    Visual comparison of Northrop (top image) and Lockheed and McDonnell-Douglas designs

    The soaring costs and technical difficulties of the program attracted significant criticism in Congress. By the early 1980s, the estimated project cost was $22.1 billion, but as it advanced, the combination of technical hurdles and escalating research and development expenses caused this estimate to climb to $44.7 billion by 1988. Ultimately, taking into account research and development, production, maintenance, and upgrades, the entire B-2 program cost totaled $101 billion, making each aircraft approximately $2.1 billion. In 1992, the Bush administration opted to cut the aircraft production from 132 to a mere 21. The anticipated cost for producing the 20 aircraft was about $26.8 billion. This assessment bolstered the case against any additional B-2 production. Consequently, Congress decided to stop further production, maintaining 20 operational aircraft and 1 experimental one in service.

    Its high maintenance costs and limited fleet prompted the US Air Force to announce in 2018 that the bomber would be retired by 2032, to be replaced by the B-21 Raider, a new generation of stealth bombers.

    B-2 design and technical features:

    A standout aspect of the B-2’s design is its distinctive flying wing structure, which lacks any vertical or horizontal tails. This feature is intended to minimize radar reflection. The tailless configuration, combined with its expansive wings, effectively lowers the radar cross-section (RCS), enhancing its stealth capabilities. Consequently, the B-2 can operate at high speeds and altitudes while remaining undetectable to enemy radars. Measuring 21 meters in length, 5.18 meters in height, and boasting a wingspan of 52.4 meters, this aircraft ranks among the largest stealth platforms globally.

    The B-2’s flying wing design

    Since the B-2 is a traditional airframeless aircraft, integrating strength into its structure required the use of advanced materials. For this purpose, special composites such as carbon fiber and metal compounds were used in the fuselage structure, as they are lightweight while also providing high strength and excellent radar absorption. Additionally, to withstand the stresses and pressures from flying at very high altitudes, the body was designed to endure extreme changes in temperature and air pressure.

    B-2 Avionics and Guidance Systems:

    Another notable feature of the B-2 is its advanced avionics. One of these systems is the AN/APQ-181 multi-purpose radar, designed to detect and track targets under various flight conditions. With its capability to operate in multiple bands, this radar enables the B-2 to identify its targets across a broad spectrum. The system employs radar stealth technology to conduct precise reconnaissance without being detected by enemy defense systems.

    The AN/APQ-181 radar is among the most advanced terrain mapping and tracking systems designed specifically for the B-2 Spirit stealth bomber. It operates in the G-band and features 21 operational modes, including terrain tracking, navigation, target acquisition, tracking, and weapons guidance.

    The AN/APQ-181 features a modular design that enhances capabilities and reduces failure rates. This system employs two electronically scanned array antennas, providing a broad field of view that covers the front and sides of the aircraft. The radar consists of 10 modular replaceable units (LRUs), with a combined weight of 955 kg and a volume of 1.485 cubic meters. Each antenna has a weight of 260 kg. Designed to meet the MIL-STD-1553 standard, the AN/APQ-181 system is resistant to electromagnetic interference as well as the effects of electromagnetic pulses (EMP). Additionally, the radar is optimized for challenging operating conditions, including low-altitude and high-speed flights. In response to the growing demand for the frequency spectrum by commercial communications systems, the US Air Force initiated a program in 2004 to upgrade this radar to an active phased array (AESA) system.

    Alongside radar, the B-2’s sophisticated navigation system incorporates GPS and astro-inertial technology, ensuring accurate guidance through lengthy and perilous routes. These systems are designed to function optimally, even in electronic warfare environments, with the ability to autonomously correct their course when necessary.

    Stealth of the B-2 bomber:

    Stealth is a key feature of the B-2, enabling the aircraft to stay concealed from modern detection systems such as multi-band radars and infrared sensors. To achieve this goal, the B-2’s airframe was designed to minimize radar reflection by reducing its radar cross-section (RCS). The delta-shaped flying wing configuration, along with the airframe’s sharply angled surfaces that reduce radar reflection, collectively enhance the B-2’s stealth capabilities. The B-2 reportedly has a radar cross-section of about 0.1 square meters.

    Image of the B-2 radar’s initial reflection angles

    Another stealth feature of the B-2 is the use of special radar-absorbing coatings called Radar Absorbent Material (RAM). These coatings are applied throughout the aircraft’s body to absorb radar waves, thereby minimizing its radar cross-section.

    To lower its thermal signature, the B-2’s engines are uniquely positioned within the body, and their exhaust is carefully shrouded to reduce heat visibility. Additionally, ventilation and cooling systems for the engine’s intake air, combined with efforts to decrease exhaust temperature, effectively minimize the B-2’s thermal signature.

    B2 engines specially designed within the body to minimize thermal signature

    Engine power and performance of the B-2 bomber:

    The B-2 bomber features four General Electric GE-100 non-afterburning turbofan engines, generating 77 kilonewtons (17,300 pounds) of thrust. These uniquely designed engines enable the B-2 to achieve speeds exceeding 630 mph (1,010 km/h) at an altitude of 40,000 feet (12,000 m). Additionally, the aircraft can cruise at 560 mph (900 km/h) at the same elevation. With an operational range of approximately 6,800 miles (11,000 km), the B-2 is equipped for long-range missions.

    Armament and carrying capacity of the B-2 bomber:

    The bomber can carry 40,000 pounds (18,000 kg) of ordnance, which may consist of both nuclear and conventional weapons. Since the Cold War concluded, modifications have enabled the aircraft to effectively deploy conventional armaments as well. It has the capacity to hold up to 80 500-pound bombs, 36 750-pound bombs, and 16 2,000-pound bombs in its two bays. Additionally, the bomber is outfitted with long-range weapons such as the AGM-154 Joint Standoff Weapon (JSOW) and the AGM-158 Joint Air-to-Surface Standoff Missile (JASSM).

    To complement the aircraft’s military capabilities, the B-2 is also designed to carry two massive Massive Ordnance Penetrator (MOP) bombs. The 14-ton GBU-57 bunker-busting bomb is ideal for destroying bomb-resistant structures such as bunkers and fortified underground facilities. The B-2 is one of the few platforms capable of delivering these bombs.

    The cockpit and flight crew of the B-2 bomber:

    The B-2 bomber features an advanced, automated cockpit managed by two pilots. The primary pilot sits on the left, while the mission commander is located on the right. This arrangement enables the flight crew to continuously and seamlessly monitor systems and conduct intricate operations. Additionally, the aircraft is equipped with sophisticated systems that minimize flight crew fatigue, enabling one member to rest or utilize the aircraft’s amenities during extended flights.

    B-2 bomber cockpit

    B-2 Missions and Operations:

    Since entering service in the 1990s, the B-2 Spirit has participated in numerous important military missions. Its first operational appearance occurred during the Kosovo War in 1999, where the B-2 played a significant role in destroying targeted sites, dropping 11 percent of the bombs used in the conflict. The aircraft also marked the first use of JDAM smart bombs.

    In the 2000s, B-2 bombers played a crucial role in the Afghanistan and Iraq wars. They undertook one of their longest missions, flying from Whiteman Air Force Base in the United States to Afghanistan and back after refueling. The B-2 also took part in attacks on Iraq from Diego Garcia in the Pacific and other US bases, dropping over 1.5 million pounds of munitions. Additionally, in 2011, B-2 bombers entered Libya as the first American aircraft involved in Operation Odyssey Dawn. By 2025, the bombers were again stationed at Diego Garcia, conducting bombing operations in Yemen.

    B-2 bomber specifications:

    Type: Strategic heavy bomber
    Manufacturer: Northrop Grumman
    Country of manufacture: United States
    First flight: 1989
    Entered service: 1993
    Crew: 2
    Length: 21 m
    Wingspan: 52.4 m
    Height: 5.18 m
    Engine: 4 × General Electric F118-GE-100 engines without afterburner
    Maximum range: 11,000 km
    Combat range: 9,600 km
    Cruise speed: 900 km/h
    Maximum speed: 1,010 km/h
    Rate of climb: 3,000 ft/min
    Service ceiling: 15,240 m
    Endurance: up to 40 hours (estimated)
    Empty weight: 71,700 kg
    Maximum takeoff weight: 170,500 kg
    Payload: 18,000 kg (official), 23,000 kg (estimated)
    Armament:
    Two internal bays with a capacity of 18,000 kg (46,000 lb) of ordnance
    80 × 500 lb class bombs (Mk-82, GBU-38)
    36 × 750 lb class cluster bombs (CBU)
    16 × 2,000 lb class bombs (Mk-84, GBU-31)
    16 × B61 or B83 nuclear bombs
    AGM-154 JSOW and AGM-158 JASSM missiles
    2 × GBU-57 heavy bunker buster bombs

    More images of the B-2 bomber:

    Sources:
    Defense Technical Information Center
    Northrop B-2 Spirit
    Northrop B-2 Spirit
    B-2 Spirit
    Report to Congressional Committees- B-2 Bomber Cost and Operational
    “2009 USAF Almanac, Fact and Figures” – Air Force Magazine
    Why the Air Force Only Has 20 B-2 Spirit Stealth Bombers
    B-2 Bomber: Status of Cost, Development, and Production
    The Bomber Roadmap” – Air Force Magazine
    Inside the Stealth Bomber

  • Military Knowledge: Zhubin Suicide Drone

    Military Knowledge: Zhubin Suicide Drone

    The Zhubin, also known as the Fateh, can be described as a mature and efficient product. It was first publicly showcased during a training exercise in 2022 and entered mass production for the Army Ground Forces in 2024.

    This drone features a standard aerodynamic design characterized by an elongated dolphin-shaped body, flat trapezoidal wings, and a V-shaped tail. The body length is 120 cm, and each wing measures 70 cm, resulting in a total wingspan of 140 cm.

    The wings have a trapezoidal shape, which means their width tapers from the root to the tip. This design is commonly employed to evenly distribute air pressure across the wings and optimize lift. However, the reduction in width on the Zhubin drone is minimal and not immediately noticeable. Additionally, the wings are designed to integrate smoothly with the fuselage at a gentle angle, emphasizing stability at medium speeds. The seamless connection of the wings to the fuselage, likely utilizing “Blended Wing Body” techniques, reduces aerodynamic drag and enhances lift.

    Wings in Zhubin drone

    The dolphin-shaped design of this drone is based on streamlined principles to minimize both shape resistance and surface friction. The body tapers in diameter toward the rear, contributing to its aerodynamic efficiency. Its soft curves and absence of sharp corners along the body, wings, and tail reflect a commitment to biomimicry.

    While we cannot definitively identify the material used for the body, indications such as the type of molding and the smooth surface suggest that it is likely made from carbon fiber or fiberglass composites.

    Overall, the Zhubin drone has a relatively low mass of 6.3 kg. This lightweight design enables it to be powered by a low-power electric motor, allowing for flight durations of up to 30 minutes and altitudes of up to 200 meters.

    The nose of this drone features a unique quasi-conical and modular design. This design allows for the accommodation of various types of warheads, including penetrating and fragmentation options, since the drone’s nose is where the warhead is located. The Fateh drone is equipped with a 500-gram warhead made up of small fragments, making it effective for targeting unprotected groups of personnel and equipment.

    The Zhubin features a unique launch method. It is launched using a small pneumatic launcher with a metal base. The components of this launcher include a control module, a hollow metal rod, a pressure regulation system, and a gas cylinder. There is an empty space at the bottom of the drone’s body, just below the engine. During the launch, the launcher’s hollow metal rod is inserted into this space, and high-pressure gas is released to provide the necessary propulsion force for the drone’s initial acceleration. The gas is supplied by small, reusable capsules.

    A special variant of the Zhubin drone has been developed with the capability to be fitted with optical seekers, featuring television lenses in its nose. While specific information about this version’s performance is limited, some visible features include two linear radio antennas and a rotating satellite receiver mounted on top of the fuselage.

    The drone operates using an inertial-satellite guidance system, which may result in target destruction accuracy of up to a few meters. In contrast, the television guidance version offers much greater precision by transmitting images directly to the operator. The stated operational range of this drone is approximately 20 kilometers. However, this range is primarily constrained by radio frequency limitations. With an enhanced guidance system, it could potentially achieve a range of over 30 kilometers.

    One of the relatively interesting things about the Zhoubin drone was the flight of its prototype from a Fateh-class submarine of the Iranian Navy.

    Launch of a Zhubin drone from a Fateh-class submarine

    The Zhubin drone shares many similarities with the Warmate drone. In fact, the Zhubin can be regarded as a successful variant of the Polish Warmate, which has had a notable impact in Ukraine. The Warmate is a type of suicide drone featuring an electric motor and a modular warhead. It is designed and manufactured by WB Electronics, a subsidiary of the WB Group.

    The drone entered the initial production phase in 2016 and was officially adopted by the Polish Armed Forces in the fall of 2017. The primary purpose of the Warmate is to serve as a lightweight, precise, and flexible weapon for close-quarters operations, emphasizing the identification and targeting of various objectives on the battlefield.

    The Warmate drone has been in development since 2010, with the initial version unveiled in 2014. In 2017, the Polish army placed an order for 10,000 units valued at $20 million. The first batch was delivered in 2018 and was immediately deployed in the Ukrainian campaign starting in 2022. Other known customers for this drone include the United Arab Emirates, India, and South Korea.

    Specifications for the Warmate drone include a flight endurance of one hour, an operational range of 30 kilometers, a length of 1.1 meters, and a wingspan of 1.6 meters.

    Overall, the Warmate family serves as a strong model for the continued development of the army’s Zhubin family. The Warmate has various versions, including a launch pod with movable wings that can be kept ready for a long time. This version would be suitable for equipping armored and tactical vehicles.

    Conclusion:

    Suicide drones, such as the Zhoubin, serve a crucial role on modern battlefields as loitering munitions and offer several advantages for tactical operations. With their lightweight and portable design, these drones can easily be transported by ground forces—two people can carry them in a backpack and quickly prepare them for use on the battlefield. Their low mass and straightforward setup allow for rapid deployment in operational conditions, which is essential for responding to sudden threats.

    One of the most significant advantages of the Zhubin drone is its ability to hover over target areas. It can remain airborne for an extended period, identify targets, and attack them with high precision. This feature, combined with the capability to fly in groups, makes the Zhubin particularly effective in destroying moving or concealed targets, such as artillery pieces, bunkers, or concentrations of troops. Additionally, the drone can carry a variety of warheads—including fragmentation, thermobaric, armor-piercing, and explosive warheads—providing great flexibility for different mission requirements.

    The cameras mounted on the drone’s nose enable live image transmission to the operator, enhancing detection and targeting accuracy. Ground control systems, using encrypted communication, ensure operational security and allow for real-time mission adjustments or target changes. Moreover, these drones have a lower operational cost compared to guided missiles and can operate in groups, increasing their effectiveness for detection and attacks on the battlefield. Ultimately, these drones are a powerful tool for military forces in both tactical and combat operations, combining accuracy, versatility, and affordability.

    Specifications of the Zhubin UAV (Fateh UAV):
    Origin: Iran
    Unveiled: 2022
    Length: 120 cm
    Wingspan: 140 cm
    Engine: Electric
    Range: 20 km
    Flight altitude: 200 m
    Flight duration: 30 minutes
    Weight: 6.3 kg
    Warhead weight: 500 g
    Warhead type: Modular

    Zhubin suicide drone (Fateh suicide drone)

    A collection of Zhubin posters in Farsi, Russian, Arabic and Hebrew:

  • Military Knowledge: Raad Suicide Drones

    Military Knowledge: Raad Suicide Drones

    An overview of the Raad drone family

    The Raad family of drones is among the first Iranian unmanned munitions specifically designed for infantry use. These drones feature a standard aerodynamic design similar to other models like the Russian Lancet and the Israeli Hero. With a cylindrical body, two rows of wings, and electric propulsion, along with an electro-optical system integrated into the nose, the Raad drones have a familiar appearance.

    Read more: Military Knowledge: Lancet-3 Suicide Drone

    After modeling itself on Switchblade drones and developing an indigenous version called Meraj 521, the IRGC Ground Force has now also begun to explore the use of other prominent global models.

    Military Knowledge: Meraj-521 Loitering Munition

    Raad-1 drone:

    Currently, there are no available details regarding this drone, leaving its specifications and capabilities shrouded in mystery.

    Raad-2 drone:

    The Raad-2 suicide drone features a wingspan of 1.8 meters and a fuselage length of 1.5 meters. It is capable of flying for up to 17 minutes using an electric motor. With a declared operational range of 20 kilometers, the drone can achieve speeds estimated between 60 and 70 kilometers per hour. Additionally, the Raad-2 carries a 5-kilogram warhead, which can be fitted with various types of fragmentation or explosive warheads.

    It’s worth mentioning that prior to its official unveiling during the second phase of the Great Prophet-19 exercise in 2025, the Ra’ad-2 suicide drone was informally referred to as the Rezvan drone.

    Raad-3 drone:

    The Raad-3 drone has a mission similar to that of the Raad-2, but with some enhancements. It features an increased wingspan of approximately 1.85 meters and a slightly larger fuselage measuring about 2 meters in length. These larger dimensions, along with a more powerful engine, likely enable the drone to carry a greater energy storage capacity. As a result, its flight duration has been extended to 40 minutes, and it can now support a warhead weighing up to 12 kilograms.

    Despite the fact that the Raad family of drones, which have been produced in three versions so far, all use electric propulsion, their launching method is different.

    The Raad-2 UAV features a compact design with retractable wings, enabling efficient storage and launch from a cylindrical chamber. Its wings, each attached by a spring joint, are compressed towards the nose when in the chamber. Upon launch, a rocket booster propels the UAV out of the chamber, and the wings deploy by rotating 90 degrees. This innovative design allows the UAV to be stored and launched from a confined space using a hot gas blast.

    The moment the Raad-2 drone launches and exits the cylindrical chamber
    Launch of the Ra’ad-2 drone during the Great Prophet-19 exercise in 2025

    On the other hand, the box-launching capability of the Raad-2 UAV has enabled the development of multi-launchers for this drone. A specialized multi-purpose launcher has been created for both the Raad-2 and Ghaem-118 UAVs, allowing for the deployment of up to 8 box launchers on Toyota tactical vehicles as well as on the Aras family of vehicles.

    Ra’ad-2 multiple launchers on a tactical vehicle

    Unlike the Raad-2, the Raad-3 features fixed wings and is launched from a rail with the assistance of a rocket booster. The use of rail launchers to provide initial acceleration for drones is common, utilizing hydraulic, pneumatic, or JATO (Jet-Assisted Take-Off) systems. This approach is seen, for example, in different variants of the Russian Lancet-E and other similar drones.

    Raad-3 drone launched from the rail

    The Raad family of drones is equipped with an electro-optical system located in the nose, likely a simple and cost-effective type of television camera. This capability allows the drone to transmit images to the operator via radio communication with low latency. Consequently, the operator can use these images to identify the environment or make decisions about targeting specific objectives.

    It is expected that Raad drones, similar to their foreign counterparts, will eventually be capable of being outfitted with more advanced and multifunctional electro-optical systems, such as thermal or semi-visible cameras for nighttime operations. However, there is currently no official information confirming this.

    Regardless, it is evident that the development of loitering ammunition for infantry and special forces is crucial on modern battlefields.

    Raad-3 UAV Electro-Optical System

    In modern warfare, mobility has become a fundamental principle in the design of ground combat systems. Enhancing the survivability of weapons on the battlefield—especially against enemy counterfire and other threats—demands agility and rapid movement. In this context, mobile multiple rocket launcher systems (MLRS) and self-propelled guns equipped with automatic loading systems are effective weapons. They enable precise and rapid attacks while allowing for immediate repositioning after each operation. This strategy not only boosts firepower but also decreases the likelihood of detection and destruction by the enemy, which is crucial in dynamic, rapid-response combat scenarios. Thus, the significance of the Ra’ad family of drones can be understood within this framework.

    Raad-2 and Raad-3 suicide drones

    It is important to note that, in addition to the Raad family of drones, the IRGC Ground Forces also utilize another similar type of drone known as the Saeqeh family. According to available information, this family was produced as a more cost-effective option and comes in three versions.

    The Saeqeh-1 drone has a flight endurance of 30 minutes and an operational range of 20 kilometers, with the capacity to carry a 1-kilogram warhead. At least in the Saeqeh-1 version, this family of drones is equipped with only a small fixed forward-looking camera located in the nose.

    Saegheh-1 drone

    The concurrent development of these two families of drones raises questions about their roles within the IRGC Ground Forces combat organization. One key question is whether these drones can operate in a network-based manner. This would allow an operator to simultaneously control multiple drones, utilizing one Raad family drone for reconnaissance while deploying several Saeqeh drones for attack missions.

    Today, loitering munitions have evolved beyond their traditional roles, becoming essential in both offensive and defensive missions, including the suppression of enemy air defenses (SEAD). Recent conflicts in the Middle East and Ukraine have underscored the need for tactical advancements that meet infantry requirements, and this has become a pivotal focus for enhancing combat effectiveness. The Iranian armed forces have keenly recognized this trend, dedicating significant attention to developing new technologies and operational capabilities. Notably, this includes innovations such as the Ra’ad and Sa’eqeh suicide drones from the IRGC Ground Force, showcasing a commitment to advancing military strategies. It’s exciting to see how these developments can shape future operations and strengthen Iraninan defense systems!

    The history and evolution of loitering ammunition:

    The concept of “loitering” was first introduced in the military field in the early 1980s. It emerged in response to the widespread development of mobile air defense systems in the Soviet Union and, subsequently, in Eastern Bloc countries. Systems like the SAM-6 (SA-6 Gainful) challenged the doctrine of Western air superiority because, unlike traditional fixed defense systems, they were not permanently stationed in one location. Instead, these mobile systems were activated only when a threat arose and then concealed again after completing their mission.

    At that time, advanced reconnaissance technologies such as modern drones and imaging satellites with today’s capabilities did not exist. Existing spy planes were limited to the technology available during that era. Consequently, detecting mobile defense systems became one of the most challenging military problems.

    SAM6 air defense system mounted on an armored chassis

    For this reason, the United States, as one of the two main poles of the Cold War, along with the Zionist regime, which was involved in severe conflicts with Arab countries at that time, sought to develop weapons that could remain in the operational area for an extended period after launch. These weapons were designed to eliminate targets as soon as they were identified, unlike conventional air-launched or cruise missiles.

    The roots of this strategy can be traced back to the painful experiences of Israeli forces during the Yom Kippur War, where they faced the Soviet-made defense systems of Syria and Egypt. However, new tactics were quickly implemented during Operation Mole Cricket 19 in 1982, aimed at suppressing Syrian air defenses. In this operation, a significant number of unmanned aerial vehicles were used as bait to provoke ground-based defense systems, creating opportunities for the use of anti-radar weapons.

    The successful results of this operation encouraged further investment in drones and loitering munitions throughout the 1980s.

    The Harpy drone, which is based on the South African ARD-10 Lark, along with the American Tacit Rainbow anti-radar missile, were some of the earliest weapons to have this capability in the 1980s. These weapons could essentially “scroll” through the sky to identify and destroy targets at the appropriate moment. However, due to the absence of advanced optical sensors, complex image processing algorithms, and limited radio and satellite communications, these weapons relied heavily on anti-radiation seekers.

    Read more: Military Knowledge: Harop Suicide Drone

    As the 2000s progressed, the limitations of loitering munitions diminished, allowing their role to expand beyond suppressing enemy air defenses (SEAD). The integration of electro-optical systems with advanced image processing and sensors shaped the modern concept of these drones. A notable example is the transformation of the Harpy drone into the Harop. While militaries worldwide began to adopt drones during this period, the focus largely remained on cruise missiles and air-launched weapons. However, this perspective shifted significantly over the following two decades.

    The evolution of loitering munitions advanced with the creation of special forces and infantry versions, emphasizing drone miniaturization to reduce mass and occupied space. This allowed for faster transport and deployment by infantry. Traditional aerodynamic designs like delta wings proved less effective, prompting the exploration of unconventional alternatives. During the 2000s, the United States experimented with small-sized battlefield drones through projects like GLUAV, CCLR, and SBIR, which largely met with limited success. However, these efforts culminated in the development of the Switchblade Block-0 drone in 2004.

    Read more: Military Knowledge: Switchblade Loitering Munition

    Switch-blade drone

    Besides the Switchblade, the Hero series of drones, developed by Israel’s UVision Industries, was among the earliest operational models in this category. Established in 2011, UVision introduced the innovative X-wing design, which has since become a widely adopted standard across various drone manufacturers.

    Hero-30, Hero-120 and Hero-400 drones

    Raad drone posters in Farsi, Russian, Arabic and Hebrew:

  • Military Knowledge: Rampage Missile and EXTRA Rocket; Israel’s Most Widely Used Weapons Against Adversaries!

    Military Knowledge: Rampage Missile and EXTRA Rocket; Israel’s Most Widely Used Weapons Against Adversaries!

    An overview of the development and production history of the Rampage missile:

    The Rampage missile emerged from a collaboration between Israel Military Industries (IMI) and Israel Aerospace Industries (IAI). This partnership traces its origins to the development of the EXTRA series rockets at IMI, from which an air-launched version was created in collaboration with IAI. Initially named MARS (Multi-purpose, Air-launched Rocket System), this version was later marketed as Rampage and is currently produced by the military company Elbit Systems.

    The EXTRA (Extended Range Artillery) is a type of artillery rocket developed by Israel Military Industries (IMI) and has been used by the Israeli army, the Baku government, Vietnam, and Kazakhstan since 2013.

    The EXTRA rocket boasts a maximum range of 150 km, equipped with a 120 kg warhead, and maintains an accuracy of 10 meters at its maximum range.

    Its design features a solid-fuel propellant, stabilizing wings at the rear of the fuselage, and guide fins near the nose. The guidance and control system enhances the missile’s accuracy by four times that of unguided rockets, adjusting the ballistic trajectory to counteract wind drift and other meteorological effects.

    Extended Range Artillery Rocket – EXTRA

    The warhead of this guided rocket is also modular, suitable for carrying different types of submunitions or a single warhead. For example, the EXTRA can carry up to 400 bomblets, anti-runaway munitions or penetrating warheads.

    The Extra rocket is commonly used in the PULS rocket launcher system, formerly known as Lynx. The launcher was originally developed by Israel Military Industries (IMI) and was called Lynx. When IMI was sold to Elbit Systems, the launcher was upgraded and renamed PULS, which stands for Precise & Universal Launching System.

    Elbit Systems promotional video for the PULS Multiple Launch Rocket System

    The PULS system can carry two separate launch pods, each of which can host up to 18 Accular-122 rocket pods with a range of 36 km, 10 Accular-160 rocket pods with a range of 40 km, 4 EXTRA guided rocket pods with a range of 150 km, or two Predator Hawk tactical ballistic missiles.

    Due to the remarkable success of the EXTRA rocket, the development of its air-launched version was also commissioned.

    Rampage missile:

    The Rampage long-range air-to-surface missile is engineered for precision strikes against strategic targets from a safe distance. It minimizes risks to the aircraft and crew, enabling operations beyond the range of enemy air defenses. This offers a significant advantage when targeting high-value fixed or mobile assets, including command centers and air force bases.

    Officially unveiled in June 2018, the Rampage missile was initially developed by Israel Military Industries (IMI) and Israel Aerospace Industries (IAI). On November 25, 2018, Elbit Systems acquired IMI and rebranded it as Elbit Systems Land. Today, Elbit Industries produces the missile.

    Measuring 4.7 meters in length, 306 millimeters in diameter, and weighing 580 kilograms, the Rampage missile boasts excellent operational flexibility. It is compatible with a wide range of Eastern and Western fighter aircraft, eliminating the need for avionics changes. Rampage can be adapted to fighter jets through various methods, such as reprogramming the weapon system or deploying a separate avionics kit in the cockpit.

    The missile’s capability to operate in all weather conditions makes it a reliable option for quick-response attacks, functioning effectively both day and night.

    Additional features of this weapon include pre-programmed or in-flight mission execution, allowing target coordinates to be directly provided to the missile’s flight computer before firing.

    Guidance for the Rampage missile relies on a combination of satellite navigation and internal inertial navigation, with anti-jamming and fire-and-forget capabilities.

    The Rampage missile can be deployed by single-engine or so-called small fighter aircraft, each capable of carrying up to four missiles. The missile’s ease of use allows it to engage a single target or multiple targets simultaneously.

    Rampage missiles can be launched from altitudes of 3,000 to 4,000 feet, at speeds of Mach 0.7 to 0.95, and at angles of 0 to 35 degrees. Depending on the launch type, the missile hits the target at speeds of 350 to 550 meters per second (Mach 1.6), with an accuracy of less than 10 meters, and at a maximum angle of 90 degrees.

    The maximum range of this missile is stated in various sources to be up to 250 kilometers.

    It should be added that this missile is capable of using a diverse range of warheads, including multipurpose, bunker-busting, and fragmentation warheads.

    Operational history:

    The Israeli regime air force uses the Rampage missile extensively. The weapon’s operational history includes the assassination of Mustafa Ahmed Shahdi, deputy commander of Hezbollah’s Radwan forces, and Israeli airstrikes in Yemen.

    On December 26, 2024, the Israeli Air Force targeted several locations in Yemen, including Sana’a International Airport, the Haziz power plants in Sana’a and Ras Qanateb in northern Hodeidah, and military infrastructure in the ports of Hudaydah, Al-Salif, and Ras Qanateb on the west coast of Hudaydah. The operations were primarily carried out by F-15D Eagle, F-16I fighter jets, and KC-707 tankers. The F-16I fighter jets involved in these operations were armed with two Rampage air-launched missiles.

    Israeli attack on Sanaa airport control tower with Rampage air-launched missile

    It is likely that Israeli warplanes used Rampage air-launched missiles in the October 26 attacks against Iran, targeting the Qadir defense installations and radar site in Ahvaz, the Ilam radar site, and the Abadan refinery. The proximity of these targets, all located less than 200 kilometers from the southwestern border with Iraq, supports this possibility.

    Users of Rampage rocket:

    Israel: The Israeli Air Force is the first user of the Rampage missile. This weapon is typically seen in combination with F-16 fighters. Retired Kfir fighters can also be equipped with this missile. Sri Lanka, Ecuador, and Colombia still have this fighter jet in service and are considered potential customers of the Rampage missile.

    India: The Indian Air Force selected the Rampage missile for service in 2024. The force’s fleet includes Sukhoi-30 and MiG-29 fighters. The Indian Navy’s MiG-29 fighters also use this missile.

    Greece: The Hellenic Air Force is considering introducing the Rampage missile for its F-15 fighters.

    Rampage missile specifications:
    Type: Standoff air-to-surface missile
    Manufacturer: Israeli regime
    Unveiled: 2018
    Length: 4.7 meters
    Diameter: 306 mm
    Range: up to 250 km
    Speed: 1.6 Mach
    Accuracy: 10 meters CEP
    Weight: 580 kg
    Warhead: Multipurpose
    Warhead weight: 150 kg
    Flight altitude: 12,190 meters
    Guidance: GPS/INS – IR

    Rampage air-to-surface missile – click to view in full size

    More images of Rampage missile:

    Posters of Rampage missiles in Farsi, Russian and Arabic:

    Source:
    Rampage missile
    Cost effective rocket for aircraft unveiled
    IMI develops air-launched missile that sounds familiar
    New multiple rocket launchers for the Spanish Army
    EXTRA Long-range high precision rocket
    EXTRA – Extended range Rocket System
    Rampage Air-to-Ground Precise Strike Weapon, Israel

  • Military Knowledge: 358 Missile; The World’s First Drone-Based Air Defense Missile!

    Military Knowledge: 358 Missile; The World’s First Drone-Based Air Defense Missile!

    The 358 missile is the world’s first UAV-based defense missile, introducing a groundbreaking defense concept that combines the capabilities of unmanned aerial vehicles (UAVs) and missiles to target hostile aircraft effectively. Iran is the first nation to deploy this type of system in real battlefield conditions. Evidence suggests that this system was first employed by Iran’s regional ally, the Yemeni army (Ansar Allah Movement).

    History:

    According to information disclosed by the IRGC in the documentary “Parchamdar” (Flagship), footage has been released showing the moment an MQ-1B drone was shot down by a 358 missile. So far, four drones of this type have been shot down in Yemen, and the released video likely dates back to 2016 or 2017, during the field testing phase of the 358 missile. Consequently, the design and development of this weapon must have occurred one or two years before the destruction of the MQ-1B drone.

    Image of the destruction of an American MQ-1B belonging to the UAE on the Yemeni front by a 358 missile

    But the official sighting of this missile dates back to 2018 and 2019. In 2018, its wreckage was discovered by the Saudi army, and in 2019, an American warship intercepted and seized a shipment of Iranian weapons en route to Yemen in the Gulf of Aden.

    358 missile design:

    The 358 missile features a cylindrical body measuring 150 mm in diameter and 2.7 meters in length. It employs an infrared imaging seeker (IIR) in its nose to locate and lock onto targets.

    Following the camera, there is a 360-degree laser proximity sensor, and beyond the proximity sensors, a 10-kg fragmentation warhead with an effective radius of 30 meters.

    Components of the 358 missile

    At the front of the missile, just after the warhead, are four movable canards used for guidance. These canards are similar in appearance and function to those on the R-27 missile. They start narrow and sharp, widening towards the tip, and are large enough to provide part of the necessary lift force.

    Alongside the large steering canards, there are four very small triangular fins designed to stabilize airflow during extremely fast, unbalancing turns.

    The middle section of the missile contains the inertial guidance equipment and the missile computer. Additionally, because the antenna is located in this section, the communication equipment is also housed here.

    In the middle section, near the rear of the rocket, are four large fixed wings that generate lift. This section also houses the rocket’s fuel tank.

    At the rear of the missile are four small fixed stabilizer fins and the missile’s mini-jet engine. The engine has four air intakes recessed into the fuselage.

    This missile cannot take off independently, so a rocket booster is installed at the bottom of the missile to assist in the initial launch.

    An examination of shipments seized in 2019 and 2022 by the US and UK reveals that the engine used in the 358 drone is a Titan type from the Dutch company AMT. A review of the supply chain indicates that the engine was purchased indirectly from the manufacturer by a company in Hong Kong.

    The Titan engine has a diameter of 147 mm and a length of 385 mm. It weighs 3645 grams without a starter and 5211 grams with a starter. This engine provides a thrust of 392 newtons, which is equivalent to 88.12 pound-forces, and has a fuel consumption of 43.3 grams per kilonewton per second.

    Announced specifications of the Titan series engines produced by the Dutch company AMT

    The 358 missile has a loitering range of 100 km, a flight ceiling of 8,500 meters, and a speed of 700 km/h, with a total weight of 58 kilograms.

    There is no evidence that the missile can be recovered after firing, so it is used as a loiterer only in areas with a high probability of enemy aircraft. In other scenarios, the 358 missile is kept ready for launch when targets are detected by surveillance cameras and radars.

    The missile can be launched from simple launchers, similar to suicide drones. Additionally, truck launchers have been developed for this missile to enhance stealth.

    One of the most intriguing aspects of the 358 missile is its high level of customization. In its full configuration, the missile has 16 wings and fins. The operator can adjust the number of fins or change the position of the main wing based on specific needs and field conditions. This flexibility significantly enhances the missile’s maneuverability and usability.

    Installation location of the 358 missile wings and fins

    For example, during the official unveiling and hot testing of this missile in the joint air defense exercise “Eghtedar 1403“, the very small triangular fins on the front of the missile, as well as the small fins at the end of the missile, were removed.

    The use of the 358 missile in the Eghtedar 1403 exercise without the small triangular fins on the front section and the small fins at the end of the missile

    How it works:

    The 358 drone-based system consists of two main components: the 358 missile and thermal search cameras. This system can be utilized in two ways:
    The first method involves ground-based thermal search cameras scanning for targets such as drones and helicopters to introduce them to the 358 drone. Radar, serving as an auxiliary element of the system, can help determine the search direction for the ground-based cameras. Once the target is located, the 358 drone is launched and moves towards it. In the final stage, the drone locks onto the target with its thermal seeker and engages it.

    A type of thermal camera used to find aerial targets that has been used in Yemen.

    The second method involves the 358 missile loitering the skies of the battle area where helicopters and drones are likely to be present. By patrolling the tense battle zone, the drone searches for targets preloaded into its computer, such as helicopters and drones. In this mode, the 358 missile can operate either completely independently based on the information in its computer or receive target direction and location updates from the operator. Once it acquires the target, it locks on and engages.

    Promotional video of the preparation and firing of the 358 missile during the Eqtedar 1403 exercise

    Users:

    The 358 missile has been used by Iran, the Iraqi Islamic Resistance, Hezbollah, as well as Ansar Allah and the Yemeni army. Russia could also become a user of this missile if the need arises.

    In 2023, Russian Defense Minister Major General Sergei Shoigu visited an exhibition of Iranian military achievements. During this visit, Brigadier General Hajizadeh, Commander of the IRGC Aerospace Force, introduced the 358 missile and its truck-mounted launcher to Shoigu.

    Similar variants in Yemen:

    As mentioned, the 358 missile is also used by the Yemeni army and has demonstrated significant success in shooting down American and Saudi coalition aircraft.

    It is likely that Yemen has localized the production of this missile. In Yemen, the 358 missile is produced and used under the names Saqar-1 and Saqar-2. The Saqar-1 missile is similar to the 358 missile, while the Saqar-2 missile is an improved version of the Saqar-1 missile.

    Saqar-1 missile

    According to the information officially announced by the Yemeni army regarding the Saqar-1 missile, its specifications are identical to those of the Iranian 358 missile in all its components. However, the specifications of the Saqar-2 resemble those of the Iranian 359 missile, which we will discuss later in the article.

    Based on the information released by the Yemeni army about the Saqar-2 missile, this missile boasts a range of 150 kilometers, which is 50 kilometers more than the Saqar-1 (358 missile). Additionally, the flight altitude has increased from 28,000 feet (8,500 meters) in the Saqar-1 to 35,000 feet (10,600 meters). However, the images published during the latest Yemeni army parade on the occasion of the September 21 Revolution of the Saqar-2 missile actually show the same Saqar-1 missile (missile 358) with a configuration lacking the small triangular fins and fins at the end, as seen in the test and unveiling of the 358 missile in Iran’s Eqtedar 1403 exercise.

    An infographic of the Saqar-2 missile has also been released, stating the missile’s length to be 6 meters. However, upon examining the published images of the Saqar-2 missile during the Yemeni army parade, it is evident that the displayed missile is approximately 3 meters long, similar to the Saqar-1. Therefore, it is likely that the Yemeni army has not published the actual image of the Saqar-2 missile for security reasons. Alternatively, in the most optimistic scenario, a more powerful engine has been used in this version.

    359 missile:

    In 2025, during the broadcast of a television documentary, the Islamic Revolutionary Guard Corps of Iran unveiled a more advanced version of the 358 missile, known as the 359 missile.

    Based on the images and information provided, the 359 missile has larger dimensions than the 358 missile, and its length and diameter have almost doubled.

    Unveiling of the 359 missile in the television documentary Guardian of the Sky

    The missile is equipped with four movable canards at the front and four large fixed wings at the rear. The wings are enlarged in proportion to the fuselage. One of the interesting features of the fixed wings is that small control surfaces are used at the ends of the wings, which improve the maneuverability and control of the missile.

    Control surfaces at the ends of the 359 missile’s rear wings

    The 359 missile features a new and larger engine, which increases its speed to 1,000 kilometers per hour. It has a range of over 150 kilometers and a flight altitude of over 30,000 feet (9,200 meters).

    The warhead of the 359 missile is larger and has greater destructive and explosive power compared to the 358 missile. Additionally, if necessary, the 359 missile can be equipped with an electro-optical payload for reconnaissance and surveillance operations instead of a high-explosive warhead.

    Another notable feature of the 359 missile is its recoverability. According to published images, unlike the 358 missile, which was not recoverable, the 359 missile is equipped with a recovery parachute. Therefore, if the interception of hostile targets is unsuccessful for any reason, or if the 359 missile is used for reconnaissance and surveillance operations, it can be recovered using a parachute.

    Recovery parachute in 359 missile

    More images of the 359 missile:

    It’s worth noting that in 2020, the United States, inspired by the Iranian 358 defense missile, designed and developed a defense system called LIDS. The Coyote-2 interceptor in this system operates in a manner very similar to the 358 missile.

    Military Knowledge: FS-LIDS And M-LIDS Anti-Drone Systems

    358 missile specifications:
    Type: Loitering anti-aircraft missile
    Manufacturer: Islamic Revolutionary Guard Corps
    Country of manufacture: Iran
    Entered service: 2016 to 2019
    Length: 2.7 meters
    Diameter: 150 mm
    Wingspan: Approximately 1 meter
    Missile weight: 58 kg
    Warhead weight: 10 kg high-explosive fragmentation
    Warhead impact radius: 30 meters
    Maximum speed: 700 km/h
    Loitering range: 100 km
    Flying altitude: 8,500 meters (28,000 feet)

    Missile 358 posters in Persian, English, Russian, Chinese, Arabic and Hebrew:

  • Iran Unveils Underwater-Launched Suicide Drone (Video)

    Iran Unveils Underwater-Launched Suicide Drone (Video)

    In the video, an Unmanned Underwater Vehicle (UUV) surfaces, and the X-winged suicide drone, similar to the recently unveiled Rezvan drones, is launched from within the UUV using a rocket booster.

    Iran Unveils Underwater-Launched Suicide Drone

    The ability to launch drones from underwater vehicles provides a strategic advantage, making it more challenging for adversaries to detect and counter these threats effectively. By integrating these weapons with artificial intelligence capabilities, their effectiveness can be significantly enhanced.

    Indeed, the combination of Unmanned Underwater Vehicles (UUVs) and Unmanned Aerial Vehicles (UAVs) could pose a significant threat to hostile warships in strategic locations like the Persian Gulf, Arabian Sea, and especially the Red Sea! This technological advancement increases Iran and its allies’ defensive and offensive capabilities in these critical maritime regions.

    Iran Unveils Underwater-Launched Suicide Drone
  • Shahid Bagheri Drone Carrier Joins IRGC Navy Fleet (Video)

    Shahid Bagheri Drone Carrier Joins IRGC Navy Fleet (Video)

    Shahid Bagheri (C110-4) drone carrier was officially inducted into the Islamic Revolutionary Guard Corps Navy fleet on February 6. The ceremony was attended by Major General Mohammad Hossein Bagheri, Chief of Staff of the Armed Forces, Major General Hossein Salami, Commander of the IRGC, and Admiral Alireza Tangsiri, Commander of the IRGC Navy.

    Shahid Bagheri drone carrier measures 240 meters in length, 32 meters in width, and has a draft of 12 meters.

    This drone carrier features a 180-meter runway and an upwardly curved ramp, similar to those found on aircraft carriers, to facilitate drone takeoff. The ship is capable of carrying and operating various types of drones and helicopters. Additionally, it has a large space on the lower levels for housing multiple drones, missile-capable speedboats, and more.

    It is reported that the Shahid Bagheri drone carrier has the capacity to carry 60 drones and 30 fast missile boats. This capability significantly enhances its operational flexibility and firepower.

    Like all aircraft carrier or drone carrier class ships, this vessel utilizes an elevator to transport aircraft and other essential items from the hangar to the deck. Behind the bridge, there is a sizable area with a helicopter pad, designated for the ship’s primary helicopter(s). On the unveiling day, this section was covered with a tent for the ceremony and the commanders’ presence. Additionally, it appears that the main missile weapons of the Bagheri drone carrier are situated in this section as well.

    The videos show the 60% scale variant of the Qaem drone being transferred to the ship’s deck by elevator and the 20% scale variant undergoing a flight test. These videos are archived and are not from the day of the joining ceremony.

    Regarding armament, the Bagheri drone carrier is currently equipped with eight Kowsar 222 air defense missiles, each with a range of 17 km, positioned at the front and rear of the ship. Additionally, there are eight anti-ship missiles from the Qader/Nasir series, comprising four twin launchers, located behind the bridge. There is also a container in this section that probably contains two ballistic missiles. The vessel also features a single-barreled 30 mm cannon with an electro-optical system at the front and two triple-barreled 20 mm Asefeh Gatling guns situated at the rear and stern.

    Admiral Tangsiri’s explanation about IRIS Shahid Baqeri

    According to Admiral Tangsiri, Commander of the IRGC Navy, the Shahid Bahman Bagheri drone carrier is equipped with the following specifications and features:

    • Speed of 22 knots
    • Fast attack boats capable of firing missiles with a range of 30 kilometers
    • Drone combat group (reconnaissance, surveillance, and combat)
    • Attack and support helicopter combat flotilla
    • Submarine combat team
    • Six-bed specialized hospital and various medical and welfare facilities
    • 180-meter runway
    • Three separate fueling stations for helicopters, drones, and vessels
    • Electronic warfare teams
    • Missile defense systems
    • Special commando operations capabilities
    • Diving team
    • Long-range surface-to-surface missiles
    • Drone and helicopter control tower
    • Drone squadron
    • Eight two-story hangars
    • Ability to operate continuously for one year

    One of the most intriguing aspects of adding this drone carrier is the unveiling and deployment of the Qaem Jet drones. The Qaem (Ghaem) drone, also known as Qaher 313, has been observed in two versions—60% and 20%—on Shahid Bagheri drone carrier. It remains uncertain if the 100% scale variant of the Qaem drone will also be deployed on this carrier.

    As previously mentioned, Shahid Bagheri drone carrier is equipped with missile-launching fast craft. These fast craft are launched into the water using overhead cranes located on the sides of the ship.

    Iran can utilize drone carriers as floating bases in nearby waters or international waters to conduct various operations, including reconnaissance, intelligence, and combat missions. The United States, China, Russia, and Turkey have previously employed this capability at sea.

    The name of this ship, Shahid Bagheri, honors martyr Bahman Bagheri, who was martyred in 1988 during the Iran-Iraq War at Faw. Bahman Bagheri was a prominent martyr of the IRGC and served as the commander of communications at the IRGC Navy’s Nuh Base during the war.

    Ababil-3 drone landing and takeoff from the deck of the IRGC Navy’s Shahid Bahman Bagheri drone carrier

    Shahid Bagheri Drone Carrier specifications:
    Commissioned: February 6, 2025
    Length: 240 meters
    Beam: 32 meters
    Draft: 12 meters
    Speed: 22 kn
    Displacement: 42,000 tons
    Endurance: 1,000 days
    Missile arsenal:
    8 air defensive missiles
    8 anti-ship missiles
    Guns:
    1x 30 mm automatic cannon
    2x 20 mm Asefeh cannons
    Aircraft carried: 60 UAVs and various types of helicopters
    Boat carried: 30 fast missile boats
    Made by: Iran

  • Military Knowledge: Ababil-5 Reconnaissance Combat Drone

    Military Knowledge: Ababil-5 Reconnaissance Combat Drone

    During a parade held on April 18th, 2022 in Tehran, a new drone called “Ababil 5” (also known as Ababil-V or AB-V) was revealed to the public. Prior to this event, no official information about the Ababil 5 drone had been released. Although the exact specifications of the Ababil-5 drone have not been officially disclosed, we will analyze the available footage to review its specifications and features in this article.

    The aerodynamic design of this UAV is generally akin to that of the Mohajer-6. While the Mohajer-6 features a High Boom Tail configuration, the Ababil-5 employs a Boom Tail configuration. This design choice not only shortens the runway length needed for landing and takeoff but also enhances the drone’s ability to perform more intense maneuvers.

    Types of aircraft tail configurations

    The body of this drone has sharp angles and lines, which are clearly designed to reduce the radar cross section from the front, i.e., when the bird is approaching the radar.

    Sharp angles and lines

    Considering the dimensions of the truck floor, the Ababil-5 drone is estimated to have a wingspan of approximately 12 meters.

    Ababil-5 estimated wingspan

    The Ababil-5 boasts a wingspan that is 20% larger than that of the Mohajer-6. This increase in wing area allows for a greater cargo mass, enabling the Ababil-5 to carry six Qaem-1 bombs, compared to the Mohajer-6, which can carry up to four bombs.

    The landing gear is designed to retract, which helps to reduce drag and minimize the radar cross-section. This reduction in drag, facilitated by the retractable landing gear, enhances the UAV’s cruise speed, flight endurance, and range.

    Another reason for incorporating retractable landing gear at the front of the body is to prevent obstruction of the electro-optical’s view. If the camera system were placed in front of the landing gear, as seen in the Mohajer-6, the increased distance from the drone’s center of mass would require additional balance weight, potentially affecting the drone’s performance. Therefore, retractable landing gear is utilized to avoid these issues.

    Ababil-5 front wheel landing gear

    The rear wheel landing gear is fixed type. According to the published images, the base of the rear wheels are connected to each other by a wire, which limits the amount of final bending of the landing wear during landing and prevents the body from hitting the runway surface.

    Ababil-5 rear wheel landing gear

    When it comes to weaponry, the Ababil-5 has been observed equipped with Qaem Glide bombs, Almas missiles, and Arman-1 bombs. This drone is capable of carrying six Ghaem-1 bombs and four Ghaem-5 bombs.

    Read more:
    Military Knowledge: Qaem Smart Bombs
    Military Knowledge: Almas Missile

    Given that the Ababil-5 has been adopted by both the Iranian Army and the IRGC, and considering it is manufactured by the Iran Ministry of Defense, there’s a possibility that the ammunition used in the Mohajer-6 could be compatible with the Ababil-5, due to the similarity of some of their components.

    Carrying a larger number of bombs or cargo effectively increases the lethality of the UAV, and economically, it destroys targets with fewer sorties and hunts targets at a lower cost. Also, reducing the number of flight sorties can be important both in terms of maintenance and increasing the operational rate of the fleet.

    In terms of camera system, the Ababil-5 drone can be equipped with a more advanced electro-optical system, in addition to using older electro-optical systems such as the Eagle 4 models. This advanced camera features at least 60x zoom capabilities, along with a thermal imaging camera and a laser rangefinder.

    Ababil-5 electro-optical system
    During the 1402 Joint Drone Exercise of the Islamic Republic of Iran Army, the Ababil-5 drone was used to observe an Arleigh Burke-class destroyer in the Indian Ocean for four hours

    This drone is powered by a piston engine. Images from the NAZAJA exercise in February 2024 reveal that the Ababil-5 is equipped with a Rotax 915 iS engine or a similar model. The Rotax 915 engine delivers up to 141 horsepower at its peak performance.

    Overall, Rotax engines are commonly employed in many Iranian drones. Due to sanctions targeting Iran’s military and aviation sectors, direct procurement from Rotax is not feasible. Consequently, to cater to the varied requirements of drones in Iran, numerous components of different Rotax engines have been domestically produced, with some models achieving a complete localization rate of 100%.

    With the Rotax 915 iS engine, the Ababil-5 achieves a flight ceiling of approximately 7,000 meters (23,000 feet) and a speed of around 210 kilometers per hour. Its maximum takeoff weight is estimated to be about 1,000 kilograms.

    The Ababil-5 drone boasts a flight duration of 12 hours in combat mode, and up to 24 hours in reconnaissance mode without a combat payload. It has a maximum range of up to 2,400 kilometers.

    Video showcasing the Ababil-5 drone’s performance during the Islamic Republic of Iran Army Ground Forces exercise in February 2024

    Ababil-5 UCAV specifications:
    Length: ~ 8 meters
    Wingspan: ~ 12 meters
    Maximum range: up to 2,400 kilometers
    Flight ceiling: 7,000 meters
    Flight endurance: 12 hours combat – 24 hours reconnaissance
    Engine type: Rotax 915 – 141 horsepower (at its peak)
    Speed: 210 km/h
    Hardpoints: 2, with the ability to carry 6 missiles and bombs
    Maximum takeoff weight: ~ 1,000 kilograms
    Weapons payload: up to 150 kilograms
    Origin: Iran

    Ababil-5 UCAV – Click to view full size

    More images of Ababil-5 drone:

    “Ababil 5” UAV poster collection in Farsi, Russian, Arabic, Chinese and Hebrew:

  • China Unveils Two Sixth-Gen Fighter Jets: Chengdu J-36 and Shenyang J-50

    China Unveils Two Sixth-Gen Fighter Jets: Chengdu J-36 and Shenyang J-50

    The Chengdu Aircraft Corporation’s (CAC) J-36 fighter jet has garnered significant attention due to its unique design. It was first publicly observed during a test flight over Chengdu, accompanied by a J-20S fighter jet.

    The J-36 fighter features a diamond-like double delta wing configuration, lacking both a tail and a vertical rudder. The removal of the vertical rudder is intended to reduce the radar cross-section. The wing angles suggest that it has been aerodynamically optimized for supercruise capability.

    The J-36 fighter jet employs five trailing edge control surfaces on each wing, including two split flap rudders at outboard wing edges to enhance maneuverability.

    Two split flap rudders at outboard wing edges to enhance maneuverability.

    A notable aspect of the J-36’s design is its use of three low-radar section turbofan engines, with the two outboard engines likely featuring thrust vector control (TVC). The engine with a movable nozzle enhances the fighter’s maneuverability. The use of three engines is a unique and innovative choice for this type of fighter jet. Previous designs and previews depicted the J-36 with two engines, making the current configuration even more distinctive.

    The J-36 features three air intakes: one located on top of the fuselage behind the cockpit, and two on the underside of the fuselage.

    Based on available information, the J-36 fighter is estimated to be between 20 and 26 meters in length, with a wingspan of approximately 24 meters and a wing area of over 200 square meters. Its maximum takeoff weight is estimated to be between 45 and 55 tons.

    Military experts estimate that J-36 can achieve speeds of Mach 2.5 and has a combat radius of approximately 3,000 kilometers, which is considered exceptionally long for a fighter jet.

    The J-36 has three weapons bays. The large, central bay is approximately 7.6 meters long, and can accommodate missiles such as the PL-17 air-to-air missile or heavier air-to-surface missiles. There are two smaller bays under the J-36’s fuselage that can carry smaller missiles. Given the large ammunition bays, the J-36 is likely to also serve as a tactical bomber.

    J-36 flight test over Chengdu city escorted by a J-20S fighter jet

    Another sixth-generation fighter from China is the J-50, developed by the Shenyang Aircraft Corporation (SAC). It was observed during a flight test over Shenyang on December 26, 2024.

    The J-50 fighter jet also incorporates the specific airframe design characteristics of a sixth-generation fighter jet. This prototype features a combination of a delta configuration with a cranked-arrow design with sharply swept lambda wings with droopped wing tips.

    A view of various delta configurations. The J-50 is a combination of the cranked arrow and lambda configurations. The J-36 configuration is similar to the diamond configuration.

    One fascinating aspect of the J-50’s airframe and aerodynamic design is its folding control surfaces. These surfaces can be folded and aligned horizontally along the wing, and when needed, they can be unfolded to act as two vertical fins. This feature enhances the fighter’s maneuverability and control in the absence of vertical rudders. The incorporation of this technology indicates that the J-50 is designed for both air superiority and strike roles.

    A video rendering of the fuselage and aerodynamics of the J-50 fighter jet. The video shows how the folding wings work on this fighter jet.

    Based on available information, the J-50 is approximately 22 meters in length, with a wingspan of 22 meters and a wing area of about 145 square meters. Its maximum takeoff weight is estimated to be around 40 tons. The J-50 can reach speeds of Mach 2 and has a combat radius of approximately 2,200 kilometers.

    The J-50 fighter jet uses two engines and has two air intakes under the fuselage.

    The J-50 is smaller in size compared to the J-36, resulting in smaller ammunition bays and the ability to carry fewer missiles. Its moderate size makes it more suitable for carrier-based operations.

    J-50 fighter jet test flight over Shenyang

    It is important to note that the names of these two sixth-generation fighters have not been officially announced by their manufacturers. The names used, J-36 and J-50, are speculative and have been attributed by military experts.

    In general, while initial information suggests that China has achieved sixth-generation fighter jet status with the J-36 and J-50, the exact roles and capabilities of these aircraft remain unknown. Sixth-generation fighter jets are distinguished not only by their unique appearances but also by critical internal components and advanced technologies such as engine design, control systems, and artificial intelligence, etc. which collectively define their true capabilities.

    China has indeed made significant strides in military aviation, appearing to lead in the development of sixth-generation fighter jets. Meanwhile, the United States has been working on its own sixth-generation fighter under the Next Generation Air Dominance (NGAD) program, which has faced delays and challenges due to technical complexities and high costs. Western European countries and Japan are collaborating on two projects, Tempest and the Future Combat Air System, to keep pace in the sixth-generation fighter race. Russia is also developing a sixth-generation fighter known as the PAK DP/MiG-41.

    Source:
    Chengdu J-36
    Chengdu J-50
    J-50 Stealth Fighter Revealed
    Delta Wing UAV
    New Chinese Sixth-Gen Fighters

  • Iran Installs New Over-the-Horizon Radar with 800 km Range in Northwest Region

    Iran Installs New Over-the-Horizon Radar with 800 km Range in Northwest Region

    This Nazir radar, with its 800 km range, can detect targets at altitudes exceeding 30 km. It can identify various low radar cross-section targets, such as drones and cruise missiles.

    With the Nazir radar in Gilan, the entire airspace over the Baku government, Armenia, large parts of eastern Turkey, most of Georgia, western Turkmenistan, part of southwestern Kazakhstan, and the Caspian Sea will be under Iran’s air defense surveillance.

    During the Israeli airstrikes on Iran on October 26, 2024, the Caspian Sea airspace was used—likely with cooperation from the Baku government—to target the Shahroud facilities. Now, with the Nazir radar operational in Gilan province, the skies over Baku and the Caspian Sea will be continuously monitored by Iran’s defense network, ready to counter any hostile movements.

  • Military Knowledge: Sparrow Air-Launched Ballistic Missiles And ROCKS Missile

    Military Knowledge: Sparrow Air-Launched Ballistic Missiles And ROCKS Missile

    Air-launched ballistic missiles, launched from fighter jets, can be highly effective and strategically advantageous for attacking targets. Their significance is especially notable when surprise and rapid deep strikes are required in environments with sophisticated and impenetrable defense systems.

    Sparrow missiles gained great attention after their remnants were discovered following the Israeli attacks on Iran on April 19 and then again on October 26. The missile boosters from the first attack were found in Al-Azizia, Wasit Province, which is 100 kilometers from the Iranian border and near Baghdad. In the second attack, the remnants were located in Salahuddin Province.

    Ballistic missiles pose a significant threat to Israel, with Iran being one of the most formidable adversaries in this domain. Iran’s advancements in ballistic missile technology have made it a powerful force, causing considerable concern for Israel.

    The Israelis initiated the development of anti-ballistic missile defense systems to mitigate the threat posed by ballistic missiles. However, testing these systems necessitated the use of ballistic missiles, which European countries did not possess in their arsenals. Additionally, treaties like the INF prevented the United States from supplying Israel with these types of missiles.

    This situation gave the Israeli regime a viable excuse, with American assistance, to develop high-speed, maneuverable target missiles to test and enhance its anti-ballistic capabilities. Additionally, producing these missiles could enable the Israeli regime to use them offensively, if necessary, to strike distant targets and enemy defense systems.

    The Israelis designed the missile to be carried and launched by a fighter jet. This approach could significantly enhance the strategic offensive capabilities of their fighter jets.

    The development of this target missile, known as Project Sparrow, was initiated by Israel’s Rafael Military Industries with support from the American company Raytheon.

    The Sparrow missile family consists of three models: Black Sparrow, Blue Sparrow, and Silver Sparrow. Depending on the mission requirements, the warheads can be of three different types: liquid-filled warheads, high-explosive warheads, and inert warheads.

    Sparrow missile warheads

    Equipped with explosive warheads, Sparrow missiles offer strategic advantages to the Israeli Air Force. Carried by fighters or bombers, these missiles can cover greater distances than ground-launched variants, thanks to the increased range provided by the aircraft and the launch altitude. Their speed and high maneuverability make them particularly effective against heavily defended, deep, and strategic targets.

    Furthermore, there is the potential for Sparrow missiles to be equipped with nuclear warhead. Due to Israel’s policy of nuclear ambiguity, this capability is not officially listed in the Sparrow catalog. However, if Israel were to pursue this option, it would undoubtedly pose a significant and dangerous threat.

    The official catalog from Rafael Military Industries outlines three flight profiles for these missiles: ballistic trajectory to mimic Scud-level missiles with conventional warheads, barrel roll, and maneuvering to simulate stealthy competitors like Iranian missiles with maneuverable warheads.

    Three flight profiles for Sparrow missiles

    Let’s take a closer look at the different models in the Sparrow series. As previously mentioned, there are three models: Black Sparrow, Blue Sparrow, and Silver Sparrow. According to the official catalog, two of these missiles are equipped with detachable warheads.

    Sparrow missiles, from top to bottom: Black Sparrow, Blue Sparrow, and Silver Sparrow

    Black Sparrow and ROCKS missile:
    The Black Sparrow is designed as a Scud-B missile simulator. While its speed is unknown, its range is estimated to be between 600 and 800 kilometers. This missile can be launched from F-16 and F-15 fighters. The Black Sparrow measures 4.85 meters in length, weighs 1,275 kilograms, and uses inertial/GPS guidance.

    Black Sparrow missile test by Israeli F-15 fighter jet
    A video of Black Sparrow ballistic missile (the early version)

    Israel has developed another missile based on the Black Sparrow, called the ROCKS missile. This missile closely resembles the Black Sparrow in both dimensions and appearance.

    The ROCKS missile was displayed at the 2019 Aero India air show in Bengaluru, India.

    The ROCKS missile at the Aero India air show in Bengaluru, India, 2015

    According to available information, the ROCKS missile is a supersonic missile with a speed of approximately Mach 3. It utilizes inertial guidance and GPS for mid-course navigation. Additionally, during the final phase to reach its target, the ROCKS missile is equipped with an electro-optical seeker, and an alleged anti-radiation homing system to enhance its anti-radar capabilities.

    The circular error probable (CEP), or the accuracy of this missile, is estimated to be around 3 meters.

    The ROCKS ballistic missile can be outfitted with either a penetrating or high-explosive warhead. When equipped with a delay warhead, it becomes particularly effective against fortified targets buried deep underground.

    From the limited images available of the ROCKS missile, it appears that the warhead is approximately 1.2 meters in length and has a diameter of about 500 millimeters. Based on the missile’s overall length and weight, and comparing these dimensions with the warhead, it is estimated that the warhead weighs around 150 kilograms.

    The range of this missile is estimated to be up to 800 kilometers.

    Footage of a ROCKS missile test targeting a sea-based objective captures the final moments of impact from the electro-optical seeker’s viewpoint.

    A key question is whether radar-absorbing materials are used in the ROCKS version. While Israel has access to this technology through the U.S., its application in ROCKS is uncertain. The Israelis place significant emphasis on the electro-optical and anti-radiation systems, highlighting their potential to enhance the missile’s targeting accuracy. This emphasis likely stems from their awareness of Iran’s advanced electronic warfare capabilities.

    Blue Sparrow missile:
    The Blue Sparrow missile features a detachable warhead equipped with a Divert Attitude Control System (DACS). DACS consists of small rocket thrusters mounted on the projectile. When activated and fired at short intervals, these thrusters cause the projectile to rotate or change its angle of motion, enabling it to maneuver towards the target. In its role as a target missile, the Blue Sparrow simulates Iranian missiles with maneuverable warheads. When used offensively, it functions as a high-speed, maneuverable ballistic missile.

    NASA tests control thrusters on Orion launch abort system

    The Blue Sparrow missile boasts a range of approximately 1,000 kilometers and can reach speeds between Mach 5 and 9, classifying it as a hypersonic ballistic missile.

    The Blue Sparrow missile uses a GPS and dual inertial guidance system. The implementation of dual inertia significantly reduces the potential for error. The missile’s accuracy, or circular error probable (CEP), is estimated to be approximately 3 meters.

    The Blue Sparrow measures 6.51 meters in length and weighs 1,900 kilograms. Published images indicate that its detachable warhead, including the guidance system, is 2.8 meters long with a diameter of about 530 millimeters.

    Given the dimensions of the warhead and the overall weight of the missile, the Blue Sparrow warhead’s weight, similar to the ROCKS, is estimated to be around 150 kilograms.

    In classified U.S. documents related to the Israeli attack on Iran, leaked on October 15, 2024, this missile is referred to by the code name “Golden Horizon.”

    Silver Sparrow missile:
    The Silver Sparrow missile is another variant in the Sparrow series. Similar to the Blue Sparrow, it features a detachable warhead. However, it is larger and heavier in terms of both dimensions and weight.

    The Silver Sparrow has been reported to measure 8.39 meters in length and weigh 3,130 kilograms.

    There are no images of the Silver Sparrow missile or its tests available. Reportedly, due to its high weight, the first test launch was conducted by a C-130 aircraft. The Silver Sparrow was initially tested on September 2, 2013. The launch, originating from the Mediterranean Sea, was detected by the Russian missile early warning radar in Armavir, and the Israelis confirmed the test shortly thereafter.

    Based on the available information, the Silver Sparrow warhead appears to be very similar in size to the Blue Sparrow’s. However, a larger booster has been used to extend its range, which is estimated to be up to 1,500 kilometers.

    Based on official catalog information, the missile’s guidance system utilizes both GPS and inertial navigation. Its accuracy is estimated to be around 3 meters, similar to the Blue Sparrow missile.

    Specifications of the Sparrow family missiles:
    Type: Air-launched ballistic missile
    Manufacturer: Rafael Advanced Defense Systems
    Origin: Israel

    Black Sparrow missile:
    Range: up to 800 km
    Length: 4.85 m
    Weight: 1275 kg
    Propulsion: single stage solid propellant
    Guidance: GPS/INS

    ROCKS missile:
    Range: up to 800 km
    Length: 4.85 m
    Weight: 1275 kg
    Warhead length: ~ 1.2 m
    Warhead diameter: ~ 500 mm
    Warhead weight: ~ 150 kg
    Propulsion: single stage solid propellant
    Guidance: GPS/INS – EO seeker
    Speed: ~ Mach 3
    Accuracy: ~ 3 m CEP

    Blue Sparrow Missile:
    Range: up to 1000 km
    Length: 6.51 m
    Weight: 1900 kg
    Warhead length: 2.8 m
    Warhead diameter: ~ 530 mm
    Warhead weight: ~ 150 kg
    Propulsion: single stage solid propellant
    Guidance: GPS – Dual INS
    Speed: Mach 5 +
    Accuracy: ~ 3 m CEP

    Silver Sparrow Missile:
    Range: up to 2000 km
    Length: 8.39 m
    Weight: 3130 kg
    Warhead length: 2.8 m
    Warhead diameter: ~ 530 mm
    Warhead weight: ~ 150 kg
    Propulsion: single stage solid propellant
    Guidance: GPS – Dual INS
    Speed: Mach 5 +
    Accuracy: ~ 3 m CEP

    Sparrow and ROCKS missiles – click to view in full size

    Sparrow and ROCKS missile posters in Persian and Russian:

    Sources:
    Sparrow target missile
    ROCKS (missile)
    Israel’s Rafael Eyeing to Sell Rocks to India

  • Military Knowledge: Yafa Drone

    Military Knowledge: Yafa Drone

    It seems that the “need for greater range” of attack is a good explanation for the reason behind the manufacturing of Yafa drone, which is a UAV that has its roots in the Sammad class, and is considered as a big development in terms of range, compared to previous drones.

    The first prototype of the Samad class drones was unveiled in 2018. Like Yaffa UAV, Samad had a long and flat wing design, which could reach a greater range, while it rises high in the air. The aircraft needs to fly at high altitudes in order to be able to reach a greater range in this flying method. The high flight altitude provides the enemy with the opportunity to detect the presence of the drone more quickly and its radars will be able to issue early warning.

    It is believed that in the July 19 air attack on the occupied city of Jaffa (Tel Aviv), the Israelis may have noticed the UAV; however, they could not act in time because of operator fault.

    The possible path of the Yafa drone towards Tel Aviv

    The path that the drone had flown, was effective in misleading the Israelis. The long route of the drone flight and its circumvention over the waters far from the Israeli-occupied territories may have played a role in confusing them.

    Military Knowledge: Sammad-3 Reconnaissance and Suicide Drone

    One of the most vital segments of an aircraft is its propulsion system. In the Sammad drone, two German two-cylinder engines 3W-110i B2 with 10 horsepower have been utilized, and a Chinese two-cylinder DLE-170 engine with approximately 17 horsepower has been applied in the more advanced versions.

    The state of affairs in Yemen and the sanctions imposed on the Arab country make the usage of accessible equipment a priority for the Yemeni army. The aforementioned engines have dual capabilities and are being utilized in civilian aerial industries and are easily accessible. Of course, the extensive usage of the German engine by the Axis of Resistance has forced Germany to adopt a more vigilant approach in this respect, and the Germans have attempted to cut the access of resistance groups to the 3W-110i B2 engines.

    For instance, based on the findings of Germany’s intelligence services, some 42 engines of this class were purchased in Greece in 2015 and then ended up in Iran. For this reason, the German officials have imposed a series of restrictions on the dealing of this sort of dual-use engine. The usage of a Chinese engine, which is both more powerful, on the other hand, the seller does not have a significant problem with the type of usage, as well as Iran’s success in developing a more powerful version of this class of engine, were among Tehran’s response to the restrictions imposed by the West.

    It can be predicted that similar Chinese engine or an upgraded Iranian version of that engine will be used on Jaffa suicide drone.

    Video of the unveiling of the Yafa suicide drone

    The Yaffa UAV requires a rocket booster to be able to start moving and speed up, like the previous variants of the Samad drone, and after reaching the appropriate speed and altitude, a piston engine begins working.

    Yafa drone’s rocket booster

    The prototypes of the Samad drone are probably utilize civilian GPS for navigation in the guidance and navigation segment, which naturally allows the UAVs to strike fixed targets, but it cannot be expected to perform appropriately, when it comes to encountering GPS disruptors.

    The Yemeni Armed Forces have applied a combination of inertial and GPS guidance to resolve this problem during the overhaul of the Yafa drone. A computer set controls the UAV’s trajectory. The suicide Yafa drone can improve the chances of reaching its target by choosing a more proper route. According to data released by the United States, two types of gyroscopes, the V-9 and V-10, have been installed on Yemeni drones. For instance, the V-10 version has been found among the remnants of Qasef drone. One of the advantages of an inertial conduction system is that it is very hard to be disrupted.

    V10 gyroscope

    In terms of dimensions, the Yafa UAV is obviously larger than the previous versions so that it can carry more fuel inside its fuselage. More fuel will help Yafa drone to fly a longer range. In accordance with the images of Yaffa drone, the aircraft has a length of 3 meters and a wingspan of about 6 meters. With these features, the range of Yafa drone is perhaps about 2,500 kilometers. This range is consistent with the expected 2,600-kilometer route flown to conduct air strike on Tel Aviv city.

    Consistent with the route covered and the type of its engine, the average speed of Yafa UAV is between 140 and 180 kilometers per hour and enjoys a flight duration of 14 hours.

    The drone has a high-explosive warhead, which weighs between 20 and 50 kilograms.

    Based on the official announcement by the Yemeni authorities, the drone is classified among stealth aircraft, possibly due to the fact that a honeycomb structure is being used inside its fuselage.

    On the whole, the Yafa UAV is considered as a long-range suicide drone, which has extended the space of operations of the Yemeni Armed Forces to the city of Tel Aviv as well as the southern half of occupied Palestine. It is also considered a significant breakthrough in terms of the range and guidance compared to the Samad class drone. Given that Israel is a regime, which possesses a powerful defense system and is widely supported by extra-regional powers, this UAV is certainly not an armament that changes the balance of war against the Israeli regime. Nonetheless, the Yafa drone represents a growing trend of cutting-edge modern technologies in the Yemeni army.

    Specifications of the Yafa suicide drone:
    Type: Suicide Drone
    Country of Manufacture: Yemen
    Unveiled: July 23, 2024
    Length: 3 m
    Wingspan: 6 m
    Engine: Piston
    Range: 2,500 km
    Speed: 180 km/h
    Flight Duration: 14 hours
    Navigation: INS – GPS – Radio
    Warhead Weight: Up to 50 kg
    Takeoff Type: JATO

    Yafa suicide drone – click to view full size

    More images of Yafa drone:

    The collection of Yaffa suicide drone posters in Arabic, Hebrew, Farsi and Russian languages:
